otsmr/blackbox-fuzzingFuzzing IoT Devices Using the Router TL-WR902AC as Example
This is the HTML version of my term paper which can be downloaded as PDF here.
Fuzzing has become "one of the most effective ways" of finding bugs in software. With this or similar claims, many current fuzzing-related papers start [google-scholar]. The main goal of our last term paper about the topic "Internet of Vulnerable Things" was to find a memory-related bug and then write an exploit for this vulnerability. We were able to find a vulnerability by reversing the firmware, but no memory related bugs were found. Finding a buffer overflow by reversing a binary by hand is not only time-consuming, but also requires a lot of experience. Fuzzing at the same time aims to be the "most effective way" to find such memory related vulnerabilities. Google, for example, introduced OSS-Fuzz, which continuously fuzzes open source software and has already found over 10,000 vulnerabilities across 1,000 projects [oss-fuzz].
The goal of this term paper is again to find a memory-related vulnerability, but this time by using fuzzing. The goal vulnerability should be exploitable over the network without knowledge of the admin credentials. This paper describes the way to achieve this goal. For this, the paper is separated into two parts. The first part focuses on how to find a potent target, which tools can be used, and what a good fuzzing target should consist of. The second part then describes how to develop and debug a harness that is able to fuzz a specific function in a binary. Then the developed harness is used by AFL++ to fuzz the target function. In the following, a short background is given and what the current state of the art is when it comes to IoT device fuzzing.
All files created in context of this term paper are also published in full on GitHub and can be accessed using the following URL: otsmr/blackbox-fuzzing.
Fuzzing IoT devices is not as easy as fuzzing an open source project. Often the source code is proprietary, which makes gray-box fuzzing, which instruments the source code for the best fuzzing performance, impossible [afl-persistent]. Also, the CPU architecture is often not natively supported by fuzzers which requires an emulator like QEMU [qemu] which also slows down the fuzzing speed [afl-persistent]. Another issue is the hardware peripherals, which complicates the development of a general approach. The paper "Embedded Fuzzing: A Review of Challenges, Tools, and Solutions" [embedded-fuzzing] gives an overview of different fuzzing strategies, like hardware-based embedded fuzzing. Most of these strategies need the source code of the target program, like when porting the fuzzers source code, like AFL, to ARM-based IoT devices to run the fuzzer on the IoT hardware. Running the fuzzer on the device's hardware also has performance problems because they often have low-level CPUs, which are slower than normal desktop CPUs. Another approach presented in this paper is emulation-based embedded fuzzing. Where either a single targeted program is executed in an emulator to perform coverage-guided fuzzing or the full system.
The above-mentioned approaches all target a binary directly by using an emulator or by instrumenting
the source code. These approaches require a fuzzing setup that must often be specifically crafted
for a single IoT device and are hard to generalize. For that, researchers created a program
IoTFuzzer which aims to be an automated fuzzing framework aiming to "finding memory corruption
vulnerabilities without access to their firmware images
[iotfuzzer]." IoTFuzzers
based on the observation that most IoT devices have a mobile app to control them, and such apps
contain information about the protocol used to communicate with the device. The program then
identifies and reuses program-specific logic to mutate the test cases to effectively test IoT
targets [iotfuzzer].
A harness describes a sequence of API calls processing the fuzzer provided inputs. On the contrary to a normal application, which often does not need a harness, a library that implements reusable functions must be called with the correct parameters and also in the right sequence, so the state between multiple shared function calls can be called. Randomly fuzzing the library without building the state machine is unlikely to be successful and will, in contrast, create a lot of false-positive crashes when the library dependencies are not enforced. This can happen when, for example, a buffer size check is skipped by the fuzzer resulting in a spurious buffer overflow.
In this paper, normal applications will be fuzzed, but because of the hardware dependencies of the use of sockets and multi-threading, we need to create a harness for them as well. The harness is loaded in the context of the binary and can call internal functions of the targeted program, as shown in Code 10.
The term "corpus" describes valid input samples or test cases and serves as a foundational reference for generating new input data during the fuzzing process. In Code 10 this would be, for example, an HTTP request. Fuzzers then leverage this corpus to create mutated or diversified test cases, aiding in the detection of software vulnerabilities through the exploration of various input scenarios.
The most time-consuming part of black box fuzzing is finding a potential
vulnerable function in the firmware. The first step is to find
interesting binaries that, for example, are accessible over the network,
use insecure functions or do not have security features like stack
canary enabled, which is buffer overflow protection. Our last paper
([iovt]) already described how to extract the firmware
from the targeted router and how to find a potentially dangerous binary.
For this, the tool EMBA [emba] was used. EMBA ranks all
binaries found in the firmware by the count of unsecure functions like
strcpy, network access, and security protection like stack canary or
the NX-Bit which become interesting when exploiting a buffer overflow,
which can be found in Code 1.
[+] STRCPY - top 10 results:
235 : libcmm.so : common linux file: no | No RELRO | No Canary | NX disabled | No Symbols | No Networking |
77 : wscd : common linux file: no | No RELRO | No Canary | NX disabled | No Symbols | Networking |
[snip]
28 : httpd : common linux file: yes | RELRO | No Canary | NX enabled | No Symbols | Networking |
27 : cli : common linux file: no | No RELRO | No Canary | NX disabled | No Symbols | No Networking |
Code 1: EMBAs result of unsecure uses of the function strcpy.
