Gaia：全局 API 完整性评估器

依赖项

• 安装 opam 以构建测试 API。

• 安装 git、python3、pip 和 .NET 以构建 RESTler 和 Schemathesis。

• 安装 cargo 以构建 Gaia。

• 安装 docker v26.0.1 和 docker compose v2.26.1 以使用 ELK Stack 构建 Gaia（如果不使用则为可选）。

• 安装 node >= v18.0.0 和 npm >= v8.6.0

• 要创建一个 opam 本地切换：

make opam-switch

• 要安装所有依赖项：

make deps

构建

• 要构建 Gaia：

make build

• 要构建测试 API：

make build-test

OpenAPI 规范

• 要为测试生成 OpenAPI 规范：

make generate-swagger

• 要删除测试的 OpenAPI 规范：

make clean-swagger

格式化

• 要格式化项目（测试 + 源代码）：

make format

清理

• 要清理构建文件（测试 + 源代码）：

make clean-build-files

• 要清理所有内容：

make clean

执行

• 构建后，可以通过以下命令显示 GAIA 选项：

./_bin/gaia --help

• GAIA 用法：

gaia --configuration <configuration> --openapi-path <openapi-path> --workdir-path <workdir-path> --verbose <verbose>

• workdir-path：工作目录，您可以在其中找到模糊测试工具的各种日志。

• openapi-path：实际 API 的 OpenAPI 文件的路径。使用模糊测试或监控时为必需，统计时不需要

• verbose：详细程度级别 {NOTHING, LOW, MID, HIGH, ALL}（默认值：NOTHING）

• configuration：包含以下内容的 JSON 文件路径：

{
  "configuration": {
    // One of : fuzzing or monitoring
    "fuzzing": {
      //Required
      "config_fuzzer": {
        //Required
        // In hours
        "timeout": 1,
        //Optional
        // Disable fuzzers
        "disable_fuzzers": [{
           "Restler":{
             // Bfs, BfsFast, BfsCheap or RandomWalk
             "strategy" : "Bfs"
            }
          },
          "Schemathesis",
          {"Custom": {"id": "1"}}
        ],
        //Optional
        "custom_fuzzers": [
          "<command line that can accept `--output_dir <PATH>`, `--openapi_path <PATH>` and `--timeout <FLOAT>` as arguments>"
        ],
        //Optional
        "generation_config": {
          //optional (Required if you set a function to generate a value)
          "lib_path": "Absolute path to the dynamic library (.so, .dll, or .rs).",
          //Optional
          "generate_string": {
            //One of : Command, Value, File path or Function
            "command": "<command line that returns a string array>",
            //Or
            "value": ["fuzzstring"],
            //Or
            "function": "<function() that returns a string array>",
            //Or
            "file": "The file path to the dictionary of values"
          },
          //Optional
          "generate_datetime": {
            //One of : Command, Value, File path or Function
            "command": "<command line that returns a datetime array in a string format>",
            //Or
            "value": ["2019-06-26T20:20:39+00:00"],
            //Or
            "function": "<function() that returns a datetime array in a string format>",
            //Or
            "file": "The file path to the dictionary of values"
          },
          //Optional
          "generate_date": {
            //One of : Command, Value, File path or Function
            "command": "<command line that returns a date array in a string format>",
            //Or
            "value": ["2019-06-26"],
            //Or
            "function": "<function() that returns a date array in a string format>",
            //Or
            "file": "The file path to the dictionary of values"
          },
          //Optional
          "generate_int": {
            //One of : Command, Value, File path or Function
            "command": "<command line that returns an int array in a string format>",
            //Or
            "value": ["0"],
            //Or
            "function": "<function() that returns an int array in a string format>",
            //Or
            "file": "The file path to the dictionary of values"
          },
          //Optional
          "generate_number": {
            //One of : Command, Value, File path or Function
            "command": "<command line that returns a float array in a string format>",
            //Or
            "value": ["1.5"],
            //Or
            "function": "<function() that returns a float array in a string format>",
            //Or
            "file": "The file path to the dictionary of values"
          },
          //Optional
          "generate_object": {
            //One of : Command, Value, File path or Function
            "command": "<command line that returns a json object array in a string format>",
            //Or
            "value": ["{\"k\" : {\"v\" : \"value\" }}"],
            //Or
            "function": "<function() that returns a json object array in a string format>",
            //Or
            "file": "The file path to the dictionary of values"
          },
          //Optional
          "generate_path_parameter": {
            //One of : Command, Value, File path or Function
            "command": "<command line that returns a key-value map with a string key referring to a path parameter and a string array of values>",
            //Or
            "value": {
              "k": {
                "v": ["value"]
              }
            },
            //Or
            "function": "<function() that returns a key-value map with a string key referring to a path parameter and a string array of values>",
            //Or
            "file": "The file path to the dictionary of values"
          },
          //Optional
          "generate_query_parameter": {
            //One of : Command, Value, File path or Function
            "command": "<command line that returns a key-value map with a string key referring to a query parameter and a string array of values>",
            //Or
            "value": {
              "k": {
                "v": ["value"]
              }
            },
            //Or
            "function": "<function() that returns a key-value map with a string key referring to a query parameter and a string array of values>",
            //Or
            "file": "The file path to the dictionary of values"
          }
        }
      },
      //Required
      "config_process_manager": {
        //Optional
        "config_reset": {
          //Required
          "reset_lib": "Absolute path to the dynamic library (.so, .dll, or .rs).",
          //Required
          "function": "Function name that takes two strings as arguments and returns a unit. The first string represents the log in JSON format, and the second represents the path to the real-time log file."
        },
        //Required
        "config_proxy": {
          //Optional
          "headers_config": {
            //Optional
            "custom_headers": [
              {
                //Required
                "title": "title",
                //Required
                "header_type": {
                  //One of : Command or Value
                  "Command": {
                    //Required
                    "cmd": "<Command that returns the value of the header>",
                    //Required
                    //Refresh value in milliseconds
                    "duration": 0
                  },
                  // or
                  "Value": { "value": "Header value" }
                }
              }
            ]
          },
          //Optional
          "openapi_config": {
            //Optional
            "responses_to_string": true, // Change the type of the responses to string
            //Optional
            "requests_config": {
              //One of : Exclude or Only
              "only": {
                //Required
                "requests": [
