CVE-2023-32233 — nf_tables Use-After-Free: Reproduction & Root-Cause Analysis

What this repo is: my hands-on reproduction and study of CVE-2023-32233, a use-after-free in the Linux kernel Netfilter nf_tables subsystem that allows local privilege escalation, publicly disclosed in May 2023 by Patryk Sondej and Piotr Krysiuk.

Credit: the PoC (exploit.c) and the original write-up are by @Liuk3r. My work in this repo is reproducing the exploit in my own lab (Ubuntu 23.04, kernel 6.2.0-20) and documenting the root cause and exploitation chain below. All testing was done on dedicated lab machines.

My Analysis Notes

Root cause

nf_tables processes configuration updates as an atomic batch. The validation of each operation against the state changes of previous operations in the same batch is insufficient. Concretely:

1. Start with an nft_rule containing a lookup expression on an anonymous nft_set that holds some elements.
2. Send a batch with two operations:
   • NFT_MSG_DELRULE — deletes the rule, which implicitly deletes the lookup expression and the anonymous nft_set;
   • NFT_MSG_DELSETELEM — deletes an element of the already deleted anonymous set.
3. The batch is accepted. nf_tables_commit_release() queues resources onto nf_tables_destroy_list, processed later by nf_tables_trans_destroy_work():

   • first nft_commit_release() → nf_tables_rule_destroy() → nft_lookup_destroy() → nft_set_destroy() → kvfree() frees the nft_set;

   • then, for NFT_MSG_DELSETELEM, nf_tables_set_elem_destroy() calls nft_set_elem_ext() which dereferences the freed nft_set:

If set->ops->elemsize is corrupted, an attacker-chosen memory location is interpreted as an nft_set_ext — the primitive everything else builds on.

Exploitation chain (as reproduced)

1. Win the race against nf_tables_trans_destroy_work() running on a background worker thread: insert a large set-destroy operation as a controlled delay, pin other CPUs busy, and reallocate the freed nft_set chunk from the same CPU with an nft_set of a different type (different elemsize) → type confusion.
2. Craft corrupted nft_set_ext headers with out-of-range offsets so nf_tables_set_elem_destroy() walks adjacent chunks as a list of nft_expr to destroy.
3. Spray nft_log expressions with controlled NFTA_LOG_PREFIX; nft_log_destroy() frees priv->prefix, giving an overlapping allocation primitive in kmalloc-{8..192} (NULL-byte-limited at first).
4. Reclaim with nft_object->udata to lift the NULL-byte restriction on the dangling read.

Notably, the primitives chosen avoid anything CFI would block — no indirect-call hijacking needed at any step.

Defensive takeaways

• Fix: upstream validates batch operations against the full transaction state; patched kernels reject the DELRULE+DELSETELEM sequence on the anonymous set. See the fixing commits referenced in the NVD entry.
• Mitigations that raise the bar: slab freelist hardening (SLAB_FREELIST_HARDENED), INIT_ON_FREE, and per-CPU slab reuse restrictions all attack step 1; CFI (where present) constrains step 3+.
• Detection ideas: audit rules on nf_tables batch netlink messages containing DELRULE+DELSETELEM on anonymous sets; crash triage for nft_set_elem_ext / nf_tables_trans_destroy_work in the stack.
• Attack surface reduction: nftables requires CAP_NET_ADMIN, but unprivileged user namespaces grant it — this is why kernel.unprivileged_userns_clone=0 is a meaningful hardening knob.

Reproduction Guide

Tested under Ubuntu 23.04 (Lunar Lobster), kernel 6.2.0-20-generic.

Installing Build Dependencies

sudo apt install gcc libmnl-dev libnftnl-dev

Building Binary

gcc -Wall -o exploit exploit.c -lmnl -lnftnl

Profile

The built-in profile targets the Ubuntu 23.04 binary kernels (linux-image-6.2.0-20-generic 6.2.0-20.20). To test other kernels, extract symbols into a profile file:

modprobe nf_tables
egrep ' (nft_counter_ops|nft_counter_destroy|free_percpu|modprobe_path)(\s|$)' /proc/kallsyms > profile

Machine-code layout of nft_counter_destroy() varies with compiler and options; see ORIGIN.md for the full parameter reference (nft_counter_destroy_call_offset/mask/check) and race-tuning knobs (race_lead_sleep etc.). Reported success probability is ≥80% on idle bare-metal Intel systems; some microarchitectures (e.g. Alder Lake) need extra tuning.

Safety Warning

The PoC leaves the kernel in an unstable state with corrupted memory after a successful run. Only test on a dedicated, disposable system or VM snapshot — never on anything with data you care about.

Files

• exploit.c — PoC source (by @Liuk3r)
• ORIGIN.md — original vulnerability & exploitation write-up (by Liuk3r)
• README.md — this file: reproduction + my analysis notes

References

• NVD — CVE-2023-32233
• Liuk3r/CVE-2023-32233 — original PoC & write-up
• Theori — CVE-2023-32233: Linux Kernel Privilege Escalation Analysis

Research conducted for defensive/educational purposes in an isolated lab environment.
