Cacti is an open-source network monitoring and graphing platform built on RRDtool.
It provides a scalable framework to collect, store, and visualize time-series data from network devices, servers, and applications.
Core capabilities include:

This browser E2E fixture contains four demo devices with response times, traffic measurements, and alert states. It uses the shipped Cacti theme stylesheets. See theme validation for the narrow-screen details screenshot and reproduction commands.

The Dark browser fixture exercises keyboard focus, gradient contrast, and wrapped details titles using synthetic monitoring data. See Dark theme validation for screenshots and tests.

The Deepness fixture checks wrapped titles and readable status messages on dark rows. See Deepness theme validation for the narrow details screenshot and browser tests.


Both Midwinter palettes have browser coverage for details controls and row-state contrast. See Midwinter theme validation for narrow-screen screenshots and reproduction commands.

The Modern fixture checks keyboard focus, wrapped titles, and readable green gradients. See Modern theme validation for the narrow details screenshot and browser tests.

The Paw fixture checks wrapped titles and readable links across row states. See Paw theme validation for the narrow details screenshot and browser tests.

The Raspberry fixture checks wrapped titles and readable links on light and selected rows. See Raspberry theme validation for the narrow details screenshot and browser tests.

The Sunrise fixture checks wrapped titles and readable highlighted options. See Sunrise theme validation for the narrow details screenshot and browser tests.

The Paper Plane fixture checks wrapped titles and readable text on dark, alternating, hovered, and selected rows. See Paper Plane theme validation for screenshots and browser tests.
Cacti maintains two primary branches:
| Branch | Purpose |
|---|---|
1.2.x | Stable long-lived release series |
develop | Active development toward Cacti 1.3.x |
For the latest published version, see GitHub Releases.
Minimum supported dependencies by branch:
| Dependency | Cacti 1.2.x | Cacti develop (1.3.x) |
|---|---|---|
| MariaDB | 10.5+ | 10.11+ |
| MySQL | 8.0+ | 8.4+ |
| PHP | 8.2+ | 8.3+ |
| RRDtool | 1.7+ | 1.8+ |
| Net-SNMP | 5.9+ | 5.9+ |
Notes:
php-snmp is now fully supported. When both php-snmp and the Net-SNMP binaries are available, php-snmp is used by default; to force the Net-SNMP binaries, set $php_snmp_support = false; in include/config.php.Operating system guidance:
1.2.x: RHEL/Rocky/Alma 8+ (or equivalent) is a common baseline.1.3.x: RHEL/Rocky/Alma 9+ or CentOS Stream 9+ is preferred for modern PHP packaging.Clone the repository:
git clone https://github.com/Cacti/cacti.git
cd cacti
Dependency management:
