CVE-2023-20938

English

漏洞分析

  1. client A与client B通过上下文管理器servicemanager建立Binder连接
  2. A创建node 0xbeef(node = binder_new_node(proc, fp);),B通过ref->target_node引用node 0xbeef
  3. B先正确处理target_node 0xbeef,将引用了target_node 0xbeef的事物binder_transaction存入A的事物队列(binder_enqueue_work_ilocked(&t->work, &proc->todo);),使A可以再次引用被释放的悬挂指针
  4. B使用未对其的offsets_size进入错误处理代码(IS_ALIGNED(tr->offsets_size, sizeof(binder_size_t))),导致还是0的buffer_offset被传入binder_transaction_buffer_release函数从而触发漏洞
  5. binder_transaction_buffer_release函数通过binder_dec_node调用binder_dec_node_nilocked函数,减少node 0xbeef的local_strong_refs引用计数器,但是node实例中有多个引用计数器及引用列表,只有当这些计数器都被清0时才会触发释放
  6. 关闭B的binder触发binder_cleanup_ref_olocked函数,此时还会调用binder_dec_node_nilocked,当binder_dec_node_nilocked返回true时,将不会把指向node(0xbeef)的指针ref->node清空
  7. 之后将会调用binder_free_ref,在binder_free_ref函数中会将node 0xbeef释放
  8. A将会在binder_thread_read函数中再次引用被释放的node 0xbeef

额外说明: 真实android环境下普通应用权限无法通过servicemanager注册服务,但可以通过ITokenManager来实现两个进程的链接,本测试用例就是用了ITokenManager

说明

  1. Makefile: make文件,可以修改里面的输出目录
  2. 配置Cuttlefish模拟器
  3. 编译内核环境,我触发漏洞的内核环境版本为:android12-5.10.136_r00,硬件架构使用x86_64
root@kitploit:~
commit ee965fe12def46132d0087a9f353750d717e717c (HEAD -> android12-5.10.136_r00, tag: android12-5.10.136_r00)
Merge: b7247246f637 fb39cdb9eac1
Author: Greg Kroah-Hartman <[email protected]>
Date:   Tue Aug 16 12:45:36 2022 +0200
  1. 在模拟器android中执行aapk,会看到如下kasan崩溃日志:
root@kitploit:~
[   43.177167] ==================================================================
[   43.178189] BUG: KASAN: use-after-free in binder_ioctl+0x48de/0x50b0
[   43.178438] Read of size 8 at addr ffff888116e99d58 by task poc/89
[   43.178646]
[   43.179102] CPU: 0 PID: 89 Comm: poc Not tainted 5.4.219 #1
[   43.179309] Hardware name: QEMU Standard PC (i440FX + PIIX, 1996), BIOS 1.15.0-1 04/01/2014
[   43.179766] Call Trace:
[   43.180332]  dump_stack+0x76/0x9c
[   43.180514]  ? binder_ioctl+0x48de/0x50b0
[   43.180738]  print_address_description.constprop.0+0x16/0x200
[   43.180962]  ? binder_ioctl+0x48de/0x50b0
[   43.181131]  ? binder_ioctl+0x48de/0x50b0
[   43.181303]  __kasan_report.cold+0x1d/0x35
[   43.181464]  ? binder_ioctl+0x48de/0x50b0
[   43.181626]  kasan_report+0x10/0x20
[   43.181761]  binder_ioctl+0x48de/0x50b0
[   43.181966]  ? switch_mm_irqs_off+0x388/0xd80
[   43.182127]  ? __switch_to_asm+0x42/0x80
[   43.182250]  ? binder_thread_write+0x2070/0x2070
[   43.182392]  ? __schedule+0x71b/0x18b0
[   43.182513]  ? io_schedule_timeout+0x150/0x150
[   43.182660]  ? hrtimer_start_range_ns+0x635/0xc10
[   43.182803]  ? wait_woken+0x1c0/0x1c0
[   43.182944]  ? hrtimer_try_to_cancel+0x19/0x3f0
[   43.183092]  ? do_nanosleep+0x246/0x4c0
[   43.183218]  ? schedule_timeout_idle+0x50/0x50
[   43.183363]  ? _raw_spin_unlock_irqrestore+0x36/0x70
[   43.183519]  ? memset+0x20/0x40
[   43.183632]  do_vfs_ioctl+0x91e/0xef0
[   43.183759]  ? selinux_file_ioctl+0x36f/0x510
[   43.183896]  ? ioctl_preallocate+0x1a0/0x1a0
[   43.184034]  ? selinux_bprm_set_creds+0xcb0/0xcb0
[   43.184182]  ? memset+0x20/0x40
[   43.184289]  ? __rseq_handle_notify_resume+0x61d/0xb10
[   43.184458]  ? __x64_sys_rseq+0x4f0/0x4f0
[   43.184600]  ? security_file_ioctl+0x4b/0x90
[   43.184742]  ksys_ioctl+0x59/0x90
[   43.184853]  ? switch_fpu_return+0xc2/0x210
[   43.184987]  __x64_sys_ioctl+0x69/0xa0
[   43.185112]  ? prepare_exit_to_usermode+0x231/0x2c0
[   43.185260]  do_syscall_64+0x87/0x140
[   43.185384]  entry_SYSCALL_64_after_hwframe+0x5c/0xc1
[   43.185665]
[   43.185836] Allocated by task 89:
[   43.186060]  save_stack+0x1b/0x80
[   43.186211]  __kasan_kmalloc.constprop.0+0xc2/0xd0
[   43.186380]  binder_new_node+0x49/0x870
[   43.186519]  binder_transaction+0x4002/0x5d20
[   43.186669]  binder_thread_write+0x454/0x2070
[   43.186816]  binder_ioctl+0xff9/0x50b0
[   43.186950]  do_vfs_ioctl+0x91e/0xef0
[   43.187070]  ksys_ioctl+0x59/0x90
[   43.187177]  __x64_sys_ioctl+0x69/0xa0
[   43.187296]  do_syscall_64+0x87/0x140
[   43.187419]  entry_SYSCALL_64_after_hwframe+0x5c/0xc1
[   43.187628]
[   43.187760] Freed by task 67:
[   43.187921]  save_stack+0x1b/0x80
[   43.188082]  __kasan_slab_free+0x12e/0x170
[   43.188286]  kfree+0x90/0x250
[   43.188485]  binder_deferred_func+0xba6/0x1040
[   43.188777]  process_one_work+0x6fe/0x1250
[   43.188989]  worker_thread+0x534/0x1200
[   43.189156]  kthread+0x314/0x3e0
[   43.189278]  ret_from_fork+0x35/0x40
[   43.189412]
[   43.189509] The buggy address belongs to the object at ffff888116e99d00
[   43.189509]  which belongs to the cache kmalloc-128 of size 128
[   43.190587] The buggy address is located 88 bytes inside of
[   43.190587]  128-byte region [ffff888116e99d00, ffff888116e99d80)
[   43.191116] The buggy address belongs to the page:
[   43.191529] page:ffffea00045ba640 refcount:1 mapcount:0 mapping:ffff88811a801480 index:0x0
[   43.192177] flags: 0x200000000000200(slab)
[   43.192678] raw: 0200000000000200 dead000000000100 dead000000000122 ffff88811a801480
[   43.192969] raw: 0000000000000000 0000000000100010 00000001ffffffff 0000000000000000
[   43.193251] page dumped because: kasan: bad access detected
[   43.193438]
[   43.193518] Memory state around the buggy address:
[   43.193928]  ffff888116e99c00: fb fb fb fb fb fb fb fb fb fb fb fb fb fb fb fb
[   43.194205]  ffff888116e99c80: fc fc fc fc fc fc fc fc fc fc fc fc fc fc fc fc
[   43.194434] >ffff888116e99d00: fb fb fb fb fb fb fb fb fb fb fb fb fb fb fb fb
[   43.194728]                                                     ^
[   43.194976]  ffff888116e99d80: fc fc fc fc fc fc fc fc fc fc fc fc fc fc fc fc
[   43.195291]  ffff888116e99e00: fb fb fb fb fb fb fb fb fb fb fb fb fb fb fb fb
[   43.195653] ==================================================================
[   43.196033] Disabling lock debugging due to kernel taint
[   43.197301] binder: release 89:89 transaction 12 in, still active
[   43.197576] binder: release 89:89 transaction 9 out, still active
[   43.198094] binder: send failed reply for transaction 12, target dead
[   43.198392] binder: send failed reply for transaction 9, target dead

TODO: exploit编写中...
