KcMapper

KcMapper is a tool for exporting Keycloak configuration data into a Neo4j graph database. This representation allows for the analysis of relationships between realms, clients, users, groups, and roles. The tool includes a web interface to run pre-defined Cypher queries for analysis and security auditing.

Features

• Complete Export: Extracts realms, clients, roles (including composites), groups (with hierarchy), users, client scopes, mappers, and authentication flows.
• Graph Modeling: Represents the Keycloak configuration as a graph in Neo4j.
• Interactive Analysis: Provides a local web interface to execute pre-defined analysis queries on the exported data.
• Security Auditing: Includes queries to help identify potentially weak security configurations.
• Extendable: Custom analysis queries can be added by modifying the webapp/queries.json file.

Installation and Usage

This guide covers the local installation of KcMapper. This method requires you to install Python and Neo4j on your machine.

Prerequisites

• Python 3.9+
• A running Neo4j instance (Community or Desktop).

Neo4j Installation (Example for Debian/Ubuntu)

You can install Neo4j Community Edition by following these steps:

# Add the Neo4j GPG key
wget -O - https://debian.neo4j.com/neotechnology.gpg.key | sudo apt-key add -

# Add the Neo4j repository
echo 'deb https://debian.neo4j.com stable 5' | sudo tee /etc/apt/sources.list.d/neo4j.list

# Update packages and install Neo4j
sudo apt-get update
sudo apt-get install neo4j -y

# Start the Neo4j service
sudo systemctl start neo4j

After installation, navigate to http://localhost:7474 in your browser and set the initial password (the default is neo4j/neo4j).

For other systems (Windows, macOS, etc.):

• Neo4j Desktop: This is the simplest option. Download and install Neo4j Desktop, which provides a graphical interface for managing your databases.
• Other Linux Installations: Follow the official instructions on the Neo4j installation page.

Configuration

1. Clone the repository

   root@kitploit:~

   git clone https://github.com/synacktiv/kcmapper.git
   cd kcmapper


2. Set up a Python virtual environment (recommended)

   root@kitploit:~

   python -m venv venv
   source venv/bin/activate  # On Windows, use `venv\Scripts\activate`


3. Install dependencies

   root@kitploit:~

   pip install -r requirements.txt


4. Configure environment variables Copy the .env.example file to .env.

   root@kitploit:~

   cp .env.example .env


   Modify the .env file to point to your Keycloak instance and your local Neo4j database.

   root@kitploit:~

   # --- Keycloak Connection ---
   KEYCLOAK_URL=http://your-keycloak-server:8080/
   KEYCLOAK_USER=admin
   KEYCLOAK_PASSWORD=your_keycloak_admin_password
   # Optional - for confidential clients
   KEYCLOAK_CLIENT_SECRET=
   # Optional - for users with 2FA enabled
   KEYCLOAK_TOTP=
   # Optional - for mTLS authentication
   KEYCLOAK_CERT_PATH=

   # --- Neo4j Connection (for local environment) ---
   NEO4J_URI=bolt://localhost:7687
   NEO4J_USER=neo4j
   NEO4J_PASSWORD=your_local_neo4j_password


Usage

1. Export Data Run the export command to populate your Neo4j database.

   root@kitploit:~

   python kcmapper_cli.py export


   • To clean the database before a new export, use the --clean option:
     root@kitploit:~

     python kcmapper_cli.py export --clean


2. Analyze Data Once the export is complete, launch the web analysis interface.

   root@kitploit:~

   python kcmapper_cli.py analyze


   • The server will be accessible by default at http://127.0.0.1:5001.

Architecture

• kcmapper_cli.py: Main command-line entry point.
• /processors: Contains the extraction and loading logic for each Keycloak object type.
• /utils: Utility functions, primarily for Neo4j connection and data cleaning.
• /webapp: Contains the Flask web application for data analysis.

Contributing

Contributions are welcome. Please feel free to open an issue to report a bug or suggest a new feature. To add new analysis queries, modify the webapp/queries.json file and submit a pull request.

License

This project is licensed under the MIT License. See the LICENSE file for details.
