abraxas/vbox-hgcm-ssm-cparmsVirtualBox 7.2.20 - High - Local - Heap overflow - HGCM SSM cParms wrap
abraxaslabs.tech · github.com/abraxas · @abraxas_null · [email protected] · vbox-hgcm-ssm-cparms
Class: Heap overflow Reach: Local (host)
Oracle VM VirtualBox OSS 7.2.20 (f2792cf44) - Oracle
Live HGCM still refuses cParms > 32. Saved-state load does not. vmmdevR3HgcmLoadState reads cParms from the .sav with no VMMDEV_MAX_HGCM_PARMS cap, then sizes the command with uint32_t cbCmd. At cParms = 0x4000000 that product wraps to sizeof(VBOXHGCMCMD) (~120). The first enmType store is already a 4-byte write past the block.
A host user who restores a hostile saved state overflows the VM-process heap. A guest cannot plant this through Save.
| ID | no CVE yet |
| Class | Heap overflow (VM-process OOB write; not host-kernel escape) |
| Reach | Local (host) (UI:R saved-state / snapshot restore) |
| CWE | CWE-190, CWE-787 |
| CVSS | High: 7.8 CVSS:3.1/AV:L/AC:L/PR:N/UI:R/S:U/C:H/I:H/A:H |
| Product | VirtualBox OSS |
| Affected | 7.2.20 (f2792cf44f663989818507e36d3db5f978523c5e) |
| Auth | host user restores a Saved VM, snapshot, or .sav |
| License | GNU Affero GPL v3.0 |
| Lab | 127.0.0.1 only. Source harness. No VirtualBox boot, no .sav parse. |
Hand the operator a VM folder whose saved state carries a pending VMMDev HGCM CALL. They click Start on a Saved VM, restore a snapshot, or adopt the .sav. Console restore walks SSMR3 into vmmdevR3LoadExec into vmmdevR3HgcmLoadState. That is UI:R. The leftover is the parser, not a guest hypercall.
VMMDev is default-on. No 3D. No Guest Additions. No VRDP. Not PUEL.
| Step | Where | What it grants |
|---|---|---|
| Restore | host UI / VBoxManage startvm on a Saved VM | The host user opens the hostile .sav. That is the only required click. |
| SSM unit | VMMDev vmmdevR3HgcmLoadState (VMMDevHGCM.cpp:2043-2091) | SSMGetU32 into cParms with no VMMDEV_MAX_HGCM_PARMS (32) cap. |
| Alloc wrap | vmmdevR3HgcmCmdAlloc (VMMDevHGCM.cpp:376-381) | uint32_t cbCmd = sizeof(VBOXHGCMCMD) + cParms * (40+24). cParms = 0x4000000 wraps to ~120. RTMemAllocZ of that size succeeds against the heap budget. |
| First store | load loop paGuestParms[i].enmType (VMMDevHGCM.cpp:2085-2091) | paGuestParms is pCmd + sizeof(VBOXHGCMCMD), which is already the alloc end after the wrap. The first type dword is a 4-byte OOB write. The stream only needs the CALL header plus one parameter type. It does not need 67 million records. |
| Kind | Provenance | What the attacker gets |
|---|---|---|
| Recon | none | Overflow bytes are sav-chosen. This is not a leak. Heap contents are not returned to the file. |
| Integrity | lab-proven | cParms=0x4000000 wraps uint32_t cbCmd to 120. One i=0 enmType store smashes a 0xA5 canary. canary0=56424f58 is the VBOX prefix of VBOX-HGCM-SSM-CPARMS-WITNESS. Control cParms=2 leaves the canary intact. |
| Integrity | inferred | Further sav-controlled parm records (type dword plus 32/64-bit or pointer-desc fields) write linearly off the ~120-byte RTMemAllocZ in VirtualBoxVM / VBoxHeadless. That is a write primitive in the VM process, same class as QEMU migration memcorr. This pack does not demonstrate instruction-pointer control. |
| Availability | inferred | VBoxVM crash if the smash is not turned into a controlled write. The harness is a canary smash, not a VirtualBox process crash. |
vmmdevR3HgcmCallAlloc still rejects cParms > 32 (VMMDevHGCM.cpp:921-926). A guest cannot plant the wrap through a legitimate Save.VMMDEV_MAX_HGCM_PARMS 32, VMMDEV_MAX_HGCM_DATA_SIZE 128MiB).offValue / cbValue memcpy on complete is a second host-heap write only if HGCM clients restore in the same sav. It is not this lab.Full host-user / host-kernel still needs a hardening leftover. Combining this smash with the public IDispatch bypass is discarded.
I pinned VirtualBox/virtualbox tag v7.2.20 peel f2792cf44. Live HGCM was the first read because CVE-2013-5892 was this class: argument-size wrap into VBOXHGCMCMD. The live path still has the cap:
ASSERT_GUEST_STMT_RETURN( cParms <= (cbHGCMCall - sizeof(VMMDevHGCMCall)) / cbHGCMParmStruct
&& cParms <= VMMDEV_MAX_HGCM_PARMS,
LogRelMax(50, ("VMMDev: request packet with invalid number of HGCM parameters: ...")),
VERR_INVALID_PARAMETER);
Load does not. vmmdevR3HgcmLoadState takes cParms from the sav and calls the same allocator:
const uint32_t cbCmd = sizeof(VBOXHGCMCMD) + cParms * (sizeof(VBOXHGCMGUESTPARM) + sizeof(VBOXHGCMSVCPARM))
+ (enmCmdType == VBOXHGCMCMDTYPE_CONNECT ? sizeof(HGCMServiceLocation) : 0);
AssertCompile comments on this pin put CMD at 120, guestparm at 40, svcparm at 24. cParms = 0x4000000 makes the 64-bit product 0x100000000 + 120. The store to uint32_t keeps 120. Then:
for (i = 0; i < cParms; ++i)
{
VBOXHGCMGUESTPARM * const pGuestParm = &pCmd->u.call.paGuestParms[i];
rc = pHlp->pfnSSMGetU32(pSSM, &u32);
pGuestParm->enmType = (HGCMFunctionParameterType)u32;
paGuestParms sits at pCmd + sizeof(VBOXHGCMCMD). After the wrap that is the alloc end. The first store is already OOB.
Wrong turns already recorded: treating live HGCM as the leftover (it still caps at 32); walking 67 million stores in the harness (the first dword is the proof); claiming a guest can plant this through Save; inflating VM-process heap smash to host-kernel escape; chaining public IDispatch.
Theatre: a reverse shell, a .sav parser, booting VirtualBox. The oracle is wrap plus a canary smash of VBOX-HGCM-SSM-CPARMS-WITNESS.
cd lab
./run.sh
Or from the pack root:
python3 vbox-hgcm-ssm-cparms-Abraxas-Labs.py
Source harness on loopback 127.0.0.1:19210. Compose project vbox-hgcm-ssm-cparms. gadget.c copies the pin sizes, the uint32_t cbCmd formula, the live 32 cap, and one load-path enmType store. It does not boot VirtualBox and it does not parse a .sav. Bind it to loopback.
SUCCESS vbox-hgcm-ssm-cparms wrap=yes oob=yes live-cap=32 canary-smashed=yes VBOX-HGCM-SSM-CPARMS-WITNESS
Cap SSM cParms at VMMDEV_MAX_HGCM_PARMS in vmmdevR3HgcmLoadState (and the pre-v17 cLinAddrs path) the same way vmmdevR3HgcmCallAlloc already does. Size cbCmd in uint64_t / size_t and refuse a wrap. A saved-state integer is not more trusted than a live guest integer.
