daem0nc0re/atomicsyscallStrumenti e PoC per l'analisi delle syscall di Windows.
Strumenti e PoC per l'analisi delle syscall di Windows.
Questa directory riguarda la tecnica Heaven's Gate. Vedi README.md
Questo strumento serve per eseguire il dump delle syscall di Windows da ntdll.dll o win32u.dll:```
C:\Tools>SyscallDumper.exe -h
SyscallDumper - Tool to dump syscall.
Usage: SyscallDumper.exe [Options] [INPUT_DLL_1] [INPUT_DLL_2]
-h, --help : Displays this help message.
-d, --dump : Flag to dump syscall from ntdll.dll or win32u.dll.
-D, --diff : Flag to take diff between 2 dlls.
-f, --format : Specifies output format. "c" for C/C++, "cs" for CSharp, "py" for Python.
-n, --number : Specifies syscall number to lookup in decimal or hex format.
-o, --output : Specifies output file (e.g. "-o result.txt").
-s, --search : Specifies search filter (e.g. "-s createfile").
INPUT_DLL_1 : Specifies path of ntdll.dll or win32u.dll. Older one in diffing.
INPUT_DLL_2 : Specifies path of ntdll.dll or win32u.dll. Newer one in diffing.
Per estrarre i numeri di syscall da ntdll.dll o win32u.dll, usa l'opzione `-d` (`--dump`). Se non specifichi la DLL di origine, questo strumento estrae i numeri di syscall da `C:\Windows\System32\ntdll.dll` e `C:\Windows\System32\win32u.dll`:```
C:\Tools>SyscallDumper.exe -d
[*] No target is specified.
[>] Dumping from system default ntdll.dll and win32u.dll.
[>] Loading C:\Windows\System32\ntdll.dll.
[+] C:\Windows\System32\ntdll.dll is loaded successfully.
[*] Architecture : AMD64
[*] Image Name : ntdll.dll
[+] Got 463 syscall(s).
[>] Loading C:\Windows\System32\win32u.dll.
[+] C:\Windows\System32\win32u.dll is loaded successfully.
[*] Architecture : AMD64
[*] Image Name : win32u.dll
[+] Got 1258 syscall(s).
[Syscall Table from C:\Windows\System32\ntdll.dll]
---------------------------------------------------------------------------------
| Syscall Name | Number | Number (hex) |
---------------------------------------------------------------------------------
| NtAcceptConnectPort | 2 | 0x0002 |
| NtAccessCheck | 0 | 0x0000 |
--snip--
| NtWriteVirtualMemory | 58 | 0x003A |
| NtYieldExecution | 70 | 0x0046 |
---------------------------------------------------------------------------------
[*] Found 463 syscall(s).
[Syscall Table from C:\Windows\System32\win32u.dll]
-----------------------------------------------------------------------------------
| Syscall Name | Number | Number (hex) |
-----------------------------------------------------------------------------------
| NtBindCompositionSurface | 4373 | 0x1115 |
| NtCloseCompositionInputSink | 4374 | 0x1116 |
--snip--
| NtValidateCompositionSurfaceHandle | 5350 | 0x14E6 |
| NtVisualCaptureBits | 5351 | 0x14E7 |
-----------------------------------------------------------------------------------
[*] Found 1258 syscall(s).
If vuoi filtrare il nome della syscall dal risultato del dump, usa l'opzione -s (--search).
E puoi salvare il risultato in un file con l'opzione -o (--output) come segue:```
C:\Tools>SyscallDumper.exe -d C:\SyscallSamples\1809x64\ntdll.dll -s token -o result.txt
[>] Loading C:\SyscallSamples\1809x64\ntdll.dll. [+] C:\SyscallSamples\1809x64\ntdll.dll is loaded successfully. [] Architecture : AMD64 [] Image Name : ntdll.dll [+] Got 462 syscall(s). [>] Trying to save results. [*] Output File Path : c:\Tools\result.txt [+] Results are saved successfully.
c:\Tools>type result.txt [Syscall Table from C:\SyscallSamples\1809x64\ntdll.dll]
[] Found 18 syscall(s). [] Filter String : "token"
Usando l'opzione `-n` (`--number`), puoi cercare il nome della syscall tramite il numero di syscall come segue.
Se desideri specificare il numero di syscall in formato esadecimale, deve iniziare con "0x".```
C:\Tools>SyscallDumper.exe -d C:\dev\SyscallSamples\21H1x64\ntdll.dll -n 85
[>] Loading C:\dev\SyscallSamples\21H1x64\ntdll.dll.
[+] C:\dev\SyscallSamples\21H1x64\ntdll.dll is loaded successfully.
[*] Architecture : AMD64
[*] Image Name : ntdll.dll
[+] Got 470 syscall(s).
[Syscall Table from C:\dev\SyscallSamples\21H1x64\ntdll.dll]
----------------------------------------
| Syscall Name | Number | Number (hex) |
----------------------------------------
| NtCreateFile | 85 | 0x0055 |
----------------------------------------
[*] Found 1 syscall(s).
C:\Tools>SyscallDumper.exe -d C:\dev\SyscallSamples\21H1x64\ntdll.dll -n 0x55
[>] Loading C:\dev\SyscallSamples\21H1x64\ntdll.dll.
[+] C:\dev\SyscallSamples\21H1x64\ntdll.dll is loaded successfully.
[*] Architecture : AMD64
[*] Image Name : ntdll.dll
[+] Got 470 syscall(s).
[Syscall Table from C:\dev\SyscallSamples\21H1x64\ntdll.dll]
----------------------------------------
| Syscall Name | Number | Number (hex) |
----------------------------------------
| NtCreateFile | 85 | 0x0055 |
----------------------------------------
[*] Found 1 syscall(s).
If you want to change output format, use -f (--format) option.
Currently, C/C++ (c), CSharp (cs) and Python (py) are supported:```
C:\Tools>SyscallDumper.exe -d C:\dev\SyscallSamples\Win11Arm64\ntdll-arm64.dll -f c
[>] Loading C:\dev\SyscallSamples\Win11Arm64\ntdll-arm64.dll. [+] C:\dev\SyscallSamples\Win11Arm64\ntdll-arm64.dll is loaded successfully. [] Architecture : ARM64 [] Image Name : ntdll.dll [+] Got 486 syscall(s).
[Syscall Table from C:\dev\SyscallSamples\Win11Arm64\ntdll-arm64.dll]
enum NT_SYSCALLS { NtAcceptConnectPort = 2, NtAccessCheck = 0, NtAccessCheckAndAuditAlarm = 41,
--snip--
