│                    Z-Jail                            │
├──────────────────────────────────────────────────────┤
│  Truthimatics PV  (evidence-based verdict engine)    │
│  Namespaces       (mount, pid, net, ipc, uts)        │
│  pivot_root       (chroot on steroids)               │
│  Capabilities     (drop all, lock securebits)        │
│  NO_NEW_PRIVS     (no privilege escalation)          │
│  seccomp-BPF      (whitelist: 15 syscalls only)      │
│  Audit            (JSON logging + BLAKE2b hashing)   │
└──────────────────────────────────────────────────────┘

---

Table of Contents

• Quick Start
• Why Z-Jail
• Architecture
• Layers
• Usage
• Build & Install
• Testing
• Performance
• Threat Model
• Documentation
• Roadmap
• License

---

Quick Start

git clone https://github.com/Division-36/Z-Jail.git
cd Z-Jail
make
sudo ./z_jail --root=/path/to/rootfs --seccomp-enforce -- /bin/ls

The --root directory should contain a minimal filesystem with the target binary and its dependencies (for static binaries, just the binary is enough).

---

Why Z-Jail

Existing sandboxing solutions make trade-offs:

	Z-Jail	Firecracker	gVisor	bwrap	nsjail
External deps	zero	libc, seccomp	Go runtime	libc	libc, protobuf
Binary size	~73 KiB	20+ MiB	40+ MiB	~70 KiB	~1 MiB
VM isolation	no	yes (microVM)	no (sandbox)	no	no
seccomp whitelist	yes	no	yes	optional	yes
Content hashing	yes	no	no	no	no
Audit JSON	yes	no	yes	no	partial
Build complexity	one make	complex	complex	trivial	moderate

Z-Jail fills the niche between bwrap (minimal, no seccomp-by-default) and nsjail (featureful, heavy deps). It is designed for CI pipelines, CTF jail challenges, and lightweight code evaluation where you need defence-in-depth without pulling in a container runtime.

---

Architecture

Data Flow

flowchart LR
    CLI[CLI args] --> P[parse_args]
    P --> C{clone namespaces}
    C -->|child| CR[child_run]
    C -->|parent| W[waitpid]
    CR --> RL[setrlimit]
    RL --> FD[close fds >= 3]
    FD --> DUMP[PR_SET_DUMPABLE=0]
    DUMP --> PV[pivot_root]
    PV --> NNP[PR_SET_NO_NEW_PRIVS]
    NNP --> CAP[drop capabilities]
    CAP --> SC[seccomp-BPF]
    SC --> SIG[signal parent]
    SIG --> EX[execve target]
    W --> A[audit JSON]
    A --> EXIT[exit]

Layer Ordering

Each layer is ordered so that a later layer can't be undone by an earlier one:

1. setrlimit — cap CPU, address space, file count, processes before anything else
2. fd scrub — close all inherited fds except the report pipe
3. PR_SET_DUMPABLE=0 — core dumps disabled, /proc/self/mem locked down
4. pivot_root — detach from host filesystem; old root unmounted lazily
5. PR_SET_NO_NEW_PRIVS — no setuid, no capset escalation after this point
6. drop_caps — zero out all capabilities, lock securebits
7. seccomp-BPF — restrict syscalls to whitelist only
8. signal parent — tell the parent the sandbox is ready
9. execve — replace process with the target binary

sequenceDiagram
    participant P as Parent
    participant C as Child
    P->>C: clone (NEWNS|NEWPID|NEWNET|NEWIPC|NEWUTS)
    Note over C: setrlimit(CPU, AS, NOFILE, NPROC)
    Note over C: close(all fds > 2)
    Note over C: PR_SET_DUMPABLE=0
    Note over C: pivot_root → chdir("/") → umount -l
    Note over C: PR_SET_NO_NEW_PRIVS
    Note over C: capset(all zero) + securebits
    Note over C: seccomp(SECCOMP_MODE_FILTER, whitelist)
    C->>P: write(pipe, ready=1)
    Note over C: execve(target)
    P->>P: waitpid
    P->>P: write audit JSON

---

Layers

1. Truthimatics Public Version

Evidence-based verdict engine. Collects weighted observations about the executed binary and determines a final verdict (DETERMINISTIC, REJECT, or UNCERTAIN). Each observation carries a weight; any single observation with weight >50% of total decides the verdict.

2. Namespaces

Five namespaces are created via clone():

Namespace	Flag	Purpose
Mount	CLONE_NEWNS	Isolated filesystem tree
PID	CLONE_NEWPID	Process ID space (child is pid 1)
Net	CLONE_NEWNET	No network interfaces
IPC	CLONE_NEWIPC	No shared memory / semaphores
UTS	CLONE_NEWUTS	Separate hostname

Requires CAP_SYS_ADMIN in the initial namespace.

3. pivot_root

Replaces the mount namespace root with the --root directory:

1. Bind-mount the root directory onto itself (MS_BIND|MS_REC)
2. pivot_root(new_root, put_old) — swap the mount tree
3. chdir("/") — move into the new root
4. umount2("/.pivot_old", MNT_DETACH) — detach old root
5. rmdir("/.pivot_old") — clean up

This is strictly stronger than chroot(2) — there is no way for the sandboxed process to escape back to the host root, even with CLONE_NEWNS from inside the sandbox (which is already blocked by seccomp).

4. Capabilities

All capabilities are dropped via:

capset(hdr, data)  // data = {0, 0, 0}
prctl(SECBIT_KEEP_CAPS_LOCKED | SECBIT_NO_SETUID_FIXUP | ...)

The process drops setuid/setgid before capset so the uid change takes effect while CAP_SETUID is still held. After capset, all caps are gone and the securebits are locked — no re-enablement is possible.

5. NO_NEW_PRIVS

prctl(PR_SET_NO_NEW_PRIVS, 1, 0, 0, 0);

Prevents the process or its children from gaining new privileges via setuid binaries, file capabilities, or LSM transitions. Irreversible.

6. seccomp-BPF (whitelist-v1)

Allow-list of 15 syscalls — anything not on the list gets SECCOMP_RET_KILL:

Syscall	Number	Notes
read	0	stdin
write	1	stdout/stderr + report pipe
openat	257	file access (not open)
close	3	—
lseek	8	—
brk	12	heap management
mmap	9	arg-restricted: flags & 4 == 0 (no MAP_SHARED), flags == 0x22 (MAP_PRIVATE|MAP_ANONYMOUS)
munmap	11	—
execve	59	single exec at startup
exit_group	231	clean process exit
rt_sigaction	13	signal handlers
rt_sigprocmask	14	signal masking
getrandom	318	random number source
clock_gettime	228	timing
fstat	5	file metadata

The BPF filter is generated dynamically: for each whitelist entry, a jump chain is emitted that either allows (if syscall matches) or falls through to KILL. Architecture is checked first (AUDIT_ARCH_X86_64).
