memory-forensic

A memory forensics toolkit that profiles Windows kernels itself — and is cross-checked, process-for-process, against Volatility 3.

mem4n6 reads every common dump format (LiME, AVML, ELF core, Windows crash dumps, hibernation files, VMware save-states, kdump, raw…) and walks processes, threads, modules, network connections, and injected memory — from one static binary you compile once and copy anywhere, with no Python, no runtime, no pre-staged symbol catalog. On Windows it builds its own profile: locate ntoskrnl in physical memory, read its PDB GUID from the CodeView record, resolve the matching Volatility-3 ISF, recover the kernel base under modern KASLR, and reconstruct PsActiveProcessHead from the symbol table — the same self-profiling chain Volatility 3 and MemProcFS use, reimplemented in Rust.

Because the bar for an evidence tool is correctness, the process walker is cross-checked against an independent reference implementation — Volatility 3 — on a real 2 GB Windows 10 image (a reference agreeing is strong evidence, not proof; the raw bytes are the ground truth):

windows.pslist on DESKTOP-SDN1RPT.mem	mem4n6 vs Volatility 3
Processes matched	94 / 94 shared PIDs — exact PID, PPID, name, create-time
Missed (vol3 found, mem4n6 did not)	0
False positives (mem4n6 found, vol3 did not)	0

mem4n6 matches Volatility 3 exactly — including recovering 11 processes orphaned by a live-acquisition smear via a bidirectional ActiveProcessLinks walk. A second independent oracle (MemProcFS) confirms a clean subset — its 77-process process_list is fully contained in mem4n6's set, with zero MemProcFS-only processes (details). See docs/validation.md for the full differential and reproduction steps.

Quick start

Install with cargo install mem4n6, or grab a prebuilt static binary from the latest release — the Linux builds are static-PIE (musl: copy-anywhere, no glibc), with macOS, Windows, and a SHA-256 checksums.txt alongside.

Or build from source (~one command):

git clone https://github.com/SecurityRonin/memory-forensic.git
cd memory-forensic && cargo build --release
./target/release/mem4n6 --help

That dev build links libc dynamically; to reproduce the release's fully static binary locally, add the musl target: rustup target add x86_64-unknown-linux-musl && cargo build --release --target x86_64-unknown-linux-musl.

# Inspect any dump — format, ranges, embedded metadata (no symbols needed)
mem4n6 info win10.mem

# Windows process tree. The ISF is resolved from the kernel's own PDB GUID;
# raw .mem dumps take the page-table base via --cr3 (crash dumps carry their own).
mem4n6 ps --symbols ntkrnlmp.json --cr3 0x1ad000 --tree win10.mem

# Linux process tree from a LiME capture
mem4n6 ps --symbols linux.json --tree memdump.lime

# Air-gapped lab? Never touch the network for symbols:
mem4n6 ps --symbols ntkrnlmp.json --offline win10.mem

Symbol files are ISF JSON — the same packs Volatility 3 uses, so an existing symbol cache works as-is.

---

Why mem4n6

	mem4n6	Volatility 3	MemProcFS	MemNixFS
Deploy	Rust · single static binary	Python · interpreter + deps	C(+Rust) · libraries	C++ · filesystem mount
Windows self-profiling (scan → PDB GUID → symbols)	✅	✅	✅	n/a — Linux dumps
Header-less DTB via the boot low stub + page-granular kernel base	✅	self-ref PML4 + image scan	✅ low stub	n/a — Linux
Offline / air-gapped symbol mode	✅ --offline	ISF pack or network	symbols / network	✅ BTF-from-dump
Panic-free on untrusted dumps (unsafe-deny; unwrap/expect denied on parsing paths)	✅	—	—	— (C++)
Cross-checked against Volatility 3	✅ (docs/validation.md)	— (the reference)	—	—

mem4n6 is, to our knowledge, the only Rust implementation of the full dump → kernel-scan → PDB-GUID → symbol-resolution → DTB chain. The technique lineage — WinDbg's symbol server, Brendan Dolan-Gavitt's pdbparse, Rekall, Volatility 3, and Ulf Frisk's MemProcFS — is well established; mem4n6 reimplements it clean-room and validates the result against the reference. MemNixFS brings that same memory-as-a-filesystem idea to Linux dumps — mount-and-browse, with symbols derived from the kernel's own BTF when no ISF exists; the n/a cells above mark a difference in scope (Linux images and a filesystem UX, vs mem4n6's Windows-validated CLI walker), not a gap. The boot low-stub / PROCESSOR_START_BLOCK anchor follows Alex Ionescu's REcon 2017 Getting Physical.

---

Install

git clone https://github.com/SecurityRonin/memory-forensic.git
cd memory-forensic
cargo build --release
./target/release/mem4n6 --help

---

Quick Reference

# Show dump format and physical memory ranges
mem4n6 info memdump.dmp

# Process tree with threads and DLLs
mem4n6 ps --symbols ntkrnlmp.json --tree --threads --dlls memdump.dmp

# Network connections (json / csv / table)
mem4n6 net --symbols ntkrnlmp.json --output json memdump.dmp

# Kernel integrity checks (SSDT, IDT, callbacks, hooks)
mem4n6 check --symbols ntkrnlmp.json --ssdt --callbacks memdump.dmp

# Linux syscall hook and malfind scan
mem4n6 check --symbols linux.json --hooks --malfind memdump.lime

# String extraction with YARA rules
mem4n6 strings --rules ./yara-rules/ --min-length 8 memdump.dmp

# Hash lookup against NSRL (known-good) and MalwareBazaar (known-bad)
mem4n6 hash --lookup memdump.dmp

# Extract framebuffer screenshot from live memory dump
mem4n6 framebuf --symbols linux.json --png screen.png memdump.dmp

# Recover files from tmpfs mounts + detect memfd fileless ELF execution
mem4n6 check --symbols linux.json --tmpfs-recovery --memfd memdump.lime

# Detect EDR bypass: direct syscalls, ETW patching, AMSI/DSE bypass
mem4n6 check --symbols ntkrnlmp.json --direct-syscalls --etw-patch --amsi-bypass memdump.dmp

# Novel kernel interface abuse: io_uring, netfilter hooks, perf_event
mem4n6 check --symbols linux.json --io-uring --netfilter --perf-event memdump.lime

# Cross-artifact ATT&CK correlation across all walkers
mem4n6 correlate --symbols ntkrnlmp.json --output json memdump.dmp

Symbol files are ISF JSON, compatible with Volatility 3 symbol packs.

---

Verify kernel integrity — hooks invisible from the OS

# SSDT, IDT, ftrace, LSM, and kernel callback checks in one pass
mem4n6 check --symbols linux.json --hooks --idt --syscalls memdump.lime
