أداة تُستخدم لاصطياد الثغرات الأمنية في برامج تشغيل WDM بنية x64
تم تقديمه في CODE BLUE 2023، ويقدم هذا المشروع بعنوان Enhanced Vulnerability Hunting in WDM Drivers with Symbolic Execution and Taint Analysis أداة IOCTLance التي تعزز قدرتها على اكتشاف أنواع مختلفة من الثغرات الأمنية في برامج تشغيل نموذج تشغيل Windows (WDM). في تقييم شامل شمل 104 برنامج تشغيل WDM معروف الثغرات و328 برنامجًا غير معروف، كشفت IOCTLance بنجاح عن 117 ثغرة أمنية غير مكتشفة سابقًا داخل 26 برنامج تشغيل متميز. ونتيجة لذلك، تم الإبلاغ عن 41 CVE، تشمل 25 حالة من رفض الخدمة، و5 حالات من عدم كفاية التحكم في الوصول، و11 مثالًا على رفع الامتيازات.
docker build .
docker run -it <IOCTLance IMAGE ID> bash
dpkg --add-architecture i386
apt-get update
apt-get install git build-essential python3 python3-pip python3-dev htop vim sudo \
openjdk-8-jdk zlib1g:i386 libtinfo5:i386 libstdc++6:i386 libgcc1:i386 \
libc6:i386 libssl-dev nasm binutils-multiarch qtdeclarative5-dev libpixman-1-dev \
libglib2.0-dev debian-archive-keyring debootstrap libtool libreadline-dev cmake \
libffi-dev libxslt1-dev libxml2-dev
pip install angr==9.2.18 ipython==8.5.0 ipdb==0.13.9
# python3 analysis/ioctlance.py -h
usage: ioctlance.py [-h] [-i IOCTLCODE] [-T TOTAL_TIMEOUT] [-t TIMEOUT] [-l LENGTH] [-b BOUND]
[-g GLOBAL_VAR] [-a ADDRESS] [-e EXCLUDE] [-o] [-r] [-c] [-d]
path
positional arguments:
path dir (including subdirectory) or file path to the driver(s) to analyze
optional arguments:
-h, --help show this help message and exit
-i IOCTLCODE, --ioctlcode IOCTLCODE
analyze specified IoControlCode (e.g. 22201c)
-T TOTAL_TIMEOUT, --total_timeout TOTAL_TIMEOUT
total timeout for the whole symbolic execution (default 1200, 0 to unlimited)
-t TIMEOUT, --timeout TIMEOUT
timeout for analyze each IoControlCode (default 40, 0 to unlimited)
-l LENGTH, --length LENGTH
the limit of number of instructions for technique LengthLimiter (default 0, 0
to unlimited)
-b BOUND, --bound BOUND
the bound for technique LoopSeer (default 0, 0 to unlimited)
-g GLOBAL_VAR, --global_var GLOBAL_VAR
symbolize how many bytes in .data section (default 0 hex)
-a ADDRESS, --address ADDRESS
address of ioctl handler to directly start hunting with blank state (e.g.
140005c20)
-e EXCLUDE, --exclude EXCLUDE
exclude function address split with , (e.g. 140005c20,140006c20)
-o, --overwrite overwrite x.sys.json if x.sys has been analyzed (default False)
-r, --recursion do not kill state if detecting recursion (default False)
-c, --complete get complete base state (default False)
-d, --debug print debug info while analyzing (default False)
# python3 evaluation/statistics.py -h
usage: statistics.py [-h] [-w] path
positional arguments:
path target dir or file path
optional arguments:
-h, --help show this help message and exit
-w, --wdm copy the wdm drivers into <path>/wdm
