swSIM

Project needs to be cloned recursively. Downloading the ZIP is not enough.

swSIM is an all-software SIM card. It's the first publicly available (to the best of my knowledge) SIM card simulator which does not rely on any SIM hardware to work.

Scope

• A software-only SIM card simulator.
• It does NOT depend on any hardware to work.
• Can connect to the PC via PC/SC using the swICC PC/SC reader.
• The PC/SC interface allows it to connect to ANY phone with a SIM card slot. We used the SIMtrace 2 device running on the cardem firmware but any other tool which forwards messages to and from the phone would work as well.

Install

• You need make and gcc to compile the project. No extra runtime dependencies.

1. sudo apt-get install make gcc
2. git clone --recurse-submodules [email protected]:tomasz-lisowski/swsim.git
3. cd swsim
4. make main-dbg (for more info on building, take a look at ./doc/install.md).

Usage

1. Start a swICC card server, e.g., swICC PC/SC reader.
2. ./build/swsim.elf --ip 127.0.0.1 --port 37324 --fs filesystem.swiccfs --fs-gen ./data/usim.json
3. pcsc_scan (part of the pcsc-tools package) will show some details of the card.
4. You can interact with the card as you would with a real card attached to a hardware card reader.
