Root Cause

JATO serializes UI view state to HTTP parameters named jato.pageSession and jato.clientSession. When a request arrives, OpenAM deserializes these parameters to restore UI state before rendering the response. The two parameters follow entirely different code paths.

The patched code path (post-CVE-2021-35464) for jato.pageSession:

// PATCHED - ConsoleViewBeanBase.deserializePageAttributes()
ObjectInputStream ois = new WhitelistObjectInputStream(new ByteArrayInputStream(decoded));
// class whitelist enforced - gadget chains blocked
Object obj = ois.readObject();

The unpatched code path for jato.clientSession (vulnerable):

// ClientSession.java
protected ClientSession(RequestContext context) {
	this.encodedSessionString =
		context.getRequest().getParameter("jato.clientSession");
}

protected void deserializeAttributes() {
	if (this.encodedSessionString != null
		&& this.encodedSessionString.trim().length() > 0) {
		this.setAttributes(
			(Map) Encoder.deserialize(
				// VULNERABLE - URL-safe base64 decode then plain ObjectInputStream
				Encoder.decodeHttp64(this.encodedSessionString), false)
		);
	}
}

Encoder.deserialize() constructs a plain ApplicationObjectInputStream - a subclass of ObjectInputStream with no class filtering. Any class on the JVM classpath can be instantiated. Deserialization is triggered during JSP rendering whenever a < jato:form > tag is rendered:

getClientSession() → hasAttributes() → getEncodedString() → isValid() → ensureAttributes() → deserializeAttributes()
