RawrXD PE Writer - Complete Implementation

Overview

This is a complete PE32+ writer and machine code emitter implemented in pure x64 MASM assembly with zero dependencies and no CRT usage. It generates runnable Windows executables from scratch.

Architecture

The PE writer follows a backend designer approach, providing a clean API for:

• Creating PE executable contexts
• Adding imports with proper IAT/INT structures
• Emitting machine code with section management
• Writing complete PE files with all required headers

Core Components

1. Structures Defined

• IMAGE_DOS_HEADER: Standard DOS header with e_lfanew pointer
• IMAGE_NT_HEADERS64: NT headers with file header and optional header
• IMAGE_SECTION_HEADER: Section headers for .text, .rdata, .idata
• IMAGE_IMPORT_DESCRIPTOR: Import table descriptors
• PE_CONTEXT: Internal context structure for building PE files

2. Key Functions

PEWriter_CreateExecutable

• Input: RCX = image base (0 = default), RDX = entry point RVA
• Output: RAX = PE context handle (0 = failure)
• Purpose: Allocates and initializes complete PE context structure

Implementation Details:

• Allocates memory for DOS header, NT headers, section headers
• Initializes DOS header with proper signature and e_lfanew
• Sets up NT headers with AMD64 machine type and PE32+ magic
• Configures optional header with image base, section/file alignment
• Allocates code buffer and import tables
• Sets default virtual addresses and file offsets

PEWriter_AddImport

• Input: RCX = PE context, RDX = DLL name, R8 = function name
• Output: RAX = 1 success, 0 failure
• Purpose: Builds import table with proper IAT/INT structures

Implementation Details:

• Manages import descriptors for multiple DLLs
• Creates import lookup table (INT) entries
• Sets up import address table (IAT) entries
• Handles import by name structures
• Tracks import count and validates limits

PEWriter_AddCode

• Input: RCX = PE context, RDX = code buffer, R8 = code size
• Output: RAX = RVA of code (0 = failure)
• Purpose: Handles machine code emission with proper section management

Implementation Details:

• Copies machine code to internal buffer
• Validates code size against maximum limits
• Calculates and returns RVA for the code
• Updates internal code size tracking
• Manages .text section content

PEWriter_WriteFile

• Input: RCX = PE context, RDX = filename
• Output: RAX = 1 success, 0 failure
• Purpose: Complete file writing with all headers, sections, and import table

Implementation Details:

• Creates output file with proper Win32 API calls
• Writes DOS header and DOS stub
• Calculates and updates final NT header values
• Writes section headers for .text, .rdata, .idata
• Implements proper file padding and alignment
• Writes section data with import table
• Handles all RVA calculations and file offsets

Memory Management

The implementation uses Windows heap APIs:

• GetProcessHeap(): Gets current process heap
• HeapAlloc(): Allocates zero-initialized memory
• HeapFree(): Frees allocated memory on cleanup

All memory allocation includes proper error handling and cleanup.

File Structure Layout

DOS Header (64 bytes)
DOS Stub (variable size, padded to 0x80)
NT Headers (248 bytes for PE32+)
Section Headers (40 bytes × 3 sections)
Padding to file alignment (0x400)

.text Section (code)
- Machine code
- Padded to file alignment

.rdata Section (read-only data)
- String constants, resources
- Padded to file alignment

.idata Section (import data)
- Import descriptors
- Import lookup table
- Import address table
- Import by name structures
- Padded to file alignment

Virtual Address Layout

0x1000: .text section (SECTION_ALIGNMENT)
0x2000: .rdata section
0x3000: .idata section
0x4000: Next available virtual address

Constants and Defaults

• Image Base: 0x140000000 (default for x64)
• Section Alignment: 0x1000 (4KB)
• File Alignment: 0x200 (512 bytes)
• Entry Point: Configurable RVA
• Subsystem: Console application (IMAGE_SUBSYSTEM_WINDOWS_CUI)

Usage Example

; Create PE context
mov rcx, 0          ; Default image base
mov rdx, 1000h      ; Entry point RVA
call PEWriter_CreateExecutable
mov rbx, rax        ; Save context

; Add kernel32.dll imports
mov rcx, rbx
mov rdx, offset dll_kernel32
mov r8, offset func_GetStdHandle
call PEWriter_AddImport

; Add machine code
mov rcx, rbx
mov rdx, offset code_buffer
mov r8, code_size
call PEWriter_AddCode

; Write executable file
mov rcx, rbx
mov rdx, offset filename
call PEWriter_WriteFile

Build Instructions

1. Ensure MASM64 and Windows SDK are installed
2. Run build.bat to compile PE writer and example
3. Execute PE_Writer_Example.exe to generate hello.exe
4. Test the generated executable

Error Handling

All functions return 0 on failure and non-zero on success. The implementation includes:

• Memory allocation failure checks
• File I/O error handling
• Input validation
• Proper resource cleanup
• Bounds checking for buffers

Limitations

• Maximum 99 imports (MAX_IMPORTS - 1)
• Maximum 64KB code size (MAX_CODE_SIZE)
• Three fixed sections (.text, .rdata, .idata)
• Console subsystem only
• No relocations support
• No digital signatures

Advanced Features

The implementation provides a solid foundation for:

• Custom section creation
• Complex import binding
• Resource embedding
• Digital signing
• Relocation support
• Exception handling tables

Technical Notes

• Pure x64 MASM assembly - no CRT dependencies
• Uses Windows heap for memory management
• Generates PE32+ format for x64
• Compatible with Windows Vista and later
• Follows Microsoft PE specification
• Zero external library dependencies except kernel32.dll

This implementation provides a complete, production-ready PE32+ writer suitable for code generation backends, custom compilers, and executable packers.
