What is TinyInst?

TinyInst is a lightweight dynamic instrumentation library that can be used to instrument only selected module(s) in the process, while leaving the rest of the process to run natively. It is meant to be easy to understand, easy to hack on and easy to hack with. It is not designed to be compatible with all targets (more on that later).

How does it compare to DynamoRIO and PIN?

TinyInst is not meant as a replacement for complex instrumentation frameworks such as DynamoRIO and PIN, but rather an alternative for scenarios where a more lightweight solution would do. TinyInst assumes that the target is well-behaved (in the sense explained below) which is not the case for more complex frameworks. Thus, you probably won’t be able to successfully run TinyInst against malware as was done with DynamoRIO previously. On the other hand, if a target does not work with other frameworks due to the module that does not need to be instrumented, and the instrumented module is well-behaved, it might work with TinyInst. Because with TinyInst, most of the process will run natively, it will have shorter process startup time, and might outperform other solutions in cases where the target process spends a lot of time in the modules where instrumentation is not needed.

How does it compare to Mesos and TrapFuzz?

TinyInst is a full binary rewriting solution, so arbitrary behavior can be changed in the target module. This allows it, for example, to be able to extract edge coverage instead of only basic blocks. Additionally, TinyInst does not depend on other software, such as IDA Pro, to identify basic blocks.

Which operating system does TinyInst support?

TinyInst is working on Windows (x86 and x64), macOS (x64 and ARM64), Linux (x64 and ARM64) and Android (ARM64). Please see README in the corresponding directory for each operating system for additional notes and limitations.

Which targets are compatible with TinyInst?

TinyInst assumes all instrumented modules are well-behaved in the sense that

• There is no self-modifying code
• Return address on the stack is never accessed by the program directly OR/AND (depending on the settings)
• No data is ever stored before the top of the stack (on addresses lower than pointed to by ESP/RSP). This condition can be relaxed into "no data before (ESP/RSP - arbitrary_offset)" using the -stack_offset flag.

TinyInst also requires DEP/NX to be enabled for the target process. If that is not already the case, you can use the -force_dep flag to force it on. However, in the unlikely case that the target genuinely needs DEP off to function properly, forcing it on might cause it to misbehave.

What is the performance overhead?

According to early measurements on image decoding, on a well-behaving 64-bit target with default TinyInst settings, the performance overhead was around 15% without a client and about 20% with the example coverage-collecting client. Note that this does not include the timeout introduced by initially instrumented the modules. See performance tips below for more details.

Building TinyInst

1. Open a terminal and set up your build environment (e.g. On Windows, run vcvars64.bat / vcvars32.bat)

2. Navigate to the directory containing the source

3. Run the following commands (change the generator according to the version of IDE and platform you want to build for):

Windows

mkdir build
cd build
cmake -G "Visual Studio 16 2019" -A x64 ..
cmake --build . --config Release

macOS

mkdir build
cd build
cmake -G Xcode ..
cmake --build . --config Release

Linux

mkdir build
cd build
cmake ..
cmake --build . --config Release

Cross-compiling for Android

mkdir build
cd build
cmake -DCMAKE_TOOLCHAIN_FILE=</path/to/android/ndk>build/cmake/android.toolchain.cmake -DANDROID_NDK=</path/to/android/ndk> -DANDROID_ABI=arm64-v8a -DANDROID_PLATFORM=<platform> ..
cmake --build . --config Release

Note #1: 64-bit build will also run against 32-bit targets on Windows and Linux operating systems

Note #2: Encountering problems creating a 32-bit build on 64-bit Windows due to the environment not being properly set up and libraries missing? Open the generated .sln file in Visual Studio and build from there instead of running cmake --build. Also note that 64-bit build is going to work on 32-bit targets, so creating a 32-bit build might not be necessary.

Using TinyInst

TinyInst is primarily meant to be used as a library inside other programs.

A TinyInst client is written as a subclass of the TinyInst class. The client can then override the API methods it needs. The API methods are defined below.

After the client is created, it must be initialized with command line options by calling

void init(int argc, char **argv);

The command line options are defined below and a client can also define their own. After that, to run and control an instrumented program, the following functions can be used.

DebuggerStatus Run(int argc, char **argv, uint32_t timeout); DebuggerStatus Attach(unsigned int pid, uint32_t timeout);

These functions either run a program (using the specified command line) or attach to an already running program. If no target method is specified, the target will continue running until either the program exits, the program crashes, or the timeout (given in milliseconds) expires. If a target method is defined, TinyInst is going to return whenever the target method is entered and whenever target method returns, allowing the caller to perform additional tasks.

When Run and Attach return while the target process is still alive, the following functions can be used to either terminate the process or continue execution.

DebuggerStatus Kill();

DebuggerStatus Continue(uint32_t timeout);

TinyInst comes with an example coverage binary, which can be invoked using

<options> -- <target command line>

Example on Windows:

litecov.exe -instrument_module notepad.exe -coverage_file coverage.txt -- notepad.exe

Instrumentation API

Debugger event callbacks

These callbacks are for information only and the client should not emit any instrumented code during them. Clients must call the same handler defined in the superclass before handling these events themselves.

OnProcessCreated Called when the target process is created or attached.

OnProcessExit Called when the target process exits.

OnProcessEntrypoint Called when the process (main binary) entrypoint gets reached

OnTargetMethodReached If the target method is defined, called when the target method is reached for the first time.

OnModuleLoaded Called when a module is loaded. Called for each module, not just instrumented ones.

OnModuleUnloaded Called when a module is unloaded. Called for each module, not just instrumented ones.

OnException
