MDE/MDI Defender setup for Ludus
Ludus range config and Ansible roles for a Windows security lab pre-staged for MDE and MDI, with a fully misconfigured ADCS installation for detection coverage testing.
| Config | VMs | Purpose |
|---|---|---|
zsec-mde-mdi-lab.yml | DC01 + WKS01 | MDE/MDI detection lab with ADCS ESC1-ESC11 and ESC13-ESC15 |
LUDUS_API_KEY set in your environmentwin2022-server-x64-template# Install roles (run on Ludus host with API key set)
cd roles/
./install-roles.sh
# Set config and deploy
ludus range config set -f zsec-mde-mdi-lab.yml
ludus range deploy
To update roles after pulling a new version of this repo:
cd roles/
./install-roles.sh --update
ludus range deploy --tags user-defined-roles # re-runs roles without VM rebuild
MDE and MDI are not auto-installed. Onboard from security.microsoft.com after the range is up:
svc_mdi for automated response.svc_honey.# Snapshot after onboarding so you can revert without repeating the process
ludus range snapshot create --name post-onboarding
Environment-specific values (domain name, passwords, hostnames) appear inline throughout the config. A reference table at the top of the file lists every value and where it's used - update with find-and-replace before deploying.
Shared MDE prerequisite settings live in global_role_vars (applied to all VMs). DC-specific overrides live in DC01's role_vars and take precedence automatically.
Compound FQDNs in dns_rewrites and SPN strings need updating separately.
All roles live in roles/. The install script handles everything. Role order in the YAML matters - enable_mdi_gpo requires the AD and GroupPolicy PowerShell modules (present on DCs by default, installed by rsat on member servers).
| Role | Used in | Purpose |
|---|---|---|
mde_prereqs | DC01, WKS01 | Defender config, audit policy, logging, LSA hardening, TLS 1.2 |
wef | DC01, WKS01 | Windows Event Forwarding (collector on DC01, forwarder on WKS01) |
sysmon | DC01, WKS01 | Sysmon install and config |
adcs_lab | DC01 | ADCS ESC1-ESC11 and ESC13-ESC15 misconfiguration setup |
ad_population | DC01 | Users, groups, OUs, Kerberoastable/ASREPRoastable accounts |
smb_shares | DC01, WKS01 | SMB shares including honeypot share |
enable_mdi_gpo | DC01 | MDI audit GPO via DefenderForIdentity module |
enable_asr | WKS01 | Attack Surface Reduction rules |
rsat | WKS01 | Remote Server Administration Tools |
pivot_tools | Kali (optional) | Chisel, Ligolo-ng, proxychains for pivoting |
Community role installed via Ansible Galaxy: badsectorlabs.ludus_adcs (DC01).
Default credentials for the zsec.local domain. Update these in zsec-mde-mdi-lab.yml before deploying.
| Account | Password | Purpose |
|---|---|---|
domainadmin | D0main@dmin2026 | Domain admin |
domainuser | Summer2026! | Standard domain user |
jsmith | Summer2026! | IT-Admins member, ADCS test user |
svc_backup | SvcBackup2026! | Kerberoastable (SPN: backup/DC01.zsec.local) |
svc_sql | SqlService2026! | Kerberoastable (SPN: MSSQLSvc/DC01.zsec.local:1433) |
svc_legacy | Legacy2026! | AS-REP roastable (pre-auth disabled) |
svc_deploy | D3pl0y@utomation! | Backup-Operators member |
svc_mdi | MdiSensor2026!@ | MDI action account (configure in portal) |
svc_honey | H0neyP0t2026!@ | Honeytoken (tag in portal) |
Planted credentials are also seeded in SMB shares (C:\Shares\IT\, C:\Shares\Backups\) for discovery scenarios.
What's collecting what after deployment:
| Layer | Coverage | Config |
|---|---|---|
| Sysmon | Process, network, registry, file, DNS, named pipe, LSASS access, WMI | Both hosts |
| WEF | Security/System/Sysmon/PS/Defender/WMI/BITS/RDP/NTLM/CAPI2 forwarded to DC01 | DC01 collector, WKS01 forwarder |
| Advanced Audit | 23+ subcategories incl. DS Access, Kerberos, Credential Validation, Process Creation | Both hosts (DC gets extras) |
| MDI GPO | Domain object SACLs, NTLM auditing, advanced audit for DCs | DC01 only |
| PowerShell | Script Block (4104), Module (4103), Transcription to C:\PSTranscripts | Both hosts |
| DC-specific | Kerberos (4768-4771), NTLM (8004), LDAP diag (1644), DNS query logging, ADCS CA audit | DC01 only |
| Firewall | Blocked connection logging on all profiles (32 MB per profile) | Both hosts |
| ASR | 17 Attack Surface Reduction rules in Enabled mode | WKS01 only |
Quick post-deploy sanity checks (run on DC01 unless noted):
# Sysmon running
Get-Service Sysmon64
# WEF subscriptions (collector)
wecutil es
wecutil gs ZSec-MDI-Events
wecutil gr ZSec-MDI-Events # WKS01 should be listed as an active source
# Audit policy
auditpol /get /category:* | Select-String "Success and Failure"
# MDI GPO applied
Get-GPO -All | Where-Object { $_.DisplayName -like 'MDI*' }
# Defender health
Get-MpComputerStatus | Select AntivirusEnabled, RealTimeProtectionEnabled, AMRunningMode
# Event log sizes
wevtutil gl Security | Select-String maxSize
wevtutil gl "Microsoft-Windows-Sysmon/Operational" | Select-String maxSize
# PowerShell logging
Get-ItemProperty 'HKLM:\SOFTWARE\Policies\Microsoft\Windows\PowerShell\ScriptBlockLogging'
# NTLM auditing (DC only)
Get-ItemProperty 'HKLM:\SYSTEM\CurrentControlSet\Control\Lsa\MSV1_0' | Select RestrictSendingNTLMTraffic, AuditReceivingNTLMTraffic
Get-ItemProperty 'HKLM:\SYSTEM\CurrentControlSet\Services\Netlogon\Parameters' | Select AuditNTLMInDomain
# MDI v3 sensor status (after onboarding)
Get-Service SenseIdentity, Sense | Format-Table Name, Status, StartType
enable_asr and enable_mdi_gpo are derived from @curi0usJack's work at curi0usJack/Ludus-MDE-MDI-Roles. This repo extends those roles into a unified DC<->WKS setup and adds the ADCS misconfiguration layer, MDE prerequisites hardening, WEF pipeline, and additional roles.
AD CS lab is a snippet from my course
