CVE-2026-40003

v0 = MEMORY[0x13B004] & 7; // हार्डवेयर पिन
switch ( (char)v0 )
{
  case 0:
    if ( nand_init() )
      goto LABEL_12;
    parse_header((Header *)0x8A000);
    v4 = "\nMODE:NAND\n";
    goto LABEL_11;
  case 1:
    if ( !nand_init() )
    {
      parse_header((Header *)0x8A000);
      uart_puts("\nMODE:USB-N\n");
    }
    usbdl_init(0x1500000);
    v5 = "TURN TO NAND\n";
    goto LABEL_16;
/* ... */
LABEL_16:
  uart_puts(v5);
LABEL_7:
  verify_and_jump((Header *)0x8A000, 0, 1);
  break;

void __fastcall usbdl_init(int usb_base)
{
  char *v1; // r0

  if ( usb_base == 0x1500000 )
  {
    alt_usb_base = 0;
    usb_init();
  }
  else
  {
    alt_usb_base = 1;
    noidea();
  }
  if ( usb_setup() )
  {
    try_sync_with_host();
    v1 = "FAILED\n";
  }
  else
  {
    v1 = "\nNOLINK\n";
  }
  uart_puts(v1);
}

ROM:00001F68 ; void __fastcall usbdl_init(int usb_base)
ROM:00001F68 usbdl_init                              ; CODE XREF: entry+5E↑p
ROM:00001F68                                         ; entry+7C↑p ...
ROM:00001F68                 PUSH            {R4,LR}
ROM:00001F6A                 MOVS            R2, #0x1500000
ROM:00001F6E                 LDR             R1, =dword_8014C
ROM:00001F70                 MOV             R4, R0
ROM:00001F72                 CMP             R0, R2
ROM:00001F74                 BNE             loc_1F80
ROM:00001F76                 MOVS            R0, #0
ROM:00001F78                 STRB            R0, [R1,#(alt_usb_base - 0x8014C)]
ROM:00001F7A                 BL              usb_init
ROM:00001F7E                 B               loc_1F88
ROM:00001F80 ; ---------------------------------------------------------------------------
ROM:00001F80
ROM:00001F80 loc_1F80                                ; CODE XREF: usbdl_init+C↑j
ROM:00001F80                 MOVS            R0, #1
ROM:00001F82                 STRB            R0, [R1,#(alt_usb_base - 0x8014C)]
ROM:00001F84                 BL              noidea
ROM:00001F88
ROM:00001F88 loc_1F88                                ; CODE XREF: usbdl_init+16↑j
ROM:00001F88                 MOV             R0, R4
ROM:00001F8A                 BL              usb_setup
ROM:00001F8E                 CMP             R0, #0
ROM:00001F90                 BEQ             loc_1F9E
ROM:00001F92                 BL              try_sync_with_host
ROM:00001F96                 ADR             R0, aFailed ; "FAILED\n"
ROM:00001F98
ROM:00001F98 loc_1F98                                ; CODE XREF: usbdl_init+38↓j
ROM:00001F98                 BL              uart_puts
ROM:00001F9C                 POP             {R4,PC}
ROM:00001F9E ; ---------------------------------------------------------------------------
ROM:00001F9E
ROM:00001F9E loc_1F9E                                ; CODE XREF: usbdl_init+28↑j
ROM:00001F9E                 ADR             R0, aNolink ; "\nNOLINK\n"
ROM:00001FA0                 B               loc_1F98
ROM:00001FA0 ; End of function usbdl_init

void try_sync_with_host()
{
  int v0; // r4
  unsigned int i; // r0
  int v2; // r5
  int v3; // r2
  int v4; // r3
  int v5; // r2
  int v6; // r3
  int v7; // r0

  v0 = 0x805A0;
  time_to_boot = 0;
  for ( i = 0; i < 0x40; ++i )
    *(_BYTE *)(i + 0x805A0) = 0;
  g_state = 0;
  v2 = 0x200;
  if ( usb_recv(byte_805A0, 0x200, 0x5A) == 1 ) // 0x5a = होस्ट द्वारा भेजा गया ack
  {
    uart_puts("TIMEOUT\n");
  }
  else
  {
    resp[0] = 0xA5;
    usb_send((int)resp, 1, v3, v4);
    g_state = 1;
    while ( !time_to_boot )
    {
      v7 = sub_11CA(v0, v2, v5, v6);
      handler(v0, v7);
      if ( g_state == 4 )
      {
        v2 = size;
        v0 = start_addr;
      }
      else
      {
        v0 = 0x805A0;
        v2 = 0x200;
      }
    }
    verify_and_jump(unk_80160, 0, 1);
  }
}

usb_send:
        resp[0] = status;
        v5 = 1;
        v6 = resp;
        return usb_send((int)v6, v5, state, v3);
      case 3u: // 0x7A
        if ( *(int *)&resp[4] >= 4 )
        {
          if ( *(int *)&resp[4] < 8 )
            *(_DWORD *)&resp[12] = (*(_DWORD *)&resp[12] << 8) | result;
        }
        else
        {
          *(_DWORD *)&resp[8] = (*(_DWORD *)&resp[8] << 8) | result;
        }
        v3 = *(_DWORD *)&resp[4] + 1;
        *(_DWORD *)&resp[4] = v3;
        if ( v3 != 8 )
          continue;
        *(_DWORD *)&resp[4] = 0;
        start_addr = *(_DWORD *)&resp[8];
        size = *(_DWORD *)&resp[12];
        g_state = 4;
        status = 0xA1;
        goto usb_send;

int __fastcall verify_and_jump(Header *a1, int zero, int must_verify)
{
  int *p_sp; // r6
  int result; // r0

  p_sp = (int *)&a1->sp;
  result = memcmp((int)a1->magic, 0x80008, 2u);
  if ( !result )
  {
    if ( !zero || (result = a1->usbdl_en, result == 0x5A) )
    {
      if ( !must_verify )
        return jump(p_sp);
      result = verify(a1);
      if ( !result )
        return jump(p_sp);
    }
  }
  return result;
}
