austin-taylor/bluewallBluewall — это фреймворк для межсетевого экрана, предназначенный для специалистов по наступательной и оборонительной кибербезопасности.
Bluewall — это фреймворк для межсетевого экрана, предназначенный для специалистов по наступательной и оборонительной кибербезопасности. Данный фреймворк позволяет специалистам по кибербезопасности быстро настроить свою среду, оставаясь в рамках своей зоны ответственности.
Идея вдохновлена скриптом генерации правил iptables hostfw Эндрю Бенсона.
* Настройка межсетевого экрана
* Настройка имени хоста
* Настройка интерфейса(ов)
* Redhat/CentOS
* Конфигурация Windows может быть сгенерирована, но не выполнена.
* bluewall -c config/example.ini
** См. пример конфигурации
* Enumerate — обнаружение живых хостов в вашей сети (скоро)
* Целевой хост — исходящая связь
* Доверенный хост — двунаправленная связь
* No Strike — устройства, с которыми ваш компьютер не должен взаимодействовать
# BUILT FOR PYTHON 2.x
sudo python setup.py install
sudo bluewall -h (for help)
# Setup Initial Environment using Configuration
sudo bluewall -c config/hostconfig.ini
# Export optional windows configuration
sudo bluewall -c config/hostconfig.ini -w autoconfig.ps1
# Add additional inbound host or ranges
sudo bluewall -ih 192.168.0.3,192.168.1.0/24
# Exclude host to communicate with
sudo bluewall -eh 192.168.1.1
# Super easy wizard mode
sudo bluewall --wizard
usage: bluewall [-h] [-V] [-v] [-r] [-p] [-i] [-d] [-w WINDOWS_CONFIG]
[-ot TCP_PORTS_OUT] [-ou UDP_PORTS_OUT] [-it TCP_PORTS_IN]
[-iu UDP_PORTS_IN] [-oh OUTBOUND_HOSTS] [-ih INBOUND_HOSTS]
[-eh EXCLUDE_HOSTS] [-l] [-s] [-q] [-D] [-A] [-F] [-S] [-c CONFIG]
[--info]
/////////////////////////////////////////////////////
| _____ __ _____ _____ _ _ _ _____ __ __ |
| | __ | | | | | __| | | | - | | | | |
| | __-| |__| | | __| | | | | |__| |__ |
| |_____|_____|_____|_____|_____|__|__|_____|_____| |
| |
\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\\
A python framework to automate firewall setup.
Defaults:
Outbound connections will be allowed on all ports to all hosts.
Inbound connections will be limited to related outbound traffic.
DHCP will be enabled.
Ping responses will be enabled.
Unsolicited inbound connections will be dropped.
optional arguments:
-h, --help show this help message and exit
-V, --version Display Version
-v, --verbose Verbose Mode
-r, --reset Send TCP RST instead of dropping packet.
-p, --disallow_ping Disallow incoming PING
-i, --allow_outbound_icmp
Don't restrict ICMP types
-d, --disallow_dhcp Disallow DHCP
-w WINDOWS_CONFIG, --windows_config WINDOWS_CONFIG
Generate Windows Configuration. Usage: bluewall -w
config.ps1
-ot TCP_PORTS_OUT, --tcp_ports_out TCP_PORTS_OUT
Comma separated list of allowed TCP ports outbound
-ou UDP_PORTS_OUT, --udp_ports_out UDP_PORTS_OUT
Comma separated list of allowed UDP ports outbound
-it TCP_PORTS_IN, --tcp_ports_in TCP_PORTS_IN
Comma separated list of allowed TCP ports inbound
-iu UDP_PORTS_IN, --udp_ports_in UDP_PORTS_IN
Comma separated list of allowed UDP ports inbound
-oh OUTBOUND_HOSTS, --outbound_hosts OUTBOUND_HOSTS
Restrict outbound to specified hosts. -oh
192.168.3.0/24,192.168.4.0/24
-ih INBOUND_HOSTS, --inbound_hosts INBOUND_HOSTS
Restrict outbound to specified hosts. -ih
192.168.3.0/24,192.168.4.0/24
-eh EXCLUDE_HOSTS, --exclude_hosts EXCLUDE_HOSTS
Exclude hosts -eh 192.168.3.0/24
-l, --log_exceptions Log Exceptions
-s, --simulate Simulate only.
-q, --quiet Quiet (don't display status messages
-D, --deny_all Absolute Deny all
-A, --allow_all Absolute allow all
-F, --flush Flush IPTables
-S, --show_rules Show rules after setting
--wizard Addressing and firewall wizard mode
-c CONFIG, --config CONFIG
Configuration for firewall
--info About Bluewall
example.ini
[local_config]
iface=em1
rh_host=RHEL-Example
rh_ipaddr=192.168.1.42
netmask=255.255.255.0
gateway_addr=172.16.63.1
dns=8.8.8.8
#win_ipaddr=192.168.1.42 - Optional windows IP Address
#
# Optional Windows host (Bluewall will generate a config file for windows)
win_host=WINExample
# MAC Addresses must be ALL CAPS Valid: AA:93:AB:EF:00:01
# rh_mac=* will generate random MAC address
rh_mac=*
[firewall_config]
# Target Range are networks you want to allow outbound communication with.
target_range=172.16.63.0/24
target_range=192.168.2.0/24
#
# Nostrike addresses are devices your computer should NOT communicate with
nostrike=192.168.2.1
#
# Trusted Range are networks you wish to have bi-directional communication with
trusted_range=172.16.63.0/24
trusted_host=42.42.42.42
[ataylor@localhost bluewall]$ sudo bluewall -c configs/exampleconfig.ini
[OK] 192.168.1.101 is a valid setting for dns
[OK] 192.168.1.1 is a valid setting for gateway_addr
[OK] 24 is a valid setting for cidr_prefix
[OK] 192.168.1.254 is a valid setting for nostrike
[OK] * is a valid setting for rh_mac
[OK] WINtaylor is a valid setting for win_host
[OK] 192.168.2.0/24 is a valid setting for target_range
[OK] 192.168.3.0/24 is a valid setting for target_range
[OK] 192.168.1.30 is a valid setting for rh_ipaddr
[OK] RHEL-taylor is a valid setting for rh_host
[OK] 42.42.42.42 is a valid setting for trusted_host
[OK] 192.168.1.0/24 is a valid setting for trusted_range
[OK] 192.168.1.50 is a valid setting for win_ipaddr
==============================
[VALID CONFIG] No Errors Detected.
CONFIGURING
writing eth config to /etc/sysconfig/network-scripts/ifcfg-ens33
[CONFIGURATION]
TYPE="Ethernet"
BOOTPROTO=none
NAME=ens33
DEVICE="ens33"
ONBOOT=no
DEFROUTE="yes"
IPV4_FAILURE_FATAL=no
DNS1=192.168.1.101
IPADDR=192.168.1.30
PREFIX=24
GATEWAY=192.168.1.1
MACADDR=00:16:3E:52:7F:8D
[+] Interface ens33 shutdown.
[+] Restarting Network Service
[+] Interface ens33 brought up.
[+] Rules Flushed!
[+] Allowing outbound ICMP/traceroute to 192.168.2.0/24...
[+] Allowing outbound ICMP/traceroute to 192.168.3.0/24...
[+] Allowing outbound ICMP/traceroute to 192.168.1.0/24...
[+] Limiting outbound TCP connections to 192.168.2.0/24.
[+] Limiting outbound TCP connections to 192.168.3.0/24.
[+] Limiting outbound TCP connections to 192.168.1.0/24.
[+] Limiting outbound UDP connections to 192.168.2.0/24.
[+] Limiting outbound UDP connections to 192.168.3.0/24.
[+] Limiting outbound UDP connections to 192.168.1.0/24.
[+] Limiting inbound UDP connections to 192.168.1.0/24.
[+] Limiting inbound TCP connections to 192.168.1.0/24.
[+] Allowing traffic for localhost.
[+] 192.168.1.254 applied to NOSTRIKE
$ iptables -nvL
Chain INPUT (policy DROP 0 packets, 0 bytes)
pkts bytes target prot opt in out source destination
0 0 DROP all -- * * 192.168.1.254 0.0.0.0/0
0 0 ACCEPT all -- * * 127.0.0.0/8 127.0.0.0/8
0 0 ACCEPT tcp -- * * 0.0.0.0/0 192.168.1.0/24
0 0 ACCEPT udp -- * * 0.0.0.0/0 192.168.1.0/24
Chain FORWARD (policy DROP 0 packets, 0 bytes)
pkts bytes target prot opt in out source destination
Chain OUTPUT (policy DROP 0 packets, 0 bytes)
pkts bytes target prot opt in out source destination
0 0 DROP all -- * * 0.0.0.0/0 192.168.1.254
0 0 ACCEPT all -- * * 127.0.0.0/8 127.0.0.0/8
0 0 ACCEPT udp -- * * 0.0.0.0/0 192.168.1.0/24
0 0 ACCEPT udp -- * * 0.0.0.0/0 192.168.3.0/24
0 0 ACCEPT udp -- * * 0.0.0.0/0 192.168.2.0/24
0 0 ACCEPT tcp -- * * 0.0.0.0/0 192.168.1.0/24
0 0 ACCEPT tcp -- * * 0.0.0.0/0 192.168.3.0/24
0 0 ACCEPT tcp -- * * 0.0.0.0/0 192.168.2.0/24
0 0 ACCEPT icmp -- * * 0.0.0.0/0 192.168.1.0/24 icmptype 0
0 0 ACCEPT icmp -- * * 0.0.0.0/0 192.168.1.0/24 icmptype 8
0 0 ACCEPT icmp -- * * 0.0.0.0/0 192.168.3.0/24 icmptype 0
0 0 ACCEPT icmp -- * * 0.0.0.0/0 192.168.3.0/24 icmptype 8
0 0 ACCEPT icmp -- * * 0.0.0.0/0 192.168.2.0/24 icmptype 0
0 0 ACCEPT icmp -- * * 0.0.0.0/0 192.168.2.0/24 icmptype 8
[+] Setup Complete.
