LLM4Decompile

git clone https://github.com/albertan017/LLM4Decompile.git
cd LLM4Decompile
conda create -n 'llm4decompile' python=3.9 -y
conda activate llm4decompile
pip install -r requirements.txt

import subprocess
import os
func_name = 'func0'
OPT = ["O0", "O1", "O2", "O3"]
fileName = 'samples/sample' #'path/to/file'
for opt_state in OPT:
    output_file = fileName +'_' + opt_state
    input_file = fileName+'.c'
    compile_command = f'gcc -o {output_file}.o {input_file} -{opt_state} -lm'#compile the code with GCC on Linux
    subprocess.run(compile_command, shell=True, check=True)
    compile_command = f'objdump -d {output_file}.o > {output_file}.s'#disassemble the binary file into assembly instructions
    subprocess.run(compile_command, shell=True, check=True)

    input_asm = ''
    with open(output_file+'.s') as f:#asm file
        asm= f.read()
        if '<'+func_name+'>:' not in asm: #IMPORTANT replace func0 with the function name
            raise ValueError("compile fails")
        asm = '<'+func_name+'>:' + asm.split('<'+func_name+'>:')[-1].split('\n\n')[0] #IMPORTANT replace func0 with the function name
        asm_clean = ""
        asm_sp = asm.split("\n")
        for tmp in asm_sp:
            if len(tmp.split("\t"))<3 and '00' in tmp:
                continue
            idx = min(
                len(tmp.split("\t")) - 1, 2
            )
            tmp_asm = "\t".join(tmp.split("\t")[idx:])  # remove the binary code
            tmp_asm = tmp_asm.split("#")[0].strip()  # remove the comments
            asm_clean += tmp_asm + "\n"
    input_asm = asm_clean.strip()
    before = f"# This is the assembly code:\n"#prompt
    after = "\n# What is the source code?\n"#prompt
    input_asm_prompt = before+input_asm.strip()+after
    with open(fileName +'_' + opt_state +'.asm','w',encoding='utf-8') as f:
        f.write(input_asm_prompt)

<func0>:
endbr64
lea    (%rdi,%rsi,1),%eax
retq

from transformers import AutoTokenizer, AutoModelForCausalLM
import torch

model_path = 'LLM4Binary/llm4decompile-6.7b-v1.5' # V1.5 Model
tokenizer = AutoTokenizer.from_pretrained(model_path)
model = AutoModelForCausalLM.from_pretrained(model_path,torch_dtype=torch.bfloat16).cuda()

with open(fileName +'_' + OPT[0] +'.asm','r') as f:#optimization level O0
    asm_func = f.read()
inputs = tokenizer(asm_func, return_tensors="pt").to(model.device)
with torch.no_grad():
    outputs = model.generate(**inputs, max_new_tokens=2048)### max length to 4096, max new tokens should be below the range
c_func_decompile = tokenizer.decode(outputs[0][len(inputs[0]):-1])

with open(fileName +'.c','r') as f:#original file
    func = f.read()

print(f'original function:\n{func}')# Note we only decompile one function, where the original file may contain multiple functions
print(f'decompiled function:\n{c_func_decompile}')

# build docker
docker build -t llm4decompile .

# run docker with GPU
docker run --gpus all -it --name llm4decompile llm4decompile /bin/bash

# run demo.py (choose a model suitable for your resources before running)
cd ghidra
python demo.py

@misc{tan2024llm4decompile,
      title={LLM4Decompile: Decompiling Binary Code with Large Language Models},
      author={Hanzhuo Tan and Qi Luo and Jing Li and Yuqun Zhang},
      year={2024},
      eprint={2403.05286},
      archivePrefix={arXiv},
      primaryClass={cs.PL}
}
