SPiCa

System Process Integrity & Cross-view Analysis

"I'm going to sing, so shine bright, SPiCa..."

SPiCa is an eBPF-based Linux rootkit detector written in Rust. The name comes from the Hatsune Miku song SPiCa and the star it references — Spica (Alpha Virginis), the brightest point in Virgo. What looks like a single star to the naked eye is actually a spectroscopic binary: two stars in mutual orbit, indistinguishable as separate objects without measuring their spectra. SPiCa applies the same principle to kernel observation: multiple independent channels measure the same kernel state from physically distinct mechanisms, and a rootkit that suppresses one is exposed by the others.

Disclaimer: Significant portions of this codebase were generated or refactored with GLM assistance. Rigorous testing and iterative design were applied, but review the code for security and performance before production use.

Table of Contents

1. Threat Model
2. Architecture Overview
3. The sched_switch Observation Channel
4. The NMI Integrity Channel
5. Detection Logic
6. Verifier-Bounded Address Secrecy
7. LSM Map-Access Gate
8. Key Management & Obfuscation
9. PCR-Bound TPM Sealing (Design)
10. Defense in Depth
11. The BTF Bug Incident
12. Known Limitations & Attack Surface
13. Build & Run
14. Roadmap
15. Glossary

1. Threat Model

The constrained adversary: the eBPF rootkit

SPiCa is designed to defeat the eBPF-constrained adversary — an attacker with elevated privileges (CAP_BPF or CAP_SYS_ADMIN) who loads a privileged eBPF program into the kernel. This adversary is fundamentally weaker than an LKM rootkit because the BPF verifier imposes hard constraints:

With LKMs blocked by the LSM gate after boot, this constrained adversary is the realistic remaining threat. SPiCa's anti-evasion machinery is calibrated for this threat — every defense is honest about what it covers and what it doesn't.

Non-goals

• Nation-state kernel exploits — memory corruption yielding arbitrary kernel write without init_module. SPiCa raises the floor by blocking the easier LKM vector but does not ceiling the adversary.
• Hostile LKMs loaded before SPiCa started — defense in depth (Secure Boot, module signing, IMA) is required for the boot window.
• Verifier exploits — if the BPF verifier is unsound (historical CVEs: CVE-2020-27194, CVE-2022-23222, CVE-2023-2163), the adversary escapes the constrained model into arbitrary kernel code execution. This is a separate threat class. SPiCa's defenses hold under a correct verifier.

SPiCa is the last-resort layer in a defense-in-depth stack, not a substitute for the layers above.

2. Architecture Overview

SPiCa runs four eBPF programs attached to kernel hooks, plus a userspace detection engine that cross-correlates their output against the system's view of itself (/proc).

Three observation channels, each suppressible only by a mechanism of escalating cost

The key architectural property: a rootkit cannot suppress all three channels simultaneously without the suppression itself becoming detectable or destabilizing. Suppressing NMI requires patching the IDT (Interrupt Descriptor Table), which panics on most kernels. This is the "live bomb" — the attacker's only path to total blindness is one that likely crashes the system.

Detection model — three sentences

sched sees it, /proc doesn't              → DKOM
NMI finds sched's heartbeat stopped       → TAMPER
sched goes globally silent, /proc != empty → SILENT

Each detection class is a differential verdict: a discrepancy between two or more channels. The detection engine is a pure function over the registry + /proc snapshot + channel timestamps — no I/O, no side effects, fully unit-testable.

The NMI redesign: from observation to integrity

In the original design, NMI was a second process-observation channel that sampled the CPU and reported which task was running. This was redundant: sched_switch already observes scheduling, and NMI sampled the same data via a different mechanism. The redundancy cost ~1000+ ring-buffer events/sec/CPU of process data that 99.999% of the time confirmed "yes, the scheduler is doing what the scheduler does."

In the redesigned architecture, NMI is repurposed from process observation to tracepoint integrity verification. It no longer reports which process is on the CPU. Instead, it verifies that sched_switch is actually running by reading a shared .bss heartbeat. This:

1. Eliminates ~99% of NMI ring-buffer traffic (near-zero steady-state events)
2. Directly detects tracepoint detachment, suppression, and BTF/attach failures (the original BTF bug — see §11)
3. Runs from a hardware interrupt, outside the tracepoint dispatch path — immune to bpf_override_return, kprobe interception, and funcs-array manipulation
4. Reads .bss globals via direct memory access, not BPF helpers — immune to fmod_ret on helper functions

3. The sched_switch Observation Channel

An eBPF program attached to the sched_switch tracepoint fires every time the kernel schedules a process onto a CPU. It reads the incoming task's PID and comm directly from the tracepoint arguments using traditional (non-BTF) fixed-offset reads:

ctx.read_at::<u32>(56)    → next_pid
ctx.read_at::<[u8;16]>(40) → next_comm

Deliberately not BTF/CO-RE. The tracepoint argument layout is stable across kernel versions (it's part of the tracepoint ABI). Using hardcoded offsets avoids the kernel-version fragility of BTF-resolved struct navigation. This is a deliberate design choice documented in §11.

On every invocation, the program:

1. Reads next_pid and next_comm from the tracepoint context
2. Filters out the idle task (PID 0)
3. XOR-obfuscates the ProcessInfo struct with BASE_KEY
4. Submits to the sc_sched ring buffer
5. Writes bpf_ktime_get_ns() to the .bss global SCHED_HEARTBEAT — the heartbeat that the NMI integrity checker monitors

The program deliberately avoids bpf_get_current_pid_tgid() in this context. At sched_switch time, "current" is the outgoing task, not the incoming one. The tracepoint arguments provide the correct (incoming) process identity.

Time-base discipline

The detection engine uses a single monotonic time base: nanoseconds since SPiCa's process startup (Instant::now() since run_detection() entry). When a sched event arrives, the event handler stores the caller-provided now (process-local nanos), not the eBPF bpf_ktime_get_ns() value embedded in the event. This avoids the time-base mismatch that would occur if kernel boot time were mixed with process-local time — a bug that was present in earlier versions and caused all liveness predicates to silently fail.

4. The NMI Integrity Channel

Design: .bss heartbeat, no BTF, no kernel struct walking

The NMI program is attached to a hardware perf counter (HW_CPU_CYCLES) that fires at hardware interrupt level. NMIs cannot be disabled with cli — suppressing them requires reprogramming the PMU or hooking the IDT, both of which are loud and destabilizing.

The integrity check mechanism is dead simple:

.bss (shared within SPiCa's ELF object — all programs see the same memory):
  SCHED_HEARTBEAT   ← written by sched_switch on every invocation
  NMI_LAST_HB       ← NMI's record of the last heartbeat it observed
  NMI_FIRST_TICK    ← first NMI invocation timestamp (grace period reference)
  NMI_LAST_EMIT     ← throttle: last event emission timestamp

sched_switch runs → SCHED_HEARTBEAT = bpf_ktime_get_ns()

NMI fires (once per second, throttled):
  if SCHED_HEARTBEAT == NMI_LAST_HB:
    if past grace period (5 seconds since first NMI tick):
      → sched_switch stopped running → emit event_type=1 (TAMPER)
  else:
    → sched_switch is alive → emit event_type=0 (heartbeat OK)
  NMI_LAST_HB = SCHED_HEARTBEAT

Why this detects every attack in scope

Why .bss specifically

.bss globals are stored in the BPF program's internal data section, backed by an internal array map that the loader manages. They are:

• Not separately pinnable — they don't appear as named maps in /sys/fs/bpf/
• Not interceptable via bpf_map_update_elem hooks — .bss writes are direct memory stores, not map-update syscalls. The old sc_canary mechanism (comparing a .bss copy against a named-map copy to detect bpf_map_update_elem interception) is no longer needed.
• Shared between programs in the same ELF object — sched_switch and NMI communicate through .bss without any external interface

Immunity to BPF-based interception

The NMI integrity checker is structurally immune to BPF override attacks because of a fundamental property: bpf_override_return intercepts function calls, but the NMI checker doesn't call the things it verifies — it reads .bss memory directly. You cannot override the return value of a memory read because a memory read is not a function call.

Additionally:

• bpf_probe_read_kernel (used for kernel struct reads in alternative designs) is a fault-safe helper that accepts any address — but SPiCa's .bss heartbeat design doesn't even need it. The checker reads .bss globals via direct load instructions.
• The NMI program runs in NMI context, where kprobes are structurally unreliable (the kernel defers or suppresses them). A kprobe-based attack against the checker's execution fights the hardware.

NMI event semantics

The NMI ring buffer (sc_nmi) carries lightweight events:

Events are emitted at most once per second (throttled by NMI_LAST_EMIT). If the NMI ring buffer goes silent for >5 seconds, userspace fires [SILENT] — the NMI channel itself is dead.

5. Detection Logic

graph TD
    subgraph RING0["Kernel Space: Four eBPF Programs"]
        direction TB
        SCHED_P["TracePoint, sched_switch<br/>read next_pid, next_comm<br/>write SCHED_HEARTBEAT (.bss)<br/>XOR obfuscate → sc_sched"]
        NMI_P["PerfEvent hardware NMI<br/>read SCHED_HEARTBEAT (.bss)<br/>compare to NMI_LAST_HB<br/>frozen → event_type=1 (TAMPER)<br/>alive → event_type=0 (heartbeat)<br/>→ sc_nmi"]
        LSM_P["BPF LSM, kernel_read_file<br/>READING_MODULE<br/>gate=0: allow + log<br/>gate=1: EPERM + log → sc_lsm"]
        WATCH_P["TracePoint, sched_process_exit<br/>current == SPICA_PID (.bss)? → sc_wd flag"]
    end

    subgraph RING3["User Space: Differential Engine"]
        ENGINE["SPiCa (Tokio async)"] -->|XOR deobfuscate| RB_S[(sc_sched RingBuf)]
        ENGINE -->|event_type=0: heartbeat<br/>event_type=1: TAMPER| RB_N[(sc_nmi RingBuf)]
        ENGINE -->|raw read| RB_L[(sc_lsm RingBuf)]
        ENGINE -->|read_dir| PROC[" /proc"]
        RB_S --> FSM{Detection FSM}
        PROC --> FSM
        FSM -->|scheduled, absent /proc, >2s| D1["[DKOM]"]
        FSM -->|in /proc, never seen by sched, >5s| D2["[GHOST]"]
        RB_N -->|event_type = 1| D3["[TAMPER]"]
        FSM -->|sched channel silent, /proc ≠∅| D4["[SILENT]"]
        FSM -->|raw getdents64 ≠ libc readdir| D9["[HOOK]"]
        RB_S -->|same TGID, different start_time_ns| D5["[DUPE]"]
        RB_L -->|allowed = 1| D7["[LKM-ALLOW]"]
        RB_L -->|allowed = 0| D8["[LKM-DENY]"]
        WATCH_P -.->|pin exists at startup| D6["[WATCHDOG]"]
    end

    classDef kernbox  fill:#fdf2f8,stroke:#9333ea,stroke-width:2px,color:#581c87;
    classDef userbox  fill:#eff6ff,stroke:#2563eb,stroke-width:2px,color:#1e3a8a;
    classDef alertbox fill:#fff7ed,stroke:#ea580c,stroke-width:1px,color:#7c2d12;
    classDef storage  fill:#f8fafc,stroke:#64748b,stroke-width:1px;
    class RING0 kernbox;
    class RING3 userbox;
    class D1,D2,D3,D4,D5,D6,D7,D8,D9 alertbox;
    class RB_S,RB_N,RB_L,PROC storage;

Channel-level SILENT detection

SILENT is a channel-level verdict, not a per-process one. It fires when:

1. sched channel dead: max(sched_last) over all registry records is stale beyond CHANNEL_DEAD_NANOS while /proc is non-empty. The non-empty-/proc guard is the liveness guarantee: on any running Linux system, /proc is non-empty (init, kernel threads, kworkers), and the scheduler is never truly idle (timer ticks, I/O waiters, RCU callbacks). A stale max(sched_last) on a non-empty system means the channel died — not that the system is idle.

2. NMI channel dead: No heartbeat event (event_type=0) has arrived from the NMI ring buffer for >5 seconds. This means the NMI perf event stopped firing — either the perf event was detached or the PMU was reprogrammed.

Both checks have a 30-second cooldown to prevent alert flooding.

LD_PRELOAD rootkit detection ([HOOK])

SPiCa reads /proc via two independent mechanisms on every tick:

1. Raw getdents64 syscall (read_tgids()) — Rust's std::fs::read_dir calls this directly via libc::syscall(SYS_getdents64, ...), bypassing all libc function hooks. LD_PRELOAD rootkits cannot intercept this path.

2. libc readdir (read_tgids_libc()) — calls libc::opendir / libc::readdir via FFI, which goes through the dynamic linker and is fully interceptable by /etc/ld.so.preload hooks.

If getdents64 sees PIDs that libc readdir doesn't, a userspace rootkit is hooking readdir to hide processes. SPiCa fires [HOOK]:

[HOOK]       3 PID(s) hidden from libc readdir — LD_PRELOAD rootkit suspected

This technique turns SPiCa's kernel-level privilege into an active detection of userspace rootkits. The raw syscall path is the ground truth — no userspace hook can blind it. The libc path is the "perceived" view that a normal tool (ps, ls) would see. The discrepancy is unambiguous proof of library interception.

Rootkits detected by [HOOK]:

Tested against real Symbiote: A live Symbiote sample (SHA256 f55af21f..., MalwareBazaar) was deployed via /etc/ld.so.preload on an Ubuntu 24.04 VM. The sample hooks readdir, readdir64, stat, fstatat, pam_authenticate, pcap_loop, recvmsg, fopen, read, execve. When the LD_PRELOAD hook actively hides a PID from readdir, SPiCa fires [HOOK] within one tick cycle (<1 s). When Symbiote is loaded but passive (not actively hiding), SPiCa produces zero false positives.

Grace window

A 50 ms grace window prevents false positives on freshly-forked processes. Channel-level SILENT checks have a 5-second grace period (the NMI program's NMI_FIRST_TICK reference) so that startup latency doesn't produce false TAMPER alerts.

6. Verifier-Bounded Address Secrecy

Definition

Verifier-bounded address secrecy is a computational security property that holds under the eBPF-constrained adversary model. It states:

Given an adversary who can load eBPF programs (CAP_BPF) but is constrained by the BPF verifier (bounded loops, restricted helpers, no arbitrary kernel write), the kernel address of a BPF program's .bss data section is computationally infeasible to discover.

The four mechanisms

The property is a composition of four independent barriers:

1. kASLR — Kernel Address Space Layout Randomization randomizes the kernel heap region where BPF map memory (including .bss backing maps) is allocated. The exact address changes on every boot.

2. Verifier instruction bound — The BPF verifier bounds total instructions per program to ~1 million and requires provably terminating loops. An adversary's scanning program can probe at most N ≈ 10^6 addresses per load via bpf_probe_read_kernel. Given a kASLR-randomized search space, per-program success probability is negligible.

3. LSM map-access gate (see §7) — Without the gate, an adversary could enumerate BPF maps by ID (BPF_MAP_GET_NEXT_ID → BPF_MAP_GET_FD_BY_ID → BPF_MAP_LOOKUP_ELEM) and read .bss contents directly. The gate removes this easy path, forcing the adversary into the verifier-bounded memory-scan path.

4. .bss placement — .bss globals do not appear in named-map enumeration interfaces with human-readable names. The internal .bss backing map is named .bss by libbpf/aya, but its contents (the actual global variables) are only accessible if you have the map fd. The map fd requires either the loading process's fd table or the map ID (blocked by the gate).

Formal argument structure

Adversary's goal:    locate SPiCa's .bss in kernel virtual memory
Search space:        kernel heap region, kASLR-randomized (~2^30 entropy)

Path A — map enumeration (blocked):
  BPF_MAP_GET_NEXT_ID → BPF_MAP_GET_FD_BY_ID → BPF_MAP_LOOKUP_ELEM
  → blocked by LSM gate (§7) for non-SPiCa processes

Path B — memory scan (bounded):
  bpf_probe_read_kernel(addr, buf, len) — fault-safe, accepts any addr
  Per-program capacity: N ≈ 10^6 probes (instruction limit)
  Success probability per load: N / |search space| ≈ 10^6 / 2^30 ≈ 10^-24
  Can reload programs, but: each load is a syscall (observable), and
  the target address doesn't change between loads (same boot session)

Path C — timing side channel (theoretical):
  bpf_probe_read_kernel timing varies on fault vs success
  Binary search over the heap could reduce scan complexity to O(log |A|)
  → O(30) probes, well within instruction budget
  LIMITATION: must be acknowledged. Mitigated by rate-limiting BPF_PROG_LOAD
  via the LSM gate (future work).

What makes this novel

Most BPF security research treats the verifier as an attack surface (verifier bugs, unsoundness, JIT spray). This work inverts the framing: the verifier's constraints are a defensive primitive that bounds the adversary's search space. The secrecy isn't cryptographic (it's not AES); it's computational — bounded by what the verifier permits the adversary to compute.

Limitations (must be stated honestly)

• Verifier exploits — If the verifier is unsound, the instruction bound breaks and the adversary can do arbitrary computation. This is outside the eBPF threat model.
• Timing side channels — bpf_probe_read_kernel is timing-observable (fault vs. success takes different cycles). A timing-based binary search over the heap is theoretically more efficient than linear scan. The instruction bound limits probes per program, but binary search could reduce the probe count to O(log |A|) ≈ 30. This is a real limitation. Mitigation: rate-limit BPF_PROG_LOAD via the LSM gate.
• Userspace root — A userspace root process (not constrained by the verifier) can enumerate maps by ID. The LSM gate blocks this, but only for non-SPiCa processes. A process that compromises SPiCa's own PID has full access.

7. LSM Map-Access Gate

The problem

.bss globals are backed by an internal BPF map. Any process with CAP_BPF can enumerate all maps on the system:

bpf(BPF_MAP_GET_NEXT_ID, …) → iterate all map IDs
bpf(BPF_MAP_GET_FD_BY_ID, id) → get fd to any map
bpf(BPF_MAP_LOOKUP_ELEM, fd, key, value) → read map contents

Against the eBPF adversary (who can't call syscalls), .bss is hidden. Against userspace root, it's a standard map — fully readable. The LSM gate closes this gap.

The defense

A BPF LSM hook on the bpf syscall checks map-access commands:

hook = "bpf"
  read cmd (arg 0)
  if cmd == BPF_MAP_GET_FD_BY_ID:
    read map_id from userspace bpf_attr (bpf_probe_read_user)
    if map_id matches any of SPiCa's stored IDs (.bss):
      if caller_tgid != SPICA_PID:
        return -EPERM

Map IDs are written to .bss by the userspace loader right after program load, before the LSM hook is armed (same timing pattern as the existing sc_gate for LKM blocking). No BTF needed — cmd and map_id come from syscall arguments, not kernel structs.

Surgical: only blocks access to SPiCa's specific map IDs. Other processes' BPF tools (tcpdump, bpftrace, bcc) access their own maps and are unaffected.

What it doesn't cover

• ptrace / /proc/pid/mem — Another root process could read SPiCa's process memory directly via ptrace, bypassing the BPF syscall entirely. This is a fundamental limitation: you can't protect against a process with the same privilege level reading your memory via /proc/pid/mem. Defense: off-host log shipping (if the attacker can read local memory, they can also suppress local alerts — only remote logging helps).
• SPiCa's own PID compromised — If the attacker gains control of SPiCa's process, they have legitimate access to the maps.

8. Key Management & Obfuscation

TPM-sourced key

On TPM-equipped hosts, the 64-bit XOR obfuscation key is sourced from TPM2_GetRandom via the tss-esapi crate (direct library call to libtss2-esys). The key transits no pipe, no subprocess command line, no disk. It exists only in TPM hardware and in kernel volatile memory (.bss backing map) for the duration of the SPiCa process.

On hosts without a TPM (VMs without vTPM, containers, machines without a TPM chip), SPiCa falls back to a per-build compile-time key generated from /dev/urandom by the build script. The fallback is visibly loud at startup with a warning banner.

.bss placement

The following values live in the eBPF program's .bss section, written by userspace via set_global() before any program is loaded:

Named BPF maps are enumerable via the bpf() syscall's map iteration interface (blocked by the LSM gate — see §7); .bss globals are accessed through the same internal map but are not separately named or pinnable.

XOR obfuscation — read-leakage defense, not encryption

All ProcessInfo fields are XOR-folded with the 64-bit BASE_KEY before being written to ring buffers. The event_type field is intentionally left unobfuscated so userspace can read it as a sentinel before deobfuscating the rest.

This is obfuscation against read-leakage, not encryption against a capable adversary. XOR with an 8-byte repeating key is structurally vulnerable to known-plaintext: predictable comm values ("bash", "systemd", "kthreadd") XOR'd against the ciphertext recover key bytes directly. The defense is appropriate for the eBPF adversary (who can't easily read the ring buffer — it requires the same capability gap that protects .bss), not for an adversary with binary access + ring buffer interception.

9. PCR-Bound TPM Sealing (Design)

Status: Design phase. Not yet implemented. This section documents the target architecture for the research paper.

Overview

PCR-bound TPM sealing moves the key distribution boundary from the software layer into silicon. The key is sealed at install time against expected Platform Configuration Register (PCR) values, and can only be unsealed if the system's boot state matches the expected measurements.

Boot measurement chain

During boot, the firmware, bootloader, and kernel measure critical components into PCRs:

Note: PCR allocation is boot-chain-dependent. GRUB measures the kernel to PCR 4; systemd-stub measures to PCR 4 and the command line to PCR 8. The sealing policy must match the target boot chain.

The seal → unseal → inject → fail-safe flow

1. Seal (install time): The 64-bit key is sealed against expected PCR values using TPM2_Create with a TPM2_PolicyPCR session. The sealed blob is stored on disk. It is encrypted with the TPM's internal key and can only be decrypted when the specified PCRs match.

2. Unseal (early boot, initramfs stage): Before any untrusted userspace code executes, SPiCa's initramfs hook requests TPM2_Unseal. If the current PCR values match the seal policy, the TPM releases the key.

3. Inject: The key is written to .bss via set_global() before programs are loaded.

4. The trap: If an attacker has modified the kernel (PCR 4 mismatch), swapped the initramfs (PCR 9 mismatch), or altered the Secure Boot policy (PCR 7 mismatch), the PCR hashes diverge. The TPM refuses to unseal, and SPiCa fails safe — it refuses to start rather than running blind with a compromised key.

PCR policy options

For the research paper, present the strong policy and discuss the re-seal tradeoff in limitations.

Relationship to verifier-bounded address secrecy

The two mechanisms are complementary:

• PCR sealing protects the key at boot — it ensures the key is only available on a trusted system state.
• Verifier-bounded address secrecy + LSM gate protect the key at runtime — they ensure the eBPF adversary can't locate or read the .bss where the key lives.

Neither is sufficient alone. PCR sealing doesn't help if the key is compromised at runtime (map enumeration). Address secrecy doesn't help if the system was compromised before SPiCa started (hostile initramfs).

What PCR sealing does NOT catch

• Runtime LSM program detachment — The BPF LSM programs (spica_lsm_modblock, the map-access gate) are loaded at runtime and are NOT measured to any PCR. A rootkit that detaches them after boot isn't caught by PCR sealing. What catches that is the NMI heartbeat (detecting that the detection system itself stopped running).
• Post-boot kernel exploitation — If the kernel is exploited after boot (memory corruption → arbitrary write), PCRs are unchanged. This is the "nation-state" non-goal.

10. Defense in Depth

SPiCa is the last enforcement layer. It complements a properly configured system, not replaces the layers above.

flowchart TD
    SB["UEFI Secure Boot<br/>─────────────────────────────<br/>Verifies bootloader signature against<br/>the UEFI db certificate store<br/>Measured to PCR 7"]
    MS["Kernel Module Signing<br/>─────────────────────────────<br/>CONFIG_MODULE_SIG_FORCE=y<br/>Kernel rejects unsigned .ko at load time"]
    IMA["IMA, Integrity Measurement Architecture<br/>─────────────────────────────<br/>Measures file hashes to TPM PCR10<br/>Appraise policy blocks non-matching signatures"]
    SPICA["SPiCa<br/>─────────────────────────────<br/>LSM gate: blocks LKM loads + map enumeration<br/>sched_switch + NMI integrity channels<br/>Differential detection: DKOM · GHOST · TAMPER · SILENT · DUPE<br/>PCR-bound key sealing (design phase)"]

    SB  -->|"boot chain verified"| MS
    MS  -->|"signed modules only"| IMA
    IMA -->|"measured + appraised"| SPICA

    classDef firmware fill:#fef3c7,stroke:#d97706,stroke-width:2px,color:#78350f
    classDef kernel   fill:#fdf2f8,stroke:#9333ea,stroke-width:2px,color:#581c87
    classDef spica    fill:#eff6ff,stroke:#2563eb,stroke-width:2px,color:#1e3a8a
    class SB firmware
    class MS,IMA kernel
    class SPICA spica

SPiCa checks all four layers at startup and prints their status.

11. The BTF Bug Incident

What happened

During testing on Ubuntu (latest kernel), a BTF incompatibility caused the sched_switch tracepoint program to attach successfully but never fire a single event. The attach() syscall returned Ok(()), so SPiCa proceeded normally — but the sched ring buffer stayed empty. No detection alerts fired because the detection engine had no scheduling data. SPiCa ran blind without any indication of failure.

This is the worst-case failure mode for a security tool: silent blindness.

Why it wasn't detected

The original detection engine reasoned per-process: each process record had sched_last and nmi_last timestamps, and liveness was computed per-record. When sched_switch died globally:

1. sched_live flipped false for every record (no new sched events → all sched_last values age out)
2. The per-process TAMPER predicate (in_proc && nmi_live && !sched_live) could fire, but required nmi_live held continuously for 2 seconds. NMI samples sparsely (10M cycle period), so suspect_since kept resetting on sampling jitter and never matured.
3. The per-process SILENT predicate required sched_live, which was now false for everything — the predicate inverted under exactly the condition it was meant to detect.
4. There was no channel-level liveness check — no "has sched EVER fired?" or "is max(sched_last) stale?" mechanism.

Additionally, a time-base mismatch was discovered: sched_last stored bpf_ktime_get_ns() (kernel boot nanoseconds) while evaluate() compared against nanos_since_startup() (process-local nanoseconds). The wrapping_sub of these different time bases produced huge values, making all liveness predicates trivially false. The detection logic had never worked correctly in production — the BTF bug just masked it by preventing events from arriving at all.

How the redesign fixes it

12. Known Limitations & Attack Surface

Within the eBPF threat model

Outside the eBPF threat model (acknowledged, not solved)

13. Build & Run

Prerequisites

• Linux kernel >= 5.15 with CONFIG_DEBUG_INFO_BTF=y (for the LSM hook only)
• For module blocking: CONFIG_BPF_LSM=y and lsm=bpf in kernel cmdline
• TPM 2.0 chip + tpm2-tss library (optional; falls back with visible warning)
• Nightly Rust toolchain

Note: The generate-vmlinux step is no longer required. The eBPF programs use traditional tracepoint offsets and .bss globals — no CO-RE/BTF struct navigation is needed. The xtask generate-vmlinux command is retained for future use but is not part of the build pipeline.

Verify BPF LSM is active: cat /sys/kernel/security/lsm should contain bpf.

Setup

make install-deps     # system packages + nightly Rust (pacman/apt/dnf auto-detected)
make install-tools    # bpf-linker
make build            # compiles eBPF + userspace (no vmlinux generation needed)

Run

make run              # sudo ./target/release/spica

Install to initramfs (early-boot protection)

sudo make install     # spica install — auto-detects Debian (initramfs-tools) or Fedora (dracut)

Verify it's working

sudo insmod some_module.ko    # should fail with EPERM (gate locked)
cat /sys/kernel/security/lsm  # should contain 'bpf'
ls /sys/fs/bpf/spica_watchdog # exists if previous run was killed ungracefully

Development (macOS or Linux)

The eBPF programs cannot run on macOS. cargo check and unit tests for the detection logic work; full runtime verification requires Linux.

make check      # cargo check for workspace
make check-ebpf # cargo check for the eBPF crate (bpfel-unknown-none)
make test       # unit tests for detection FSM, key derivation, obfuscation

14. Roadmap

• PCR-bound key sealing — real hardware attestation. At install time, seal the key to expected PCR values (PCR 4/7/9/10). At runtime, unseal fails if PCRs changed. Replaces the current GetRandom-only TPM use with full hardware root of trust. See §9.
• LSM map-access gate — BPF LSM hook on the bpf syscall blocking map enumeration of SPiCa's internal state from non-SPiCa processes. See §7.
• BPF_PROG_LOAD rate limiting — Extend the LSM gate to rate-limit BPF program loads from non-SPiCa processes, mitigating the timing-side-channel risk on .bss discovery. See §6 limitations.
• SipHash PRF obfuscation upgrade — If the threat model grows to include adversaries with ring-buffer read access, swap XOR for a SipHash-1-3 keystream (the siphasher dep is already in the tree for the integrity token).
• Enterprise logging backend — Optional Elasticsearch/Elastic SIEM shipping for SOC environments. All alerts, termination events, and restart counter anomalies shipped off-host in real time.
• Additional distro support — Arch (mkinitcpio), openSUSE.
• CI pipeline — Linux smoke tests exercising real eBPF load + attach + ring buffer flow.

15. Glossary

License

SPiCa Engine License: MIT OR Apache-2.0 (workspace). The eBPF program exports a GPL license via the _license static — this is a kernel requirement for eBPF programs that use GPL-licensed helpers, and applies only to the loaded eBPF bytecode, not the userspace binary.

Character Attribution: "Hatsune Miku" and associated character artwork are copyrighted properties of Crypton Future Media, INC. (www.piapro.net). This project is an independent, non-commercial research tool, not affiliated with Crypton Future Media. Character used under the Piapro Character License (PCL).

The SPiCa project name is inspired by the original song by Toku-P.
