CVE-2026-33317 OP-TEE PKCS#11 PoC

This repository contains the Normal World proof of concept, reproduction notes, and captured logs for CVE-2026-33317 / GHSA-8cqw-mg7v-c9p9.

The official OP-TEE advisory describes missing validation in entry_get_attribute_value() for PKCS11_CMD_GET_ATTRIBUTE_VALUE. The bug can cause out-of-bounds reads from the PKCS#11 TA heap and, with a malformed attribute template, writes beyond the temporary template buffer. This PoC targets the out-of-bounds write case and demonstrates Secure World heap corruption in the PKCS#11 TA.

• Advisory: https://github.com/OP-TEE/optee_os/security/advisories/GHSA-8cqw-mg7v-c9p9
• CVE: CVE-2026-33317
• Affected package: OP-TEE PKCS#11 TA
• Affected versions in advisory: >= 3.13.0
• Patched versions in advisory: 4.11 and later
• CVSS v3.1 in advisory: 8.7 High
• Weaknesses in advisory: CWE-125, CWE-787

Use this only in a local lab or another environment where you are authorized to test OP-TEE.

What Is In This Folder

The local working copy this README was prepared from was a flattened OP-TEE QEMUv8 workspace. The .repo directory and all .git metadata files/directories were removed, so that local archive is no longer usable with repo sync or normal git history commands.

The GitHub repository intentionally excludes the bulky OP-TEE/QEMU source trees, toolchains, and build outputs. Recreate those from qemu-v8-setup.md, or copy the PoC files into an existing OP-TEE qemu_v8 build root, before running the automated QEMU reproduction from a fresh clone.

Important top-level files:

The prepared local archive also had source/build directories such as optee_os, optee_client, qemu, linux, trusted-firmware-a, u-boot, buildroot, out-br, and toolchains; these are ignored for publication.

Vulnerability Summary

In the vulnerable optee_os tree, ta/pkcs11/src/object.c iterates over a client-supplied serialized attribute template:

cur = (char *)template + sizeof(struct pkcs11_object_head);
end = cur + template->attrs_size;
...
data_ptr = cli_head.size ? cli_ref->data : NULL;
rc = get_attribute(obj->attributes, cli_head.id, data_ptr, &cli_head.size);

The loop does not prove that each attribute header and its data area are fully inside the allocated template. The PoC sends:

• attrs_size = 8, exactly one pkcs11_attribute_head and no data bytes.
• attrs_count = 1.
• cli_head.id = CKA_LABEL.
• cli_head.size = 16, matching the created object's 16-byte label.

That creates a 16-byte template allocation:

sizeof(pkcs11_object_head) + attrs_size = 8 + 8 = 16

cli_ref->data then points at template + 16, exactly one byte past the end of the allocation. get_attribute() in ta/pkcs11/src/attributes.c sees that the caller-provided size is large enough and copies the 16-byte label to that out-of-bounds pointer, corrupting the PKCS#11 TA heap.

Quick Start

Prerequisites used by the prepared QEMUv8 workspace:

• Linux x86-64 host
• expect
• An OP-TEE qemu_v8 workspace with build outputs, toolchains, and QEMU binary laid out like the local archive described in qemu-v8-setup.md

Build the PoC:

./build_poc.sh

Expected build result:

Built: out/bin/c01_poc

Run the automated QEMUv8 reproduction:

./run_c01.sh

The wrapper checks for these staged files before booting:

• out/bin/bl1.bin
• out/bin/Image
• out/bin/rootfs.cpio.gz
• out/bin/c01_poc

If the build artifacts are missing, recreate/build the OP-TEE workspace first and then rerun ./build_poc.sh.

Expected Result

The Normal World log should show the crafted request:

[+] TEEC session with PKCS#11 TA opened
[+] INIT_TOKEN  rc=0x00000000 OK
[+] OPEN_SESSION rc=0x00000000, session_handle=0x00000001
[+] CREATE_OBJECT rc=0x00000000, obj_handle=0x00000001
[+] Object has CKA_LABEL = "AAAAAAAAAAAAAAAA" (16 bytes)
[+] Sending malicious C_GetAttributeValue (attrs_size=8, cli_head.size=16)...
[+] GET_ATTRIBUTE_VALUE[0] rc=0xffffffff

The Secure World log should contain the allocator assertion and TA panic:

E/TA:  assertion 'BH((char *) b - b->bh.bsize)->prevfree == 0' failed at lib/libutils/isoc/bget.c:1022 in brel()
E/TC:? 0 TA panicked with code 0xffff0000
E/LD:  Status of TA fd02c9da-306c-48c7-a49c-bbd827ae86ee

Captured logs from a successful run are already present at:

• out/bin/c01_nw.log
• out/bin/c01_sw.log

PoC Flow

c01_poc.c invokes the PKCS#11 TA UUID fd02c9da-306c-48c7-a49c-bbd827ae86ee through libteec:

1. Open a TEEC session with the PKCS#11 TA.
2. Initialize token slot 0.
3. Open an R/W PKCS#11 session.
4. Create an AES session object with CKA_LABEL = "AAAAAAAAAAAAAAAA".
5. Send a malformed CMD_GET_ATTRIBUTE_VALUE request with attrs_size = 8 and cli_head.size = 16.

The first malicious request is enough to corrupt heap metadata. The TA then panics when the OP-TEE bget allocator detects the corrupted block metadata.

Notes

• run_c01.sh shares out/bin into the guest over virtio-9p and writes logs back to the same directory.
• In a full local archive, staged boot artifact links in out/bin should point to artifacts inside that archive. The published GitHub repository only tracks the captured out/bin/c01_*.log files.
• C-01-reproduction.md documents an earlier x86 ASAN harness approach. The runnable PoC in this folder is the QEMUv8 TEEC PoC: c01_poc.c.
• Since repo metadata was removed, treat this directory as an archived PoC workspace rather than an upstream-synchronized OP-TEE checkout.
