anthropics/cryptography-research-demoReproducible cryptanalysis artifacts for single-key recovery attacks on reduced-round AES, including black-box key recovery, DDT-Gray search, S-box caches, and Lean formal proofs.
Source code for every experiment quoted in the paper. No measurement output or prebuilt table is bundled: each program prints or writes its own results, so every number can be regenerated from scratch.
| directory | what it is |
|---|---|
experiments/ | the two experiments behind the Measured costs appendix: the complete black-box key recovery on SR(7,2,2,6), and the per-entry / per-candidate measurements of the real 7-round AES-128 attack |
c/ | standalone C programs, one per component claim (bridge, fingerprints, DDT-Gray walk, S-box caches, wrong-key randomisation, lookup floor) |
python/ | Python single-claim checks and the pedagogical reference implementation of the attack layers (python/a1/) |
rust/ | a second, independent implementation of the component experiments (e1–e13) |
figures/ | plotting scripts that consume the TSVs written by the C programs |
lean/ | Lean 4 + Mathlib formalization of the χ★ false-positive counting bound (lean/chi-fp/, paper §5.5) |
The paper's key-recovery claims rest on experiments/; c/, python/ and
rust/ check the individual components (identities, invariances, DDT
facts, cache correctness, randomisation statistics) and are not attacks.
experiments/See experiments/README.md.
sr7226-e2e/ — complete, black-box key recovery on AES SR(7,2,2,6)
(2x2 state, 6-bit words, 24-bit key) with the full offline table, for
three variants on one code base: ours, Derbez–Fouque–Jean with our
table-enumeration optimizations, and Derbez–Fouque–Jean as published.aes128-measured/ — the real 7-round AES-128 attack one unit at a time:
genuine offline table entries (partial table), cycles per online
candidate for the three variants, the AES denominators, the ordered
fingerprint's false-positive and coverage rates, and the projection to
the full count.c/Single-file or self-contained per directory; build with
gcc -O3 -march=native -fopenmp -o <bin> <file.c> -lm (add the directory
as -I where a local header is used). Usage is documented in the header
comment of each file.
python/Python 3. python/a1/ is standard library only; the top-level test
scripts, figures/, and experiments/aes128-measured/phi/ need
numpy, scipy, and matplotlib (pip install -r requirements.txt,
exact versions verified). python/a1/README.md describes the
layered reference implementation (gf256.py, aes7r.py, chi_canon.py,
prop2.py, the golden vectors in test_vectors.py). Top-level scripts are
single-claim checks: bridge invariants (test_invariants.py,
), the bridge on real AES traces (),
edge behaviour (), wrong-key randomisation
(), clumping / collision entropy (),
the key-schedule inversion behind CompleteKey (), and
the fingerprint-prefix false-positive demo ().
rust/cargo build --release, then ./target/release/repro <exp> [args]; each
run appends a timestamped block under rust/results/. The experiment
list and what each one checks is in rust/src/main.rs: e1–e13 cover the
bridge identity, group and coset facts, the honest bridge on real AES-128
traces, wrong-key randomisation, collision entropy, χ★ invariance, the DDT
spectrum, AES sanity, per-entry timing, and the SR(7,4,4,4) pipeline.
| path | checks | paper location |
|---|
clump.c, chi_clump.c | collision entropy of the I_{m,n} and χ★ fingerprints | fingerprint properties; app. collision entropy |
wrongkey.c | wrong-key randomisation, exhaustive 2^32 sweep of k_6 | app. wrong-key randomisation |
fp_solve.c | DDT solving and branch-bit enumeration used by the table construction | §DDT-Gray |
bridge-consistency/bc_impl_{a,b}.c, bc_truehit.c | two independent implementations of the bridge-consistency false-accept statistic | Alg. BridgeConsistency |
ddt-gray/ddt_gray_*.c | DDT-aware Gray walk: incremental equals cold recomputation, amortised S-box cost, timing | §DDT-Gray, app. DDT-Gray |
sb-cache/sbc_repro.c | XOR-separability behind the W / UU S-box caches; c_iSB closed form | §S-box caches |
mobius-honest/honest_online.c | the online side with |K_on| = 8: the δ-set rebuilt from k_{-1} only, and the wrong-key survivor rate | §component lemmas |
mobius-honest/honest_rebound.c, degen_analysis.c, saes_imn.c | pipeline checks of the offline rebound and of I_{m,n} matching on small-scale AES; known-key shortcuts are documented in each header — these are pipeline checks, not key recoveries | §component lemmas, app. degenerate cases |
floor/verify_ls_fp.c, floor/verify_incompat.c, floor/a1_floor.py | the lookup floor for |K_on| = 8: dim LS(fp) ∈ {0,8} and T ≥ 2^88.67 | app. lower bound |
verify_Imn.pytest_bridge_aes.py0^{-1}test_zeroinv.pytest_wrongkey.pytest_clumping*.pykeysched_solve.pyfp_concat_demo.py
