USTP

USTP means UDP Speedy Transmission Protocol.

USTP keeps the same authenticated transport model, but the project name is now simply USTP again.

By default, USTP uses AEAD for DATA.

It also supports an optional negotiated cleartext + HMAC mode for DATA, where payload bytes are visible on the wire but tampering is detected and rejected.

USTP now supports an optional congestion controller called USTP Congestion. It is still UDP-first, but it can optionally slow down and ramp back up when the path starts showing congestion signals.

Status: Beta

USTP is no longer just a proof of concept. It is currently in the Beta phase.

USTP can be used for many kinds of applications and transports.

This repository, however, is focused specifically on streaming over USTP.

News

02/08/2026: USTP-Secure is now back to USTP.
- USTP-Secure was an old project name and no longer a good fit for the project.
- The shorter USTP name is now preferred again.
- The full name is now UDP Speedy Transmission Protocol, without Secure in the title.
2026-07-18: USTP/2 Beta was removed from the current tree.
- Real-world behavior was less stable than USTP/1.1 under loss.
- The current stable transport path is USTP/1.1 only.
- The transport handshake now uses plaintext ASCII records.

Build note

Built with Codex using GPT-5.4 (Low).
Verified without freezing at --loss 33.
Test path: Brazil -> Canada with about 140ms RTT.

Security model

Transport remains UDP (no TCP tunnel)
AEAD ciphers:
- chacha20 = CHACHA20_POLY1305
- aes-256-gcm = AES_256_GCM
- aes-128-gcm = AES_128_GCM
Default AEAD cipher: chacha20
Default DATA protection mode is AEAD.
Optional DATA protection mode is cleartext + per-packet HMAC.
In cleartext mode, payload bytes are not encrypted, but modifications are detected and invalid packets are discarded.
Transport control packets (HELLO, ACK, RETRANSMIT_REQUEST, CLOSE) stay plaintext on purpose.

Packet magic values

ACK:, NACK:, HELLO:, and CLOSE: are the plaintext control record prefixes.
USS1 means UDP Speedy Secure, version 1.
USC1 means UDP Speedy Clear, version 1.
UPAK is the binary UPACK DATA frame marker.
In USTP, plaintext control is human-readable ASCII such as ACK: 10, NACK: 42, HELLO: ..., and CLOSE:.
In USTP, UPAK identifies binary DATA packets after decryption.

Transport model

USTP can run with optional USTP Congestion, negotiated during the handshake.
Packets carry both a transport seq and an application-facing stream_pos.
seq is used for ACK, loss detection, retransmission, and RTT sampling.
stream_pos tells the application where the payload belongs in the logical byte stream.
In the current implementation, seq is a 32-bit counter that starts at 1 for each fresh session.
In the current implementation, stream_pos is a 64-bit byte counter that starts at 0 for each fresh logical stream.
The receiver accepts packets immediately instead of blocking delivery behind one missing packet.

Handshake and session model

The client starts with a plaintext transport HELLO carrying its X25519 public key, requested cipher, requested congestion-control mode (on or off), and requested DATA protection mode (cleartext on|off).
The server does not send media immediately. It first sends a plaintext challenge containing:
- a random retry token
- a generated Base64 session_id
- the selected cipher
- the negotiated congestion-control mode
- the negotiated DATA protection mode
- the server public key
The client must answer with that exact same token and session metadata.
Only after that token round-trip succeeds does the server create the session and begin sending DATA.
After validation, the session is bound to the source IP:port that completed the challenge.
session_id is still used as a session label, but it is not accepted from a different IP:port.

Retry Token

USTP uses a plaintext retry-token step before any encrypted media session is accepted.
Flow:
- client sends HELLO
- server replies with USTPS-CHALLENGE1 carrying token, session_id, selected cipher, negotiated congestion-control mode, negotiated DATA protection mode, and server public key
- client echoes that token back in USTPS-CHALLENGE-REPLY1
- only then does the server create the session and send USTPS-SESSION1
Purpose:
- prove that the sender at that source IP:port can actually receive packets there
- avoid sending encrypted media immediately to an unvalidated source address
- bind the final session creation to the endpoint that completed the round-trip
The retry token is not the session key.
It is only a reachability proof and handshake gate before the real USTP session is created.
It is also not used as a nonce, not used as an ACK/NACK MAC key by itself, and not reused as packet payload state.

Historical protocol identifiers

The project name is now USTP, but several on-wire ASCII identifiers still use the historical USTPS-* prefix.
This is intentional for backward compatibility with existing implementations, captures, logs, and older deployments.
In the current implementation, the following control identifiers remain on the wire:
- USTPS-KEX1
- USTPS-CHALLENGE1
- USTPS-CHALLENGE-REPLY1
- USTPS-SESSION1
- USTPS-RESUME1
- USTPS-RTT1
The project/documentation name changed back to USTP, but those historical wire identifiers were not renamed in the protocol bytes.

MTU, PMTU, and fragmentation

Current UPACK DATA payload limit: 900 bytes.
UPACK fixed header: 20 bytes.
Outer USS1 secure envelope overhead in AEAD mode:
- 4 bytes magic
- 1 byte cipher id
- 12 bytes AEAD nonce
- 16 bytes AEAD tag
So the encrypted USTP DATA datagram is about 953 bytes before UDP/IP headers.
Outer USC1 cleartext envelope overhead in cleartext mode:
- 4 bytes magic
- 16 bytes HMAC tag
So the cleartext USTP DATA datagram is about 940 bytes before UDP/IP headers.

Old and duplicate packets

Duplicate packets inside the current session are ignored after their seq was already accepted.
Very old packets can age out of the receiver history window and then be ignored as stale.
Old ACK/NACK packets for data that has already been retired from the retransmission buffer are ignored.
A stale control packet does not recreate an already-finished packet in the sender.

Nonce behavior

DATA encryption uses a fresh random 12-byte AEAD nonce per encrypted packet.
The nonce is generated randomly, not derived from seq.
Nonce reuse with the same session key is forbidden.
seq is for transport reliability.
stream_pos is for logical application ordering.
nonce is only for AEAD packet protection.
Cleartext+HMAC mode does not use an AEAD nonce because it does not use AEAD encryption for DATA.

USTP Congestion

USTP Congestion is optional.
It does not change USTP into an ordered transport and it does not add TCP-style HoL blocking.
It only changes how aggressively the sender injects packets into the network.
Negotiation model:
- server: --congestion-control auto|on|off
- client: --congestion-control on|off
Default behavior:
- server default is auto
- client default is off
- with server auto, the server follows what the client asked for
- with server on, congestion control is forced on even if the client asked for off
- with server off, congestion control is forced off even if the client asked for on
Runtime behavior:
- starts at a normal send rate
- gradually increases the effective send window and burst size while the path stays healthy
- watches measured RTT, retransmission timeout events (), and explicit retransmit requests ()

Network change support

Automatic network/path migration has been removed from this implementation.
If the client changes network and its source IP:port changes, the current session is expected to end and the client should reconnect cleanly.
The migration implementation was removed because it caused practical reliability and security problems:
- repeated migration floods when NAT or mobile networks changed paths quickly
- stale sessions that looked recovered but no longer delivered media
- long silent periods followed by GAP-only behavior
- ambiguity between a real roaming client and spoofed packets claiming an existing session_id
- complex recovery state that could reset stream ordering or retransmission state at the wrong time
The current model is intentionally simpler: prove reachability with a challenge on the current IP:port, bind the session to that endpoint, and reconnect if the endpoint changes.

Wire format

ACK is serialized like ACK: 10 MAC:<tag> or batched like ACK: 10 11 12 ... MAC:<tag>.
RETRANSMIT_REQUEST is serialized like NACK: 42 MAC:<tag> or batched like NACK: 42 43 44 ... MAC:<tag>.
HELLO is serialized like HELLO: <base64-payload>.
CLOSE is serialized like CLOSE:.
DATA uses the binary UPACK frame format instead of ASCII to avoid bloating media payload packets.
In AEAD mode, captures typically look like readable control lines plus encrypted USS1... datagrams that decrypt to DATA frames.

Retransmission model

USTP uses selective retransmission, not Go-Back-N.
Every unique DATA packet is ACKed individually.
Missing packets trigger RETRANSMIT_REQUEST only for the missing seq.
The sender keeps sent packets in a retransmission buffer until ACKed.
RTO is not fixed-only: it is adapted from measured RTT samples of non-retransmitted packets.
Only the missing packets are retransmitted.

Log meanings

ACK: the receiver acknowledged one or more seq values, so the sender can retire them from the retransmission buffer.
NACK: the receiver detected a missing seq and explicitly requested retransmission of that missing packet only.
GAP: the client received a packet whose stream_pos is ahead of the next ordered output position, so there is currently a hole in the logical byte stream.
RECOVERY: a late packet arrived with stream_pos below the current frontier, meaning an earlier gap is being repaired or was repaired after newer data had already been seen.
RESYNC: the client anchored ordered output to a new stream_pos after a clean stream-state reset.
RTO: retransmission timeout. The sender did not see ACK progress in time, so it queued a packet for retry even without an explicit NACK.
no data for 10s: the client did not receive stream data for long enough and exits so a new clean session can be started.

Ordered Output Warning

USTP can receive packets out of order at the transport layer.
That behavior is possible, but it is not the recommended final application model for this repository.
This project is intended to use USTP as a transport that can accept later packets without transport-level blocking, while the application/output layer normally rebuilds the logical order with stream_pos when it needs a byte stream or player-friendly output.
If you expose raw out-of-order media chunks directly to a normal player or byte-stream consumer, behavior may be corrupted, incomplete, or unstable.
For that reason, direct unordered final output is not encouraged here except for very specific experiments.
This is also why --udp-unordered-live is documented separately as dangerous.
TCP has transport-level Head-of-Line blocking, while USTP avoids enforcing that ordering inside the transport itself.
If your final application output must be ordered, reordering still has to happen above USTP, in the application/output layer.

How to integrate USTP into your application

Treat USTP as a reliable transport with stream position metadata.
Do not assume packet arrival order is the real stream order.
Use stream_pos to rebuild ordered output when your application needs a byte stream.
In the normal model, the transport remains unordered and the application reorders with stream_pos.
If your application needs ordered output, keep a reorder buffer keyed by stream_pos and release data only when the required positions are available.
Do not rebuild ordering by seq; use seq only for transport reliability logic.

TCP and QUIC comparison

TCP: TCP is reliable and ordered, but that ordering is enforced by the transport itself. A single missing segment blocks later data in the same stream.
TCP with multiplexing above it: Even if an application multiplexes many logical channels over one TCP connection, loss in the underlying TCP byte stream still blocks progress behind the gap.
QUIC: QUIC removes cross-stream HoL blocking between different streams, which is a big improvement over TCP for multiplexed applications.
QUIC stream behavior: Inside one individual QUIC stream, ordering is still enforced. Missing data in that stream blocks later bytes for that same stream.
USTP: USTP does not enforce ordered delivery at the transport layer. It relies on stream_pos metadata when the application wants to reconstruct ordered output. If USTP Congestion is enabled, the sender may slow or speed up, but that does not change the transport model.

Server

python3 server.py \
  --peer-port 0 \
  --bind-ip 0.0.0.0 \
  --bind-port 40001 \
  --video "<HLS_URL_OR_LOCAL_FILE>" \
  --stream-container mpegts \
  --cipher chacha20 \
  --congestion-control auto \
  --cleartext auto

The default stream container is mpegts because it is the most reliable option with VLC in the current TCP-local playback path.

You can change the FFmpeg muxer/container with --stream-container.

Examples:

--stream-container mpegts (default, classic MPEG-TS compatibility)
--stream-container flv (experimental here; VLC may misdetect it as audio-only in this pipeline)
--stream-container nut (low overhead FFmpeg-native streaming container, but VLC may not open it)
--stream-container matroska (MKV/Matroska)

If you want custom ffmpeg encoding/transcoding parameters instead of the default copy mode, use --video-parameters.

Example:

python3 server.py \
  --peer-port 0 \
  --bind-ip 0.0.0.0 \
  --bind-port 40001 \
  --video "<HLS_URL_OR_LOCAL_FILE>" \
  --stream-container mpegts \
  --video-parameters "-c:v libx264 -preset veryfast -b:v 2500k -c:a aac -b:a 128k" \
  --cipher chacha20 \
  --cleartext off

Behavior:

without --video-parameters: uses -c copy
with --stream-container mpegts and no --video-parameters: also adds -mpegts_flags +resend_headers
with --video-parameters: uses exactly what you passed instead of the default copy settings
the selected container is always passed to FFmpeg as -f <stream-container>

About `--loss`

--loss simulates outbound packet loss on the server side for testing recovery behavior.
Value range: 0 to 100
Example:

python3 server.py \
  --peer-port 0 \
  --bind-ip 0.0.0.0 \
  --bind-port 40001 \
  --video "<HLS_URL_OR_LOCAL_FILE>" \
  --cipher chacha20 \
  --loss 40

--loss 0 means no simulated loss.
--loss 40 means the server randomly drops about 40% of its outbound packets before they leave the process.
This is useful for validating:
- retransmission behavior
- gap detection
- ACK/NACK handling
- playback resilience under controlled packet loss
In normal real-world usage, leave --loss at 0.

Client

python3 client.py \
  --peer-ip <SERVER_IP_OR_DOMAIN> \
  --peer-port 40001 \
  --bind-ip 0.0.0.0 \
  --bind-port 0 \
  --output-mode tcp \
  --tcp-host 127.0.0.1 \
  --tcp-port 1238 \
  --cipher chacha20 \
  --congestion-control off \
  --cleartext off
