安装 opam 以构建测试 API。
安装 cargo 以构建 Gaia。
安装 docker v26.0.1 和 docker compose v2.26.1 以使用 ELK Stack 构建 Gaia(如果不使用则为可选)。
要创建一个 opam 本地切换:
make opam-switch
make deps
make build
make build-test
make generate-swagger
make clean-swagger
make format
make clean-build-files
make clean
./_bin/gaia --help
gaia --configuration <configuration> --openapi-path <openapi-path> --workdir-path <workdir-path> --verbose <verbose>
workdir-path:工作目录,您可以在其中找到模糊测试工具的各种日志。
openapi-path:实际 API 的 OpenAPI 文件的路径。使用模糊测试或监控时为必需,统计时不需要
verbose:详细程度级别 {NOTHING, LOW, MID, HIGH, ALL}(默认值:NOTHING)
configuration:包含以下内容的 JSON 文件路径:
{
"configuration": {
// One of : fuzzing or monitoring
"fuzzing": {
//Required
"config_fuzzer": {
//Required
// In hours
"timeout": 1,
//Optional
// Disable fuzzers
"disable_fuzzers": [{
"Restler":{
// Bfs, BfsFast, BfsCheap or RandomWalk
"strategy" : "Bfs"
}
},
"Schemathesis",
{"Custom": {"id": "1"}}
],
//Optional
"custom_fuzzers": [
"<command line that can accept `--output_dir <PATH>`, `--openapi_path <PATH>` and `--timeout <FLOAT>` as arguments>"
],
//Optional
"generation_config": {
//optional (Required if you set a function to generate a value)
"lib_path": "Absolute path to the dynamic library (.so, .dll, or .rs).",
//Optional
"generate_string": {
//One of : Command, Value, File path or Function
"command": "<command line that returns a string array>",
//Or
"value": ["fuzzstring"],
//Or
"function": "<function() that returns a string array>",
//Or
"file": "The file path to the dictionary of values"
},
//Optional
"generate_datetime": {
//One of : Command, Value, File path or Function
"command": "<command line that returns a datetime array in a string format>",
//Or
"value": ["2019-06-26T20:20:39+00:00"],
//Or
"function": "<function() that returns a datetime array in a string format>",
//Or
"file": "The file path to the dictionary of values"
},
//Optional
"generate_date": {
//One of : Command, Value, File path or Function
"command": "<command line that returns a date array in a string format>",
//Or
"value": ["2019-06-26"],
//Or
"function": "<function() that returns a date array in a string format>",
//Or
"file": "The file path to the dictionary of values"
},
//Optional
"generate_int": {
//One of : Command, Value, File path or Function
"command": "<command line that returns an int array in a string format>",
//Or
"value": ["0"],
//Or
"function": "<function() that returns an int array in a string format>",
//Or
"file": "The file path to the dictionary of values"
},
//Optional
"generate_number": {
//One of : Command, Value, File path or Function
"command": "<command line that returns a float array in a string format>",
//Or
"value": ["1.5"],
//Or
"function": "<function() that returns a float array in a string format>",
//Or
"file": "The file path to the dictionary of values"
},
//Optional
"generate_object": {
//One of : Command, Value, File path or Function
"command": "<command line that returns a json object array in a string format>",
//Or
"value": ["{\"k\" : {\"v\" : \"value\" }}"],
//Or
"function": "<function() that returns a json object array in a string format>",
//Or
"file": "The file path to the dictionary of values"
},
//Optional
"generate_path_parameter": {
//One of : Command, Value, File path or Function
"command": "<command line that returns a key-value map with a string key referring to a path parameter and a string array of values>",
//Or
"value": {
"k": {
"v": ["value"]
}
},
//Or
"function": "<function() that returns a key-value map with a string key referring to a path parameter and a string array of values>",
//Or
"file": "The file path to the dictionary of values"
},
//Optional
"generate_query_parameter": {
//One of : Command, Value, File path or Function
"command": "<command line that returns a key-value map with a string key referring to a query parameter and a string array of values>",
//Or
"value": {
"k": {
"v": ["value"]
}
},
//Or
"function": "<function() that returns a key-value map with a string key referring to a query parameter and a string array of values>",
//Or
"file": "The file path to the dictionary of values"
}
}
},
//Required
"config_process_manager": {
//Optional
"config_reset": {
//Required
"reset_lib": "Absolute path to the dynamic library (.so, .dll, or .rs).",
//Required
"function": "Function name that takes two strings as arguments and returns a unit. The first string represents the log in JSON format, and the second represents the path to the real-time log file."
},
//Required
"config_proxy": {
//Optional
"headers_config": {
//Optional
"custom_headers": [
{
//Required
"title": "title",
//Required
"header_type": {
//One of : Command or Value
"Command": {
//Required
"cmd": "<Command that returns the value of the header>",
//Required
//Refresh value in milliseconds
"duration": 0
},
// or
"Value": { "value": "Header value" }
}
}
]
},
//Optional
"openapi_config": {
//Optional
"responses_to_string": true, // Change the type of the responses to string
//Optional
"requests_config": {
//One of : Exclude or Only
"only": {
//Required
"requests": [
{
//Required
"path": "Regex that represents a path",
//Required
"methods": [
"Get",
"Put",
"Post",
"Delete",
"Options",
"Head",
"Patch",
"Trace"
]
}
]
},
//Or
"Exclude": {
//Required
"requests": [
{
//Required
"path": "Regex that represents a path",
//Optional: Defaults to all methods if not specified.
"methods": [
"Get",
"Put",
"Post",
"Delete",
"Options",
"Head",
"Patch",
"Trace"
]
}
]
}
}
},
//Optional
"stream_response_services": [
{
//Required
"path": "Regex that represents a path",
//Optional: Defaults to all methods if not specified.
"methods": [
"Get",
"Put",
"Post",
"Delete",
"Options",
"Head",
"Patch",
"Trace"
]
}
]
},
//Optional
"use_sync_requests" : true
}
},
"monitoring": {
"config_monitoring": {
//One of : log_file_path or service
"log_file_path": {
//Required
"path": "/home/log.log"
},
"service": {
//Required
"url": "http://localhost:3000/log"
}
}
}
},
//Optional
"config_checker": {
//Optional
"checkers_cmd": [
"<command line that take a string as an argument and return unit. This string represents the log in JSON format>"
],
//Optional
"checkers_lib": [
{
//Required
"checkers_lib": "Absolute path to the dynamic library (.so, .dll, or .rs).",
//Required
"function_names": [
"Function names that take a string as an argument and return unit. This string represents the log in JSON format"
]
}
]
},
//Optional
"config_checker_elk_stack": {
//Required
"kibana_port": 5602 //Kibana url : http://localhost:{kibana_port}
},
//Optional
"config_statistics": {
//Required
"process": {
//One of : docker, process or service
"docker": {
//Required
"container_id": "89u32eew2r"
},
"process": {
//Required
"pid": 1100293
},
"service": {
//Required
"url": "http://localhost:3000/statistics"
}
}
},
//Optional
"scanner": true
}
{
"id" : 9009,
"request": {
"method": "GET",
"url": "http://localhost:8080/api/data",
"headers": [
["connection", "keep-alive"],
["accept", "*/*"],
["user-agent", "schemathesis/3.24.3"],
["host", "localhost:8081"],
["accept-encoding", "gzip, deflate"],
["authorization", "Bearer"],
["x-schemathesis-testcaseid", "97pK1I"],
["authorization", "Bearer Test"]
],
"params": [],
"body": "",
"timestamp": "2024-06-17T12:43:21.717+00:00"
},
"response": {
"status_code": 403,
"headers": [
["access-control-allow-headers", "accept, content-type"],
["access-control-allow-origin", "*"],
["content-type", "application/json"],
["content-length", "70"]
],
"body": "{\"error\":\"get_data\",\"exception\":\"sender Test should be connected\"}",
"timestamp": "2024-06-17T12:43:21.717+00:00"
},
"reset": false
}
{
"request": {
"method": "POST",
"url": "http://localhost:20000/injection/block",
"headers": [
["user-agent", "restler/9.2.3"],
["content-type", "application/json"],
["accept", "application/json"],
["x-restler-sequence-id", "20f34e2b-13e8-4861-a7aa-77df3dff5ad6"],
["host", "localhost:22333"],
["content-length", "225"]
],
"params": [
["async", "fuzzstring"],
["force", "fuzzstring"],
["chain", "fuzzstring"]
],
"body": {
"data": "fuzzstring",
"operations": [[{ "branch": { "fuzz": false }, "data": "fuzzstring" }]]
},
"timestamp": "2024-06-17T12:43:21.717+00:00"
},
"response": {
"status_code": 400,
"headers": [
["content-type", "text/plain"],
["transfer-encoding", "chunked"]
],
"body": null,
"timestamp": "2024-06-17T12:43:21.722+00:00"
},
"reset": false
}
