CVE-2025-8045 — Arm Mali GPU KCPU Queue UAF

A local privilege escalation exploit for CVE-2025-8045, a use-after-free in the Arm Mali GPU kernel driver (kbase). A non-privileged local process races the CSF KCPU queue dump path to free and reclaim a cpu_queue.buffer, turns the dangling allocation into a page table it owns ("dirty pagetable"), and uses that primitive to gain arbitrary kernel physical read/write — ending in a root shell with SELinux set permissive.

Exploited on Pixel 7 Pro (build BP3A.250905.014). The hardcoded offsets in exploit.c are calibrated for this target; other devices/builds need the offsets re-derived (see Tuning & portability).

The vulnerability

CVE-2025-8045 is a use-after-free in the Arm Valhall and 5th Gen GPU Architecture kernel drivers (r53p0–r54p1). A local, unprivileged process can drive GPU processing operations in a way that leaves the driver operating on already-freed memory, opening the door to kernel memory disclosure, corruption, and code execution.

This exploit reaches the bug through the CSF KCPU queue interface exposed by /dev/mali0:

• A KCPU queue is armed with an unsatisfiable CQS_WAIT followed by a FENCE_SIGNAL. The wait stalls the queue so the fence timer fires later, on a predictable timer-wheel bucket boundary.
• KBASE_IOCTL_CS_CPU_QUEUE_DUMP drives kbase_csf_cpu_queue_dump_buffer(). Racing the queue's state transition (ISSUED → COMPLETE/PENDING) against the dump path frees cpu_queue.buffer while it is still referenced — the UAF.

The exploit is a timing exploit: it first calibrates the deadline, then predicts it every round and fires a "wave" of harmless dump calls to widen the race window around the moment of the free.

Exploitation strategy

Because one page ends up being both a Mali allocation and a live CPU page table, the process parks forever instead of exiting — freeing it would be a double-free and panic the kernel.

Build

# Android / arm64 (NDK)
aarch64-linux-android31-clang -O2 -o exploit exploit.c

Run

./exploit

On success you get a root shell (uid=0) with SELinux permissive. Sample flow:

[*] pid=...  cpus=8  wave=64  harvest cpu=7  rounds=256
[*] round  1  calibrate  deadline t0+... ms  phase ... ms
[*] round  N  read +... us
[+] UAF page: spray region R page P @ ..., 1 live descriptor
[+] entry 0 = ... -- a CPU page table, writable through the GPU
[+] alias: dirty pagetable
[+] selinux_state.enforcing = 0 @ phys ...
[+] sel_read_enforce patched @ phys ...
[+] root shell: uid=0 euid=0

If it runs all rounds without a win, cpu_queue.c:71 in dmesg indicates the race is landing but the reclaim missed — tune the reclaim/wave parameters.

Tuning & portability

The values in exploit.c are calibrated for the Pixel 7 Pro, build BP3A.250905.014. Offsets and constants are device/kernel-specific and must be re-derived for any other target:

• KERNEL_PA_BASE, SEL_READ_ENFORCE, INIT_CRED, COMMIT_CREDS, SELINUX_STATE — kernel symbol/physical offsets.
• ARM64_PTE_FLAGS — last-level descriptor template for the target MMU config.
• WAVE_*, SWEEP_*, BUCKET_NS, WAIT_NS, spray sizes — race timing and heap-grooming knobs.

Affected versions

• Arm Valhall GPU Kernel Driver: r53p0 – r54p1
• Arm 5th Gen GPU Architecture Kernel Driver: r53p0 – r54p1

Update to the fixed driver release from Arm to remediate.

Disclaimer

This code is published strictly for defensive security research, detection engineering, and education. Do not run it against systems you do not own or lack explicit written authorization to test. The author accepts no liability for misuse or for any damage caused. Using it against systems without permission is illegal.
