PhantomFS v1.2.20

Fake Files. Real Security.
Virtual honeypot file system for Windows — lure attackers into a directory that looks real, then catch them in the act.

---

What Is PhantomFS?

PhantomFS uses the Windows Projected File System (ProjFS) to surface a virtual directory full of convincing decoy files — financial reports, SSH keys, API credentials, HR spreadsheets, NDAs — that exist only in memory. No data is ever written to disk until an attacker (or insider threat) opens one.

The moment a file is touched, PhantomFS:

• Writes a Windows Event Log entry (Application log, source PhantomFS)
• Fires a Toast notification to the active desktop session
• Logs the exact filename, timestamp, and process context
• When accessed over a network share — captures the SMB username and source address

Because legitimate users have no reason to open files they didn't put there, every alert is high-confidence. No tuning, no ML, no cloud dependencies — just a native Windows driver and a single executable.

---

Features

Feature	Details
Zero-footprint decoys	Files are projected on demand — nothing is written to disk unless an attacker reads a file
Windows Event Log	Event ID 1001 (file read), 1002 (placeholder created), 1003 (started), 1004 (stopped)
Toast alerts	Immediate desktop notification via Windows PowerShell — works even over RDP
Remote session logging	SMB username and source address captured via NetSessionEnum when PID 4 triggers access
Auto-cleanup	Hydrated synthetic files deleted after a configurable delay; reverts to virtual on next access
Configurable templates	PDF, XLSX, DOCX, JSON, CSV, PEM, plain text — all served from XML templates in the config
Per-file cooldown	Configurable throttle (default 15 s) prevents alert floods when a tool reads multiple chunks
Synthetic file list	Drop-in XML list of convincing filenames with realistic byte sizes
Single executable	PhantomFS.exe + PhantomFS.exe.config — no installer required

---

Requirements

• Windows 10 version 1809 (Build 17763) or later — Windows 11 recommended
• .NET Framework 4.8
• Windows Projected File System optional feature enabled (Enable-WindowsOptionalFeature -Online -FeatureName Client-ProjFS -NoRestart)
• Administrator privileges to start the virtual root

---

Quick Start

Simple Commands (recommended)

1. Download PhantomFS-v1.1.0-x64.zip from Releases and extract it
2. Run as Administrator — enable ProjFS, Enable-WindowsOptionalFeature -Online -FeatureName Client-ProjFS -NoRestart
3. Execute .\PhantomFS.exe --virtroot C:\PhantomFS\Virtual\Documents --syntheticonly
4. Browse to C:\PhantomFS\Virtual\Documents in Explorer — you will see the decoy files
5. Open one — watch the Toast fire and check Event Viewer → Windows Logs → Application

---

Configuration

All settings live in PhantomFS.exe.config. All keys are optional — omitting a key uses the default shown in the table.

Use the PhantomFS Profile Builder to generate different config profiles for your deployment scenarios:

• https://alloysecuregroup.github.io/PhantomFS/

<settings> Section

<settings>
  <enableEventLog>true</enableEventLog>
  <enableToast>true</enableToast>
  <alertOnOpen>true</alertOnOpen>
  <alertOnRead>true</alertOnRead>
  <toastCooldownSeconds>15</toastCooldownSeconds>
  <verbose>false</verbose>
  <virtRoot></virtRoot>
  <sourceRoot></sourceRoot>
  <syntheticOnly>true</syntheticOnly>

  <!-- v1.1.0 — auto-cleanup -->
  <autoCleanupEnabled>true</autoCleanupEnabled>
  <autoCleanupDelaySeconds>300</autoCleanupDelaySeconds>

  <!-- v1.1.0 — remote session logging -->
  <resolveRemoteIPs>true</resolveRemoteIPs>
</settings>

Key	Default	Since	Description
enableEventLog	true	1.0.0	Write to Windows Application event log
enableToast	true	1.0.0	Send desktop Toast notification
alertOnOpen	true	1.0.0	Alert when a placeholder is first created (directory browse)
alertOnRead	true	1.0.0	Alert when file data is actually read
toastCooldownSeconds	15	1.0.0	Minimum seconds between Toasts for the same file path
verbose	false	1.0.0	Extra console output for diagnostics
virtRoot	(arg 1)	1.0.0	Override virtual root path from config rather than command line
sourceRoot	(empty)	1.0.0	Optional real backing directory — leave empty for synthetic-only mode
syntheticOnly	true	1.0.0	Serve only the files listed in <syntheticFileList>
autoCleanupEnabled	true	1.1.0	Delete materialized synthetic files after the delay and revert to virtual
autoCleanupDelaySeconds	300	1.1.0	Seconds after hydration before the file is deleted (cleanup timer runs every 30 s)
resolveRemoteIPs	true	1.1.0	DNS-resolve the SMB client hostname to an IP address; set to false if lookup latency is unacceptable

Remote Session Logging

When a file is accessed over an SMB share, PhantomFS detects PID 4 (the Windows System process / kernel SMB driver) as the caller and automatically calls NetSessionEnum to identify the remote user. The Event Log entry and Toast notification will include:

PhantomFS — Honeypot File Content Read
File    : Documents\Q4_Financial_Report_2024.pdf
Process : System (PID 4)
Remote  : CORP\jsmith @ DESKTOP-A1B2C3D  [192.168.1.45]

Requirements for remote logging:

• The Server service must be running (it starts automatically whenever a share is active)
• PhantomFS must be running on the machine hosting the share
• resolveRemoteIPs requires the client machine to be resolvable via DNS

Auto-Cleanup Behaviour

After a synthetic file is opened and hydrated (content written to disk), a background timer checks every 30 seconds and deletes files whose hydration time exceeds autoCleanupDelaySeconds. The deleted file reverts to a virtual ProjFS placeholder — the next access re-triggers the ProjFS callback as if the file had never been opened.

Files that are still open when the cleanup timer fires are skipped without error and retried on the next 30-second cycle.

Adding Decoy Files

Add entries under <syntheticFileList> in the config:

\Documents,true,0,1744586986
\Documents\Q4_Financial_Report_2024.pdf,false,8192,1744586986
\Documents\Employee_Salaries_2024.xlsx,false,4096,1743942586
\IT\Keys,true,0,1744586986
\IT\Keys\deploy_key.pem,false,3247,1742354986

Adding Content Templates

<syntheticTemplates>
  <template name="my_custom_file.txt"><![CDATA[
    ... your file content here ...
  ]]></template>
</syntheticTemplates>

---
