Agente SSH que cria e gere chaves seladas por TPM para autenticação vinculada ao hardware, suportando geração de chaves, importação, encapsulamento, proteção por PIN e fallback de proxy.
ssh-tpm-agent é um agente compatível com ssh-agent que permite que chaves sejam criadas
pelo Trusted Platform Module (TPM) para autenticação junto a servidores ssh.
Chaves seladas por TPM são chaves privadas criadas dentro do Trusted Platform Module
(TPM) e seladas em arquivos com sufixo .tpm. Elas são vinculadas ao hardware em que
são produzidas e não podem ser transferidas para outras máquinas.
Isso permite que você utilize um cliente nativo em vez de ter que carregar bibliotecas PKCS11 existentes no ssh-agent e/ou no cliente ssh.
O projeto usa TPM 2.0 Key Files
implementados através do projeto go-tpm-keyfiles.
ssh-agent funcional.ssh-agent como fallback.Em vez de utilizar o TPM diretamente, você pode usar --swtpm ou export SSH_TPM_AGENT_SWTPM=1 para criar uma identidade respaldada por
swtpm que será armazenada em
/var/tmp/ssh-tpm-agent.
Observe que o swtpm não fornece propriedades de segurança e deve ser usado apenas para
testes.
A maneira mais simples de instalar este plugin é executando o seguinte:
go install github.com/foxboron/ssh-tpm-agent/cmd/...@latest
Como alternativa, baixe os binários pré-compilados.
# Create key
$ ssh-tpm-keygen
Generating a sealed public/private ecdsa key pair.
Enter file in which to save the key (/home/fox/.ssh/id_ecdsa):
Enter passphrase (empty for no passphrase):
Enter same passphrase again:
Your identification has been saved in /home/fox/.ssh/id_ecdsa.tpm
Your public key has been saved in /home/fox/.ssh/id_ecdsa.pub
The key fingerprint is:
SHA256:NCMJJ2La+q5tGcngQUQvEOJP3gPH8bMP98wJOEMV564
The key's randomart image is the color of television, tuned to a dead channel.
$ cat /home/fox/.ssh/id_ecdsa.pub
ecdsa-sha2-nistp256 AAAAE2VjZHNhLXNoYTItbmlzdHAyNTYAAAAIbmlzdHAyNTYAAABBBOTOsMXyjTc1wiQSKhRiNhKFsHJNLzLk2r4foXPLQYKR0tuXIBMTQuMmc7OiTgNMvIjMrcb9adgGdT3s+GkNi1g=
# Using the socket
$ ssh-tpm-agent -l /var/tmp/tpm.sock
$ export SSH_AUTH_SOCK="$(ssh-tpm-agent --print-socket)"
$ ssh [email protected]
Nota: Para ssh-tpm-agent, você pode especificar a senha do proprietário do TPM usando as flags de linha de comando -o ou --owner-password, que são preferíveis. Alternativamente, você pode usar a variável de ambiente SSH_TPM_AGENT_OWNER_PASSWORD.
Útil se você quiser fazer backup da chave em um armazenamento seguro remoto enquanto usa a chave no dia a dia a partir do TPM.
# Create a key, or use an existing one
$ ssh-keygen -t ecdsa -f id_ecdsa
Generating public/private ecdsa key pair.
Enter passphrase (empty for no passphrase):
Enter same passphrase again:
Your identification has been saved in id_ecdsa
Your public key has been saved in id_ecdsa.pub
The key fingerprint is:
SHA256:bDn2EpX6XRX5ADXQSuTq+uUyia/eV3Z6MW+UtxjnXvU fox@framework
The key's randomart image is:
+---[ECDSA 256]---+
| .+=o..|
| o. oo.|
| o... .o|
| . + .. ..|
| S . . o|
| o * . oo=*|
| ..+.oo=+E|
| .++o...o=|
| .++++. .+ |
+----[SHA256]-----+
# Import the key
$ ssh-tpm-keygen --import id_ecdsa
Sealing an existing public/private ecdsa key pair.
Enter passphrase (empty for no passphrase):
Enter same passphrase again:
Your identification has been saved in id_ecdsa.tpm
The key fingerprint is:
SHA256:bDn2EpX6XRX5ADXQSuTq+uUyia/eV3Z6MW+UtxjnXvU
The key's randomart image is the color of television, tuned to a dead channel.
Serviços ativados por socket permitem que você inicie o ssh-tpm-agent quando ele for necessário pelo seu sistema.
# Using the socket
$ ssh-tpm-agent --install-user-units
Installed /home/fox/.config/systemd/user/ssh-tpm-agent.socket
Installed /home/fox/.config/systemd/user/ssh-tpm-agent.service
Enable with: systemctl --user enable --now ssh-tpm-agent.socket
$ systemctl --user enable --now ssh-tpm-agent.socket
$ export SSH_AUTH_SOCK="$(ssh-tpm-agent --print-socket)"
$ ssh [email protected]
# Start the usual ssh-agent
$ eval $(ssh-agent)
# Create a strong RSA key
$ ssh-keygen -t rsa -b 4096 -f id_rsa -C ssh-agent
...
The key fingerprint is:
SHA256:zLSeyU/6NKHGEvyZLA866S1jGqwdwdAxRFff8Z2N1i0 ssh-agent
$ ssh-add id_rsa
Identity added: id_rsa (ssh-agent)
# Print looonnggg key
$ ssh-add -L
ssh-rsa AAAAB3NzaC1yc[...]8TWynQ== ssh-agent
# Create key on the TPM
$ ssh-tpm-keygen -C ssh-tpm-agent
Generating a sealed public/private ecdsa key pair.
Enter file in which to save the key (/home/fox/.ssh/id_ecdsa):
Enter passphrase (empty for no passphrase):
Confirm passphrase:
Your identification has been saved in /home/fox/.ssh/id_ecdsa.tpm
Your public key has been saved in /home/fox/.ssh/id_ecdsa.pub
The key fingerprint is:
SHA256:PoQyuzOpEBLqT+xtP0dnvyBVL6UQTiQeCWN/EXIxPOo
The key's randomart image is the color of television, tuned to a dead channel.
# Start ssh-tpm-agent with a proxy socket
$ ssh-tpm-agent -A "${SSH_AUTH_SOCK}" &
$ export SSH_AUTH_SOCK="$(ssh-tpm-agent --print-socket)"
# ssh-tpm-agent is proxying the keys from ssh-agent
$ ssh-add -L
ssh-rsa AAAAB3NzaC1yc[...]8TWynQ== ssh-agent
ecdsa-sha2-nistp256 AAAAE2VjZHNhLXNo[...]q4whro= ssh-tpm-agent
$ ssh-tpm-agent --no-load &
2023/08/12 13:40:50 Listening on /run/user/1000/ssh-tpm-agent.sock
$ export SSH_AUTH_SOCK="$(ssh-tpm-agent --print-socket)"
$ ssh-add -L
The agent has no identities.
$ ssh-tpm-add $HOME/.ssh/id_ecdsa.tpm
Identity added: /home/user/.ssh/id_ecdsa.tpm
$ ssh-add -L
ecdsa-sha2-nistp256 AAAAE2VjZHNhLXNoYTItbmlzdHAyNTYAAAAIbmlzdHAyNTYAAABBBJCxqisGa9IUNh4Ik3kwihrDouxP7S5Oun2hnzTvFwktszaibJruKLJMxHqVYnNwKD9DegCNwUN1qXCI/UOwaSY= test
No lado do cliente, crie uma chave primária sob uma hierarquia. Este exemplo usará a hierarquia de proprietário com uma SRK.
O arquivo de saída srk.pem precisa ser transferido para o lado remoto, que
cria a chave. Isso pode ser feito como parte do provisionamento do cliente.
$ tpm2_createprimary -C o -G ecc -g sha256 -c prim.ctx -a 'restricted|decrypt|fixedtpm|fixedparent|sensitivedataorigin|userwithauth|noda' -f pem -o srk.pem
No lado remoto, criamos uma chave ssh p256, sem senha, e a envolvemos com
ssh-tpm-keygen usando o srk.pem do lado do cliente.
$ ssh-keygen -t ecdsa -b 256 -N "" -f ./ecdsa.key
# OR with openssl
$ openssl genpkey -algorithm EC -pkeyopt ec_paramgen_curve:prime256v1 -out ecdsa.key
# Wrap with ssh-tpm-keygen
$ ssh-tpm-keygen --wrap-with srk.pub --wrap ecdsa.key -f wrapped_id_ecdsa
No lado do cliente, podemos desembrulhar wrapped_id_ecdsa para uma chave carregável.
$ ssh-tpm-keygen --import ./wrapped_id_ecdsa.tpm -f id_ecdsa.tpm
$ ssh-tpm-add id_ecdsa.tpm
O ssh-tpm-agent também oferece suporte ao armazenamento de chaves de host dentro do TPM.
$ sudo ssh-tpm-keygen -A
2023/09/03 17:03:08 INFO Generating new ECDSA host key
2023/09/03 17:03:08 INFO Wrote /etc/ssh/ssh_tpm_host_ecdsa_key.tpm
2023/09/03 17:03:08 INFO Generating new RSA host key
2023/09/03 17:03:15 INFO Wrote /etc/ssh/ssh_tpm_host_rsa_key.tpm
