smt878u-ionstack-poc

[!CAUTION] THIS PROJECT IS UNFINISHED — IT DOES NOT WORK YET. There is no working root on any device as of 2026-10-06. Do not expect the quick-start below to succeed. Read Current status before building or running anything.

[!WARNING] STATUS: WORK IN PROGRESS — ring 1 not landed

• Not achieved: persistent or even one-shot root on SM-T878U.
• Last verified failure: the stack-reclaim payload never reaches the kernel's write path. Across ~470 instrumented runs the forged lock is never observed to be taken at rtmutex.c:585, so the store *(ASHMEM_MISC_FOPS) = fake_fops never executes.
• Former blocker, now resolved: crash forensics used to be unavailable to uid 2000 shell (/proc/kmsg, /proc/last_kmsg, /sys/fs/pstore, dmesg → all EACCES). A durable write()+fsync() log mirror (IONSTACK_LOG_MIRROR) now survives CONFIG_PANIC_ON_OOPS=y, so a panicked run still leaves a complete trail.
• See docs/RTMUTEX_WEAPONIZATION.md §15.16–§15.18 for the full evidence trail.

Pure-C, host-assisted re-root proof of concept for Samsung Galaxy Tab S7 (SM-T878U / gts7l) against CVE-2026-43499 (IonStack / GhostLock).

The runtime chain uses native C/ELF components only. It does not require Python, Java, DEX, app_process, or a JVM on the Android target. ADB is used for deployment and verification.

---

Current status (UNFINISHED)

No root has been obtained. This section is the authoritative, up-to-date account of where the chain stands (last revised 2026-10-06). Everything below is measured on real hardware (SM-T878U, T878USQS8DXE1, kernel 4.19.113-27114284), not theory.

What is proven to work

Stage	Status	Evidence
Target identity + KASLR leak	working	[reroot] LEAK_OK kaslr_base=… task=… (perf side-channel)
CVE trigger: FUTEX_CMP_REQUEUE_PI → -EDEADLK	working	[*] requeue ret=-1 errno=35 — EDEADLK == 35 on Linux
Buggy rollback leaves dangling pi_blocked_on	matches upstream fix	upstream 3bfdc63936dd changes current->pi_blocked_on → waiter->task->pi_blocked_on
struct rt_mutex_waiter layout (4.19)	verified from source	tree_entry@0x00 pi_tree_entry@0x18 task@0x30 lock@0x38 prio@0x40 deadline@0x48
Stack geometry paint == rt_waiter + 0x28	verified 4× incl. objdump	rt_waiter = do_futex_sp+0xC0; address = ___sys_sendmsg_sp+0xB8
Durable crash forensics	working	IONSTACK_LOG_MIRROR write()+fsync() trail survives a panic reboot
Per-message frag-page identity tag	working	reclaim-scan tag=1 sent=8201 range=1..8201 ok=8192 bad=0 dup=0 undecoded=0 absent=9
Queue scan: kernel wrote 0 bytes into 8192 queued frag pages	verified	256 MB compared byte-for-byte against the payload, hits=0
rt_mutex_adjust_prio_chain reaches the write path	verified from disassembly	top_waiter == NULL ⇒ requeue stays true ⇒ 664/682/685/716-725 structurally reachable

What is NOT working

1. The write path never executes. Across ~470 instrumented runs, all 174 page-dump and 45 ring1-page observations report first_diff=8000 (pristine), owner_cpu=00000000, case1_gate=0, and lock_root/lock_leftmost exactly equal to the payload value. The walk has never been seen to take fake_lock->wait_lock at rtmutex.c:585, so 664/682/685/716-725 — the only branch that can store into *(ASHMEM_MISC_FOPS) — has never run. Note that _raw_spin_trylock()/_raw_spin_unlock() route through out-of-line helpers and this vendor tree has no arm64 queued_spin_unlock override, so wait_lock.val == 1 is the reliable 585 witness and owner_cpu != 0 is only a secondary one.
2. The published vehicle is unavailable here. The only public successful exploit of this CVE (NebuSec, IonStack part II) reclaims the frame with prctl(PR_SET_MM, PR_SET_MM_MAP, …). This kernel ships # CONFIG_CHECKPOINT_RESTORE is not set, so that syscall is compiled out. It also never uses sendmsg — our vehicle — which is very likely the root cause of (1).
3. ring1-read has never run. The only userspace read-back of ring 1 (configfs_read_once(fd, data_addr(ASHMEM_MISC_FOPS), …)) sits behind the queue-scan gate and behind the harness MARKER default, which stops 8 s earlier at ring1-page. Every run that reached the gate died between page-dump tag=pre-arm and page-dump tag=post-arm.

Immediate next steps (in priority order)

1. Re-run the one configuration in which 664/682/685 can complete inside our own page — IONSTACK_FOPS_WAIT_LOCK_WORD=0 with IONSTACK_PAINT_WAITER_TASK_MODE=fake-task — and read page-dump tag=post-arm / ring1-lock585 for wait_lock=00000001.
2. Get ring1-read to execute: run with IONSTACK_RECLAIM_SCAN_QUEUE unset and MARKER='ring1-read|…' so the harness does not stop at ring1-page.
3. Identify the held page: run with IONSTACK_RECLAIM_TAG=1 and compare pipe_tag against msg_tag in page-dump. All frag pages are byte-identical copies of the payload, so first_diff alone cannot tell them apart.
4. Re-test the IONSTACK_FOPS_WAIT_LOCK_WORD question on a properly posed basis — wlw=0 vs wlw=1 with IONSTACK_RECLAIM_TAG held constant. The earlier correlation was confounded by the two variables moving together.
5. Port the res_in/res_out pselect6 paint surface from the K40 4.19 port.
6. Only then convert the write primitive into privilege escalation.

Unrelated open bug

fops.c:3157 reason=selinux_write ret=-1 errno=22 EINVAL — still unresolved.

---

Documentation

Document	What
docs/RTMUTEX_WEAPONIZATION.md	Full evidence trail for the rtmutex chain (largest document)
docs/ROOT_CHAIN_THEORY.md	End-to-end ring 0→4 root chain design
docs/PAINT_ORACLE_ANALYSIS.md	Why the stack-paint oracle reads the way it does
docs/PSELECT_GEOMETRY_FINDINGS.md	pselect6 as an alternative paint vehicle
docs/RING1_RECLAIM_IDENTITY_2026-10-06.md	Per-message frag-page identity tag; queue-scan verification
docs/RING1_585_NEVER_SUCCEEDED_2026-10-06.md	Proof that rtmutex.c:585 never succeeded
docs/RING1_ORACLE_FIX_2026-10-05.md	Oracle correction
docs/RING1_ORACLE_WRONG_FRAGMENT_2026-10-06.md	Why the held fragment was mis-identified

---

Target artifacts (for external analysis)

target-artifacts/ carries everything needed to analyze this target without the device:
