bazad/ida_kernelcacheAn IDA Toolkit for analyzing iOS kernelcaches.
ida_kernelcache is an IDAPython module for IDA Pro to make working with iOS kernelcaches easier. The module provides functions to:
__PRELINK_INFO segment into a Python dictionary.__got sections and stub functions in __stubs sections.The main processing function is designed to be run before any manual analysis or reverse engineering. With the default settings, IDA tends to miss a lot of useful information in the kernelcache. These scripts help IDA along by leveraging the known structure of the kernelcache to automatically propagate useful information.
In addition to the stock functionality in the module, ida_kernelcache contains several scripts to make analyzing the iOS kernelcache easier. For example, you can use the scripts to autogenerate C structs used by a function.
Many of the techniques used in ida_kernelcache were developed for and borrowed directly from memctl.
ida_kernelcache has been tested with IDA Pro 6.95 on kernelcaches for iOS versions 10.1.1, 11.0, 11.2, 11.3.1, and 12.0 beta. Currently only Arm64 kernelcaches from iOS 10 and later are supported.
You need to already have a decompressed kernelcache file loaded into IDA. You can find the URL to download a particular IPSW from Apple online, and there are a number of public tools (including memctl) capable of decompressing the kernelcache.
In IDA, select "File" -> "Script file..." from the menu bar, then choose the ida_kernelcache.py
script in the main directory. This will load the ida_kernelcache module into the IDAPython
interpreter under the names ida_kernelcache and kc. In the IDAPython prompt, type
kc.kernelcache_process() and hit Enter to start analyzing the kernelcache. This function performs
all the major analyses supported by ida_kernelcache. The function will run for several minutes as
IDA identifies and analyzes new functions.
ida_kernelcache will try not to overwrite user names for addresses. This means that if the
kernelcache has been manually analyzed prior to initialization with kernelcache_process, the
results may not be as thorough because user-specified names may block automatic name propagation.
However, there's also no guarantee that ida_kernelcache won't mess up prior analysis, so if you do
decide to run kernelcache_process on a kernelcache file which you've already analyzed, make a
backup first.
ida_kernelcache is meant to be loaded via ida_kernelcache.py; the submodules in the
ida_kernelcache directory are not meant to be loaded directly. However, ida_kernelcache exposes
the functionality of many of these submodules. Here is what each of them does:
ida_utilities:
This module wraps some of IDA's functions to provide an easier-to-use API. Particularly useful are
is_mapped, read_word, read_struct, force_function, and ReadWords. is_mapped checks
whether an address is mapped, and optionally whether it contains a known value. read_word reads a
variably-sized word from an address. read_struct reads a structure type into a Python dictionary
or Python accessor object, which makes parsing data structures much easier. force_function tries
several tricks to convert an address into the start of a function in IDA. ReadWords is a
generator to iterate over data words and their addresses in a range.
build_struct: This internal module contains utilities to automatically populate an IDA struct based on a sequence of accesses to the struct.
class_struct:
This module provides functions to generate IDA structs representing C++ virtual method tables and
classes. initialize_vtable_structs scans the (symbolicated) virtual method tables and creates IDA
structs to hold virtual method pointers. initialize_class_structs performs a data flow analysis
on the virtual methods to identify accesses to the fields of each class, then builds IDA structs to
represent the classes. Instructions that appear to reference a field are also converted into
structure offset references. See the module docstring for more details.
classes:
This module defines the ClassInfo type that holds information about C++ classes in the
kernelcache and provides the function collect_class_info to scan the kernelcache for classes and
populate the global class_info dictionary with a map from class names to ClassInfo objects. The
ClassInfo type records the class name, the OSMetaClass instance, the virtual method table, and
the superclass name for each C++ class. Additionally, each ClassInfo object stores references to
the superclass's ClassInfo and the ClassInfo of all direct subclasses, making it easy to
examine and traverse the class hierarchy. collect_class_info also stores the set of all virtual
method tables in the global vtables set.
data_flow: This internal module contains data flow operations used by the rest of ida_kernelcache.
kernel:
This module provides the base and prelink_info global variables. base is the base address of
the kernel image (the start of the kernel's Mach-O header). prelink_info is the parsed
__PRELINK_INFO dictionary.
kplist:
This module provides the kplist_parse function to parse kernel-style plists.
metaclass:
This module provides the function initialize_metaclass_symbols which adds a symbol for each
known OSMetaClass instance.
offset:
This module provides the functions initialize_data_offsets and initialize_offset_symbols. The
former scans through the segments looking for pointers which can be converted into offsets. The
latter symbolicates offsets in the __got section of each kext if the target of the offset has a
symbol.
segment:
This module provides the function initialize_segments to rename IDA's segments to be more useful.
By default, IDA seems to create the segment names by combining a guess of the bundle identifier
with the Mach-O section describing the region. initialize_segments extracts the true bundle
identifier from the __PRELINK_INFO dictionary and renames each segment to include the bundle
identifier, Mach-O segment, and Mach-O section. This makes it possible, for example, to distinguish
between __TEXT.__const and __DATA_CONST.__const. This module also provides the function
kernelcache_kext (re-exported at the top level) to determine the kext containing the specified
address (only on the old iOS 11 split-kext kernelcache format).
stub:
Many kexts in the kernelcache contain stub functions in a __stubs section that jump to functions
in the kernel proper. Unfortunately, these stubs provide a barrier for propagating cross references
and type information. This module doesn't solve these problems, but it does make looking at stubs a
bit easier by automatically renaming stub functions so that the target function name is visible.
Stubs and their targets are forcibly converted into functions in IDA, which helps make the
functions in IDA line up with the functions in the original source code.
