PyVEX

PyVEX is Python bindings for the VEX IR.

Project Links

Project repository: https://github.com/angr/pyvex

Documentation: https://api.angr.io/projects/pyvex/en/latest/

Installing PyVEX

PyVEX can be pip-installed:

pip install pyvex

Using PyVEX

import pyvex
import archinfo

# translate an AMD64 basic block (of nops) at 0x400400 into VEX
irsb = pyvex.lift(b"\x90\x90\x90\x90\x90", 0x400400, archinfo.ArchAMD64())

# pretty-print the basic block
irsb.pp()

# this is the IR Expression of the jump target of the unconditional exit at the end of the basic block
print(irsb.next)

# this is the type of the unconditional exit (i.e., a call, ret, syscall, etc)
print(irsb.jumpkind)

# you can also pretty-print it
irsb.next.pp()

# iterate through each statement and print all the statements
for stmt in irsb.statements:
    stmt.pp()

# pretty-print the IR expression representing the data, and the *type* of that IR expression written by every store statement
import pyvex
for stmt in irsb.statements:
    if isinstance(stmt, pyvex.IRStmt.Store):
        print("Data:", end="")
        stmt.data.pp()
        print("")

        print("Type:", end="")
        print(stmt.data.result_type)
        print("")

# pretty-print the condition and jump target of every conditional exit from the basic block
for stmt in irsb.statements:
    if isinstance(stmt, pyvex.IRStmt.Exit):
        print("Condition:", end="")
        stmt.guard.pp()
        print("")

        print("Target:", end="")
        stmt.dst.pp()
        print("")

# these are the types of every temp in the IRSB
print(irsb.tyenv.types)

# here is one way to get the type of temp 0
print(irsb.tyenv.types[0])

Keep in mind that this is a syntactic representation of a basic block. That is, it'll tell you what the block means, but you don't have any context to say, for example, what actual data is written by a store instruction.

VEX Intermediate Representation

To deal with widely diverse architectures, it is useful to carry out analyses on an intermediate representation. An IR abstracts away several architecture differences when dealing with different architectures, allowing a single analysis to be run on all of them:

• Register names. The quantity and names of registers differ between architectures, but modern CPU designs hold to a common theme: each CPU contains several general purpose registers, a register to hold the stack pointer, a set of registers to store condition flags, and so forth. The IR provides a consistent, abstracted interface to registers on different platforms. Specifically, VEX models the registers as a separate memory space, with integer offsets (i.e., AMD64's rax is stored starting at address 16 in this memory space).
• Memory access. Different architectures access memory in different ways. For example, ARM can access memory in both little-endian and big-endian modes. The IR must abstract away these differences.
• Memory segmentation. Some architectures, such as x86, support memory segmentation through the use of special segment registers. The IR understands such memory access mechanisms.
• Instruction side-effects. Most instructions have side-effects. For example, most operations in Thumb mode on ARM update the condition flags, and stack push/pop instructions update the stack pointer. Tracking these side-effects in an ad hoc manner in the analysis would be crazy, so the IR makes these effects explicit.

There are lots of choices for an IR. We use VEX, since the uplifting of binary code into VEX is quite well supported. VEX is an architecture-agnostic, side-effects-free representation of a number of target machine languages. It abstracts machine code into a representation designed to make program analysis easier. This representation has five main classes of objects:

• Expressions. IR Expressions represent a calculated or constant value. This includes memory loads, register reads, and results of arithmetic operations.
• Operations. IR Operations describe a modification of IR Expressions. This includes integer arithmetic, floating-point arithmetic, bit operations, and so forth. An IR Operation applied to IR Expressions yields an IR Expression as a result.
• Temporary variables. VEX uses temporary variables as internal registers: IR Expressions are stored in temporary variables between use. The content of a temporary variable can be retrieved using an IR Expression. These temporaries are numbered, starting at t0. These temporaries are strongly typed (i.e., "64-bit integer" or "32-bit float").
• Statements. IR Statements model changes in the state of the target machine, such as the effect of memory stores and register writes. IR Statements use IR Expressions for values they may need. For example, a memory store IR Statement uses an IR Expression for the target address of the write, and another IR Expression for the content.
• Blocks. An IR Block is a collection of IR Statements, representing an extended basic block (termed "IR Super Block" or "IRSB") in the target architecture. A block can have several exits. For conditional exits from the middle of a basic block, a special Exit IR Statement is used. An IR Expression is used to represent the target of the unconditional exit at the end of the block.

VEX IR is actually quite well documented in the libvex_ir.h file (https://github.com/angr/vex/blob/dev/pub/libvex_ir.h) in the VEX repository. For the lazy, we'll detail some parts of VEX that you'll likely interact with fairly frequently. To begin with, here are some IR Expressions:

IR Expression	Evaluated Value	VEX Output Example
Constant	A constant value.	0x4:I32
Read Temp	The value stored in a VEX temporary variable.	RdTmp(t10)
Get Register	The value stored in a register.	GET:I32(16)
Load Memory	The value stored at a memory address, with the address specified by another IR Expression.	LDle:I32 / LDbe:I64
Operation	A result of a specified IR Operation, applied to specified IR Expression arguments.	Add32
If-Then-Else	If a given IR Expression evaluates to 0, return one IR Expression. Otherwise, return another.	ITE
Helper Function	VEX uses C helper functions for certain operations, such as computing the conditional flags registers of certain architectures. These functions return IR Expressions.	function_name()

These expressions are then, in turn, used in IR Statements. Here are some common ones:

IR Statement	Meaning	VEX Output Example
Write Temp	Set a VEX temporary variable to the value of the given IR Expression.	WrTmp(t1) = (IR Expression)
Put Register	Update a register with the value of the given IR Expression.	PUT(16) = (IR Expression)
Store Memory	Update a location in memory, given as an IR Expression, with a value, also given as an IR Expression.	STle(0x1000) = (IR Expression)
Exit	A conditional exit from a basic block, with the jump target specified by an IR Expression. The condition is specified by an IR Expression.	if (condition) goto (Boring) 0x4000A00:I32
