CVE-2025-69420 — OpenSSL TimeStamp Response type confusion PoC

Crash-only laboratory reproducer for CVE-2025-69420 in OpenSSL. The PoC loads a valid RFC 3161 TimeStamp Response, changes the signed ESS attribute from V_ASN1_SEQUENCE to V_ASN1_NULL in memory, and calls TS_RESP_verify_response().

On an affected build, ossl_ess_get_signing_cert_v2() or ossl_ess_get_signing_cert() accesses the ASN1_TYPE union as a sequence without validating the active type. UBSan reports member access through a null ASN1_STRING pointer. The expected impact is process termination / denial of service; this repository contains no code-execution logic.

Confirmed result

The supplied test output confirms the issue:

runtime error: member access within null pointer of type 'struct ASN1_STRING'
#0 ossl_ess_get_signing_cert_v2
#1 ts_check_signing_certs
#2 TS_RESP_verify_signature
#3 int_ts_RESP_verify_token
#4 TS_RESP_verify_response

This matches the vulnerability description: a malformed TimeStamp Response reaches TS_RESP_verify_response(), and an ESS signing-certificate attribute of a type other than V_ASN1_SEQUENCE causes an invalid or NULL pointer dereference.

Scope

Test only in an isolated environment against an OpenSSL build you own or are authorized to assess. This is a crash-only reproducer.

Requirements

• Linux and GCC
• OpenSSL affected build compiled with ASan and UBSan
• OpenSSL development headers in the build tree

Default build path:

/path/to/openssl-3.0.7-asan

Override it when needed:

export OPENSSL_BUILD=/path/to/openssl-asan-build

Usage

git clone https://github.com/Kha-Beleh/PoC-CVE-2025-69420.git
cd PoC-CVE-2025-69420

export OPENSSL_BUILD=/path/to/openssl-3.0.7-asan
make prepare
make build
make run

Or run everything separately:

./scripts/prepare.sh
./scripts/build.sh
./scripts/run.sh

prepare.sh uses the repository's minimal openssl.cnf, so it does not depend on a missing $OPENSSL_BUILD/ssl/openssl.cnf.

Expected output on an affected build

[+] Loaded valid TimeStamp Response
[+] Found attribute: id-smime-aa-signingCertificateV2
[+] Original ASN.1 type: 16
[+] Attribute changed to V_ASN1_NULL
[+] Calling TS_RESP_verify_response()
crypto/ts/ts_rsp_verify.c:...: runtime error: member access within null pointer of type 'struct ASN1_STRING'
    #0 ... in ossl_ess_get_signing_cert_v2
    #1 ... in ts_check_signing_certs
    #2 ... in TS_RESP_verify_signature
    #3 ... in int_ts_RESP_verify_token
    #4 ... in TS_RESP_verify_response

The exact addresses and line numbers vary by build. With UBSAN_OPTIONS=halt_on_error=1, the process terminates at the first detected undefined operation.

Expected result on a fixed build

The malformed attribute should be rejected cleanly without a sanitizer finding or process crash. The PoC then prints:

[+] Malformed response rejected without a crash

Technical interpretation

The original attribute type value 16 is V_ASN1_SEQUENCE. The PoC changes it to V_ASN1_NULL. In the affected implementation, the code subsequently treats the union member as value.sequence and dereferences it. Because the active member is not a sequence, UBSan detects member access through a null ASN1_STRING *.

This is a type-confusion / missing exceptional-condition check rather than a heap or stack buffer overflow.

Files

• poc.c — minimal reproducer
• scripts/prepare.sh — generates TSA key, certificate, request and valid response
• scripts/build.sh — compiles against the ASan/UBSan OpenSSL build
• scripts/run.sh — runs with sanitizer settings
• openssl.cnf — minimal provider/request configuration
• tsa.conf — local RFC 3161 TSA configuration
• evidence/confirmed-output.txt — shortened confirmed sanitizer trace

References

• NVD: CVE-2025-69420
• OpenSSL fix: commit 4e254b48ad93cc092be3dd62d97015f33f73133a
