DARKCLOAK

Linux process identity cloaking

DARKCLOAK chains the manipulation of all userspace-visible identity sources into an 11-phase sequential pipeline that progressively transforms a process until it becomes indistinguishable from the impersonated one to userspace monitoring tools. To the best of our knowledge, no published tool combines the simultaneous manipulation of all userspace-visible identity sources.

The full technical write-up is available on the RAZOR blog.

What gets spoofed

• task_struct->comm: via PR_SET_NAME
• argv[0]: via direct stack overwrite
• Command line (/proc/$PID/cmdline): via PR_SET_MM_ARG_START/END
• Environment (/proc/$PID/environ): via PR_SET_MM_ENV_START/END
• Executable path (/proc/$PID/exe): via PR_SET_MM_EXE_FILE
• File-backed VMAs (/proc/$PID/maps): replaced with anonymous memory
• Process namespace visibility: via unshare

How it works

The pipeline runs in a strict order defined by the dependencies between the kernel subsystems being manipulated:

1. ELF introspection: parses the auxiliary vector at _start to resolve the PHT and obtain the virtual address ranges of all three PT_LOAD segments
2. Credential read: getresuid / getresgid to store original UIDs and GIDs for later restoration
3. UID escalation: setresuid(0,0,0) if any of the three UIDs is 0
4. Capability escalation: copies the permitted set into the effective and inheritable sets via capget/capset
5. Identity spoofing:
   • prctl(PR_SET_NAME) → overwrites task_struct->comm
   • direct stack write at [rsp+8] → overwrites argv[0]
   • prctl(PR_SET_DUMPABLE, 0) → blocks access and from unprivileged processes

The mmap trampoline

PR_SET_MM_EXE_FILE fails with EBUSY while any VMA is still backed by the original binary. Since the .text segment cannot be unmapped while RIP is inside it, the anonymization runs from a temporary anonymous page:

1. Allocate a 4096-byte anonymous page (mmap)
2. Copy the anonymization code (mm_start→mm_end) and segment metadata into it
3. Make the page executable (mprotect)
4. Jump into it: RIP leaves .text
5. For each of the three PT_LOAD segments: mmap a fresh anonymous region → memcpy segment contents → munmap the original → mremap the anonymous copy back to the original address → mprotect to restore original permissions
6. Return to now-anonymous .text, unmap the trampoline page

The binary is a static ELF with no interpreter, so the runtime VMA layout is fully deterministic: three PT_LOAD segments, the stack, and the kernel vDSO.

Build

nasm -f elf64 darkcloak.asm -o darkcloak.o
ld darkcloak.o -o darkcloak

Configuration

Spoofing targets are defined at compile time in the .data section. The defaults impersonate sshd:

mimic_name    db 'sshd', 0
mimic_argv    db './sshd', 0
mimic_exe     db '/usr/sbin/sshd', 0
mimic_cmdline db '/usr/sbin/sshd', 0, '-D', 0, '[email protected]', 0, ...
mimic_environ db 'LANG=en_US.UTF-8', 0, 'NOTIFY_SOCKET=/run/systemd/notify', 0, ...

To impersonate a different process, update these values before building.

Usage

./darkcloak

Requires CAP_SYS_RESOURCE, CAP_SETUID, CAP_SETGID, and CAP_SETPCAP in the permitted set. If CAP_SYS_RESOURCE is absent, the MM spoofing block (VMA anonymization + EXE_FILE swap) is skipped entirely. If CAP_SETPCAP is absent, the tool falls back from PR_SET_SECUREBITS to PR_SET_KEEPCAPS.

Verify

./darkcloak &
PID=$!

cat /proc/$PID/comm
readlink /proc/$PID/exe
cat /proc/$PID/cmdline | tr '\0' ' '
cat /proc/$PID/environ | tr '\0' '\n' | head -3
cat /proc/$PID/maps | head -5
cat /proc/$PID/status | grep -E 'Uid|Gid|Cap'
ps aux | grep $PID

Disclaimer

Published exclusively for educational and research purposes. Use only on systems you own or have explicit written authorization to test.
