Class: Type confusion / arb R/W Reach: Local (guest)
Oracle VM VirtualBox OSS 7.2.20 (f2792cf44f663989818507e36d3db5f978523c5e)
SAS1068 MPT CONFIG treats SCSI-SPI Port 0 as a 12-byte page. On SAS that page is the other half of a union: pManufacturingPage7 plus cbManufacturingPage7. A guest CONFIG READ DMA-leaks the heap pointer. A CONFIG WRITE plants pointer and size. Manufacturing page 7 then copies through the planted pointer.
Guest ring3 on an attached SAS1068 (PDM LsiLogicSas, PCI 1000:0054) gets arbitrary read/write in the VM process. That is VirtualBoxVM / VBoxHeadless heap, not a host-kernel escape.
| ID | no CVE yet |
| Class | Type confusion / arb R/W |
| Reach | Local (guest) |
| CWE | CWE-843, CWE-822 |
| CVSS | Critical: 8.8 CVSS:3.1/AV:L/AC:L/PR:L/UI:N/S:C/C:H/I:H/A:H |
| Product | VirtualBox OSS |
| Affected | 7.2.20 (f2792cf44) |
| Needs | attached SAS1068 (PDM LsiLogicSas, PCI 1000:0054) |
| License | GNU Affero GPL v3.0 |
| Lab | loopback source harness |
Method: guest ring3 programs the SAS1068 MMIO doorbell or request FIFO with MPT_MESSAGE_HDR_FUNCTION_CONFIG (0x04), page type SCSI-SPI Port 0 (0x03). Dispatch always calls the SPI getter. Only EXTENDED is SAS-gated. The page-attribute getter is commented out, so the Readonly Port 0 page is still writable. SPI Port 0 is packed 12 bytes and overlays SasPages.pManufacturingPage7 (8) plus cbManufacturingPage7 (4).
| Privilege | Kind | Status | What it grants |
|---|---|---|---|
| CONFIG SCSI-SPI Port 0 READ | recon | lab-proven | DMA of the VM-process heap pointer pManufacturingPage7 and its size into guest RAM. ASLR input. |
| CONFIG SCSI-SPI Port 0 WRITE | integrity | lab-proven | plant guest-chosen pointer + size over those SAS fields |
| manufacturing page 7 CONFIG READ | integrity | lab-proven | copy host bytes from the planted address into guest GPA (VBOX-LSILOGIC-SAS-CONFIG-WITNESS) |
| manufacturing page 7 CONFIG WRITE | integrity | inferred from the same getter | copy guest bytes to the planted address (arb write in VirtualBoxVM) |
| Port 1 / Device 0 SPI pages | recon / integrity | inferred overlay | Port 1 leaks/plants pSASIOUnitPage0; Device 0 page 0 hits paPHYs; Device 0 page 1 hits pSASDeviceHead |
| wild planted pointer | availability | inferred | crash the VM process on the next SAS page access or on lsilogicR3ConfigurationPagesFree |
Closed adjacent:
SpiPages is the real layout; this type-confusion needs SAS1068)VERR_NOT_FOUND)This is VM-process arb R/W, not host-kernel escape. Full host-user still needs a hardening leftover. I did not pair it with a remaining 3D write: VMSVGA DX11 UAF (d691aa68) is closed on this pin.
No Guest Additions. No 3D. No VRDP. Not PUEL. Hostile guest ring3 is enough; the in-box mpt/mptsas driver is not required.
I sat on OSS 7.2.20 after the Sep 2026 CPU and walked LsiLogic MPT CONFIG. The silent 2026 reply-stack leak is already closed: 122c6880 RT_ZEROs MptReplyUnion on SCSI I/O error. I was looking for a leftover of that class, not that sink.
The leftover is a union, not a stack reply:
union {
MptConfigurationPagesSpi SpiPages;
MptConfigurationPagesSas SasPages;
} u; /* DevLsiLogicSCSI.h:3323 */
SAS alloc fills SasPages host pointers and never runs SPI page init. The SPI Port getter at DevLsiLogicSCSI.cpp:2795 has no enmCtrlType check. CONFIG dispatch SPI cases are ungated. The page-attribute getter is commented out at cpp:3159. Manufacturing page 7 at cpp:2701 is SAS-gated, which is the intended path, and dereferences pManufacturingPage7 with no NULL check. That is how a SPI-typed Port 0 READ/WRITE becomes a SAS pointer leak and plant.
Wrong turns already recorded: re-filing 122c6880; treating default LSI53C1030 as this bug; inflating a wild-pointer crash to host-kernel escape; a live VM when the packed overlay is enough. Theatre: a reverse shell. The oracle is CONTROL dummy page data, then leak/plant/arb-read of VBOX-LSILOGIC-SAS-CONFIG-WITNESS.
cd lab
./run.sh
Or python3 vbox-lsilogic-sas-config-Abraxas-Labs.py. Source harness of the pin structs. VirtualBox is not booted. Compose project vbox-lsilogic-sas-config, network_mode: none. Bind nothing.
CONTROL: SPI-typed Port 0 overlay-read is dummy page data, not the manufacturing-page-7 heap pointer.
SAS confused: Port 0 READ leaks pManufacturingPage7 matching calloc. Port 0 WRITE plants a second witness buffer pointer+size. Manufacturing page 7 getter plus CONFIG READ copies the witness into the guest GPA array.
SUCCESS vbox-lsilogic-sas-config leak=yes plant=yes arb-read=yes VBOX-LSILOGIC-SAS-CONFIG-WITNESS
Gate SCSI-SPI page types on enmCtrlType == LSILOGICCTRLTYPE_SCSI_SPI. Restore the page-attribute check so Readonly Port 0 stays read-only. NULL-check pManufacturingPage7 (and the other SAS pointers) before dereference. Stop overlaying SpiPages and SasPages in one union.
