A Zeek OpenVPN protocol analyzer, based on Spicy.
This is a protocol analyzer that detects OpenVPN traffic. You must install Spicy to use this package.
Blogs and webinars detailing the development of this protocol analyzer:
$ cat conn.log
#separator \x09
#set_separator ,
#empty_field (empty)
#unset_field -
#path conn
#open 2022-01-21-11-46-35
#fields ts uid id.orig_h id.orig_p id.resp_h id.resp_p proto service duration orig_bytes resp_bytes conn_state local_orig local_resp missed_bytes history orig_pkts orig_ip_bytes resp_pkts resp_ip_bytes tunnel_parents
#types time string addr port addr port enum string interval count count string bool bool count string count count count count set[string]
1613755368.960989 CyO1lb37w2czkxBsPd 192.168.88.3 50568 46.246.122.61 1198 udp ssl,spicy_openvpn_udp 44.271572 5825 8524 SF - - 0 Dd 57 7421 48 9868 -
#close 2022-01-21-11-46-35
$ cat ssl.log
#separator \x09
#set_separator ,
#empty_field (empty)
#unset_field -
#path ssl
#open 2022-01-21-11-46-35
#fields ts uid id.orig_h id.orig_p id.resp_h id.resp_p version cipher curve server_name resumed last_alert next_protocol established ssl_history cert_chain_fps client_cert_chain_fps sni_matches_cert ja3 ja3s
#types time string addr port addr port string string string string bool string string bool string vector[string] vector[string] bool string string
1613755369.067702 CyO1lb37w2czkxBsPd 192.168.88.3 50568 46.246.122.61 1198 TLSv13 TLS_AES_256_GCM_SHA384 x25519 - F - - T CsiI - - - c81fc162549590f0e836b538fe5bfdd7 15af977ce25de452b96affa2addb1036
#close 2022-01-21-11-46-35
