AgentSmith-HIDS

                            --项目名称灵感来源于电影《黑客帝国》

English | 简体中文

THIS REPO IS OLD

RELEASE VERSION: https://github.com/bytedance/Elkeid

关于AgentSmith-HIDS

AgentSmith-HIDS严格意义上并不是一个“Host-based Intrusion Detection System”，因为目前开源的部分来讲它缺乏了规则引擎和相关检测的能力，但是它可以作为一个高性能“主机信息收集工具”来构建属于你自己的HIDS。 由于AgentSmit-HIDS的特点(从内核态获取尽可能全的数据)，对比用户态的HIDS拥有巨大的优势：

• 性能更优，通过内核态驱动来获取信息，无需诸如遍历/proc这样的行为进行数据补全；传输方案使用共享内存，而不是netlink，相对来说也有更好的性能表现。
• 难以绕过，由于我们的信息获取是来自于内核态驱动，因此面对很多刻意隐藏自己的行为如rootkit难以绕过我们的监控。
• 为联动而生，我们不仅可以作为安全工具，也可以作为监控，或者梳理内部资产。我们通过内核模块对进程/用户/文件/网络连接进行梳理，如果有CMDB的信息，那么联动后你将会得到一张从网络到主机/容器/业务信息的调用/依赖关系图；如果你们还有DB Audit Tool，那么联动后你可以得到DB User/库表字段/应用/网络/主机容器的关系；等等，还可以和NIDS/威胁情报联动，达到溯源的目的。
• 用户态+内核态，AgentSmith-HIDS同时拥有内核态和用户态的模块，可以形成互补。

AgentSmith-HIDS实现了以下的主要功能：

• 内核模块通过kprobeHook了execve,connect,process inject, create file,DNS query,load LKM的行为，并且通过对Linux namespace兼容的方式实现了对容器行为的信息收集
• 用户态支持自定义检测模块，目前已内置：系统用户列表查询，系统端口监听列表查询，系统RPM LIST查询，系统定时任务查询
• 部分Rootkit检测能力，From: Tyton ，目前已经移植了PROC_FILE_HOOK，SYSCALL_HOOK，LKM_HIDDEN，INTERRUPTS_HOOK，目前仅支持Kernel > 3.10。
• cred 变化检测 （sudo/su/sshd除外）
• 用户登陆监控

AgentSmith-HIDS的使用场景/方式(待补充)

• 如何利用AgentSmith-HIDS检测反弹shell

关于内核版本兼容性

• Kernel > 2.6.25
• AntiRootKit > 3.10

对容器的兼容

行为源	Nodename
Host	hostname
Docker	container name
k8s	pod name

AgentSmith-HIDS的组成部分

• 内核驱动模块（LKM），通过kprobe hook关键函数，进行数据捕获；
• 用户态Agent，收取驱动捕获的指令并进行处理，然后将数据发送到Kafka；并向Server发送心跳确认存活，以及接受Server下发的指令进行执行；
• Agent Server端，向Agent下发指令，以及来查看当前Agent状态数量等信息；（可选组件）

Execve Hook

通过Hook sys_execve()/sys_execveat()/compat_sys_execve()/compat_sys_execveat() 实现，数据样例：

{
    "uid":"0",
    "data_type":"59",
    "run_path":"/tmp",
    "exe":"/opt/ltp/testcases/bin/growfiles",
    "argv":"growfiles -W gf26 -D 0 -b -i 0 -L 60 -u -B 1000b -e 1 -r 128-32768:128 -R 512-64000 -T 4 -f gfsmallio-35861 -d /tmp/ltp-Ujxl8kKsKY ",
    "pid":"35861",
    "ppid":"35711",
    "pgid":"35861",
    "tgid":"35861",
    "comm":"growfiles",
    "nodename":"test",
    "stdin":"/dev/pts/1",
    "stdout":"/dev/pts/1",
    "sessionid":"3",
    "sip":"192.168.165.1",
    "sport":"61726",
    "dip":"192.168.165.128",
    "dport":"22",
    "sa_family":"1",
    "pid_tree":"1(systemd)->1384(sshd)->2175(sshd)->2177(bash)->2193(fish)->35552(runltp)->35711(ltp-pan)->35861(growfiles)",
    "tty_name":"pts1",
    "socket_process_pid":"2175",
    "socket_process_exe":"/usr/sbin/sshd",
    "SSH_CONNECTION":"192.168.165.1 61726 192.168.165.128 22",
    "LD_PRELOAD":"/root/ldpreload/test.so",
    "user":"root",
    "time":"1579575429143",
    "local_ip":"192.168.165.128",
    "hostname":"test",
    "exe_md5":"01272152d4901fd3c2efacab5c0e38e5",
    "socket_process_exe_md5":"686cd72b4339da33bfb6fe8fb94a301f"
}

Bind Hook

通过Hook sys_bind() 实现，数据样例：

{
    "uid":"0",
    "data_type":"49",
    "sa_family":"2",
    "exe":"/usr/bin/python2.7",
    "pid":"109640",
    "ppid":"215496",
    "pgid":"109640",
    "tgid":"109640",
    "comm":"python",
    "nodename":"n225-117-018",
    "sip":"0.0.0.0",
    "sport":"8000",
    "res":"0",
    "sessionid":"30",
    "user":"root",
    "time":"1587540231936",
    "local_ip_str":"10.225.117.18",
    "hostname_str":"n225-117-018",
    "exe_md5":"4f458165a2129ba549f1b6605ee87e74"
}

Connect Hook

通过Hook tcp_v4_connect()/tcp_v6_connect()/ip4_datagram_connect()/ip6_datagram_connect() 实现，数据样例：

{
    "uid":"0",
    "data_type":"42",
    "sa_family":"2",
    "connect_type":"4",
    "dport":"1025",
    "dip":"180.101.49.11",
    "exe":"/usr/bin/ping",
    "pid":"6294",
    "ppid":"1941",
    "pgid":"6294",
    "tgid":"6294",
    "comm":"ping",
    "nodename":"test",
    "sip":"192.168.165.153",
    "sport":"45524",
    "res":"0",
    "sessionid":"1",
    "user":"root",
    "time":"1575721921240",
    "local_ip":"192.168.165.153",
    "hostname":"test",
    "exe_md5":"735ae70b4ceb8707acc40bc5a3d06e04"
}

DNS Query Hook

通过Hook udp_recvmsg()/udpv6_recvmsg() 实现，数据样例：

{
    "uid":"0",
    "data_type":"601",
    "sa_family":"2",
    "dport":"53",
    "dip":"192.168.165.2",
    "exe":"/usr/bin/ping",
    "pid":"6294",
    "ppid":"1941",
    "pgid":"6294",
    "tgid":"6294",
    "comm":"ping",
    "nodename":"test",
    "sip":"192.168.165.153",
    "sport":"53178",
    "qr":"1",
    "opcode":"0",
    "rcode":"0",
    "query":"www.baidu.com",
    "sessionid":"1",
    "user":"root",
    "time":"1575721921240",
    "local_ip":"192.168.165.153",
    "hostname":"test",
    "exe_md5":"39c45487a85e26ce5755a893f7e88293"
}

Create File Hook

通过Hook security_inode_create() 实现，数据样例：

{
    "uid":"0",
    "data_type":"602",
    "exe":"/usr/lib/jvm/java-1.8.0-openjdk-1.8.0.232.b09-0.el7_7.x86_64/jre/bin/java",
    "file_path":"/tmp/kafka-logs/replication-offset-checkpoint.tmp",
    "pid":"3341",
    "ppid":"1",
    "pgid":"2657",
    "tgid":"2659",
    "comm":"kafka-scheduler",
    "nodename":"test",
    "sessionid":"3",
    "user":"root",
    "time":"1575721984257",
    "local_ip":"192.168.165.153",
    "hostname":"test",
    "exe_md5":"215be70a38c3a2e14e09d637c85d5311",
    "create_file_md5":"d41d8cd98f00b204e9800998ecf8427e"
}

Process Inject Hook

通过Hook sys_ptrace() 实现，数据样例：

{
    "uid":"0",
    "data_type":"101",
    "ptrace_request":"4",
    "target_pid":"7402",
    "addr":"00007ffe13011ee6",
    "data":"-a",
    "exe":"/root/ptrace/ptrace",
    "pid":"7401",
    "ppid":"1941",
    "pgid":"7401",
    "tgid":"7401",
    "comm":"ptrace",
    "nodename":"test",
    "sessionid":"1",
    "user":"root",
    "time":"1575722717065",
    "local_ip":"192.168.165.153",
    "hostname":"test",
    "exe_md5":"863293f9fcf1af7afe5797a4b6b7aa0a"
}

Load LKM File Hook

通过Hook load_module() 实现，数据样例：

{
    "uid":"0",
    "data_type":"603",
    "exe":"/usr/bin/kmod",
    "lkm_file":"/root/ptrace/ptrace",
    "pid":"29461",
    "ppid":"9766",
    "pgid":"29461",
    "tgid":"29461",
    "comm":"insmod",
    "nodename":"test",
    "sessionid":"13",
    "user":"root",
    "time":"1577212873791",
    "local_ip":"192.168.165.152",
    "hostname":"test",
    "exe_md5":"0010433ab9105d666b044779f36d6d1e",
    "load_file_md5":"863293f9fcf1af7afe5797a4b6b7aa0a"
}

Cred Change Hook

通过Hook commit_creds() 实现，数据样例：

{
    "uid":"0",
    "data_type":"604",
    "exe":"/tmp/tt",
    "pid":"27737",
    "ppid":"26865",
    "pgid":"27737",
    "tgid":"27737",
    "comm":"tt",
    "old_uid":"1000",
    "nodename":"test",
    "sessionid":"42",
    "user":"root",
    "time":"1578396197131",
    "local_ip":"192.168.165.152",
    "hostname":"test",
    "exe_md5":"d99a695d2dc4b5099383f30964689c55"
}
